Belkin OMNIVIEW F1DN102U User Manual

Belkin OmniView® Secure KVM Switch User Manual F1DN102U F1DN104U F1DN108U Common
Criteria supplement
This section supplements the Belkin Quick Installation Guide in accordance with ADO_IGS.1 Common
Criteria Assurance Measure requirements.
This User Guidance and Common Criteria EAL 4 validation apply to the TOE Common Criteria Evaluated
version of OmniView™ Secure KVM Models listed below:
F1DN102U Version v.321211
F1DN104U Version v.321211
F1DN108U Version v.321211
Before you begin: The Users of the Belkin OmniView™ Secure KVM must review all associated
documentation and guidance, prior to proceeding with installation and use of the KVM switch.
1.1 Receipt and preparation of TOE and Environment prior to installation
Receipt
Assure that tamper seals are intact on the KVM switch.
•
Environment preparation
The Belkin OmniView KVM secure must be located in a physically secure location providing
•
physical protection and limited (authorized user) access controls.
1.2 Verification of Common Criteria components
The following are authorized devices for the Common Criteria Evaluated configuration. Assure that
installation processes resulting in the following hardware/firmware configuration:
TOE Belkin Secure KVM Switch 2 Port PN # F1DN102U v.321211
Belkin Secure KVM Switch 4 Port PN # F1DN104U v.321211 (or)
Belkin Secure KVM Switch 8 Port PN # F1DN108U v.321211
(and)
Environment USB Mouse
Environment USB Keyboard (Peripheral Group Member)
Environment Monitor – VGA connector
Environment Host Computers Qty 2, 4 or 8 based on KVM used
resources)
Belkin OmniView® Secure KVM Switch User CC supplement
Firmware Version 3.16
(Peripheral Group Member)
(Peripheral Group Member)
(or)
(IT Environment Computer
