- Page 1 RADIOLINK DIGITAL PROPORTIONAL R/C SYSTEM OPERATING INSTRUCTIONS Before use please read these instructions completely...
- Page 2 1 Introduction to the RL036T radio Thank you for purchasing Radiolink RL036T-001A four channel digital radio system it is a good quality radio and can be used in electric helicopter, engine aircraft, electric park-flying. It is important that you care fully read the manual before operate your moder .
- Page 3 2 RL036T TRANSMITTER Throttle actuator trim power and low battery display Elevator trim Hook Throttle actuator curve pitch of screws trim trim Antenna big and small rudder switch Undercarriage switch Drillmaster switch 3D switch Elevator/ Rudder Throttle stick. actuator /elevator aileron stick.
- Page 4 On/off Switch Rudder positive and negative Aileron positive phase switch negative phase switch Elevator positive and negative phase switch Throttle actuator positive and negative phase switch...
- Page 5 antenna handgrip Drillmaster switch 3D switch Trainer cord jack Battery Book cover battery storehouse (8pcs AA 1.5V Charging jack...
-
Page 6: Transmitter Operation
3 TRANSMITTER OPERATION LEFT RIGHT Aileron operation When the aileron stick is moved to the right,the right aileron is raised and the left aileron is lowered.relative to the direction of flight and the plane turns to the right.when the aileron stick is moved to the left.The ailerons move in the opposite direction DOWN Elevator operation... - Page 7 is raised and the tail of the plane is forced down.the air floe applied to the wings is changed.the lifting force is increased,and the plane climbs(up operation) when the elevator stick is pushed forward,the elevator is lowered the tail of the please is forced up.the air flow applied to the wings is changed.the lifting force is do creased and the plane dives(doen operation) HIGH...
- Page 8 LEFT RIGHT Rudder operation When the rudder stick is moved to the right,the rudder moves to the right,and the nose points to the right,relative to the direction of flight.When the rudder stick is moved to the left,the rudder moves the left and the direction of travel of the plane changs.
- Page 9 5 precautions during flight Do not fly simultaneously on the same frequency.Interference may cause acrash. *Use of the same frequency will cause Interference even if the modulation method(FM,PCM) is different. Do not fly in rainy or windy days water will penetrate into the transmitter and cause faulty operation,or loss of control,and cause acrash.
