- Page 1 Polycom 5300LF2 System ® ™ Hardware Guide June 2011 3725-73553-001A...
-
Page 2: Trademark Information
(e.g., a book or sound recording). Every effort has been made to ensure that the information in this document is accurate. Polycom, Inc., is not responsible for printing or clerical errors. Information in this document is subject to change without notice. - Page 3 5300LF2 Hardware Guide 5300LF2 VBP-E Series Physical connections and LED’s 1 Click - Nothing Erase 2 Clicks - Reset CLI password and restarts the system 3 Clicks - Restore to factory default 1 x 10/100/1000 Mbps Ethernet port for optional management network...
- Page 4 5300LF2 Hardware Guide Symbol Function Color Signal Off – No Power, the system is off Power Status Green On – Power is good, the system is on Off – No data access to the IDE drive Data Status On – Data is being written to the IDE drive...
- Page 5 5300LF2 Hardware Guide Color Indication Status Label 1: Ethernet port is receiving power Green or other 2: Good link between the Ethernet port and the connected switch 1: The adapter and switch are not receiving power ACK/LINK 2: No connection between both ends of the network cable, check cable, replace cable.
- Page 6 5300LF2 Hardware Guide Input Power Socket Accepts 3-pin Shroud Female plug for input power On/Off Switch Used to turn the system on and off Currently not used...
- Page 7 5. The EULA license agreement will now be displayed. After reading the license agreement, click “I agree” at the bottom to continue configuring the system. Configure the Network parameters as defined in the Configuration Guide contained on the VBP Documentation Library CD provided with the system. The Configuration Guide is also available on the Polycom Web site.
- Page 8 5300LF2 Hardware Guide 5300LF2 VBP-ST series Physical connections and LED’s 1 Click - Nothing Erase 2 Clicks - Reset CLI password and restarts the system 3 Clicks - Restore to factory default 1 x 10/100/1000 Mbps Ethernet port for optional management network Port 3 - Management interface connectivity, this interface must not be on the same network as the WAN or LAN subnets.
- Page 9 5300LF2 Hardware Guide Symbol Function Color Signal Off – No Power - the system is off Power Status Green On – Power is good - the system is on Off – No data access to the IDE drive Data Status On –...
- Page 10 5300LF2 Hardware Guide Label Color Indication Status 1: Ethernet port is receiving power Green or other 2: Good link between the Ethernet port and the connected switch 1: The adapter and switch are not receiving power ACK/LINK 2: No connection between both ends of the network cable, check cable, replace cable.
- Page 11 5300LF2 Hardware Guide Input Power Socket Accepts 3-pin Shroud Female plug for input power On/Off Switch Used to turn the system on and off Currently not used...
- Page 12 5. The EULA license agreement will now be displayed. After reading the license agreement, click “I agree” at the bottom to continue configuring the system. Configure the Network parameters as defined in the Configuration Guide contained on the VBP Documentation Library CD provided with the system. The Configuration Guide is also available on the Polycom Web site.
-
Page 13: Specifications And Certifications
5300LF2 Hardware Guide Specifications and Certifications Ethernet ports 3 x 10/100/1000 Ethernet Serial Ports 1 x RS-232 8 pin modular Dimensions W: 443mm / 17.4” x D: 292mm / 11.5” x H: 44mm / 1.73” (1U) Weight 13 lbs Power 100/240v VAC - auto-selecting, 50 to 60 Hz with 200W output –... -
Page 14: Physical Installation
5300LF2 Hardware Guide Physical Installation The 5300LF2 is designed for desktop or rack mount installation. Observe the following guidelines when installing the system: • Always verify that the AC cord is disconnected from a power source prior to installation. • Ensure that the installation site has adequate air circulation and meets the minimum operating conditions for the system as specified in the Specifications and Certifications section of this document. - Page 15 In accordance with Part 15 of the FCC rules, the user is cautioned that any changes or modifications not expressly approved by Polycom Inc. could void the user's authority to operate this equipment.
- Page 16 5300LF2 Hardware Guide the above conditions may not prevent degradation of service in some situations. Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment.
- Page 17 5300LF2 Hardware Guide Korea China...
-
Page 18: Eea Regulatory Notices
This Polycom VBP system has been marked with the CE mark. This mark indicates compliance with EEC Directives 89/336/EEC, 73/23/EEC 1999/5/EC. A full copy of the Declaration of Conformity can be obtained from Polycom Ltd., 270 Bath Road, Slough UK SL1 4DX... - Page 19 Polycom] declara que este VBP 5300LF2 está conforme com [Portuguese]: os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovensko Polycom izjavlja, da je ta VBP 5300LF2 v skladu z bistvenimi zahtevami [Slovenian]: in ostalimi relevantnimi določili direktive 1999/5/ES. Slovensky...
-
Page 20: Hardware Warranty
Hardware Warranty For a period of one (1) year after shipment of the Product, Polycom warrants that such Hardware will substantially conform to Polycom’s published specifications for such Hardware on the date of order if properly used in accordance with procedures described in the documentation supplied by Polycom. -
Page 21: End Of Life Products
Polycom encourages you to recycle your end-of-life Polycom products in an environmentally considerate way. In accordance with the requirements of the European Waste Electronic and Electrical Equipment (WEEE) Directive, all Polycom products are marked with the crossed wheelie bin symbol shown below. Products that carry this symbol should be not be disposed of in the household or general waste stream. Detail of the options open to you and the guidance on the requirements for the recycling and environmentally considerate disposal of your end of life Polycom products can be found at http://www.polycom.com/WEEE.
