SMC8506T
10/100/1000 Gigabit Copper Switch
• 6 10/100/1000 RJ-45 Ports with 1 expansion bay
• 2 port 1000Base-TX or 2 port 1000SX modules
• Auto MDI/MDIX on all ports
• Half- and full-duplex flow control
• "Smart Function" features:
24K MAC Address Table
Port-based VLAN and L2 Trunking
Password Authentification
Port Mirroring
Desktop and rack mountable
Installation Guide
SMC8506T
Advertisement
Table of Contents
Related Manuals for SMC Networks SMC8506T
Summary of Contents for SMC Networks SMC8506T
- Page 1 SMC8506T 10/100/1000 Gigabit Copper Switch • 6 10/100/1000 RJ-45 Ports with 1 expansion bay • 2 port 1000Base-TX or 2 port 1000SX modules • Auto MDI/MDIX on all ports • Half- and full-duplex flow control • "Smart Function" features: 24K MAC Address Table...
- Page 2 EZ Switch 1000 User Guide From SMC’s EZ line of low-cost workgroup LAN solutions 6 Hughes Irvine, CA 92618 Phone: (949) 707-2400...
- Page 3 6 Hughes, Irvine, CA. All rights reserved. Printed in Taiwan Trademarks: SMC is a registered trademark; and EZ Switch is a trademark of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.
-
Page 4: Limited Warranty
Limited Warranty Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be free from defects in workmanship and materials, under normal use and service, for the applicable warranty term. All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion, repair or replace any product not operating as warranted with a similar or functionally equivalent product, during the applicable warranty term. - Page 5 * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase. SMC Networks, Inc. 6 Hughes Irvine, CA 92618 The information in this manual is subject to change without notice.
-
Page 6: Fcc Class A
EC Conformance Declaration - Class A SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, 2 08970 - Sant Joan Despí, Barcelona, Spain. - Page 7 Industry Canada - Class A This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference- causing equipment standard entitled “Digital Apparatus”, ICES-003 of Industry Canada. Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux appareils numériques de Classe A prescrites dans la norme sur le matérial brouilleur: “Appareils Numériques”, NMB-003 édictée par l’Industrie.
- Page 8 Hardware Description Optional Modules Chapter 2 Equipment Checklist Selecting a site Positioning the switch Sample Applications Switch Operation Chapter 3 Configuring the SMC8506T Main Menu Port Setting VLAN Trunking Aging Function Control Port Enable/Disable Port Mirroring Port-based Priority MAC Address Filtering...
- Page 9 In addition, the SMC8506T is also support one module slot for 2 Ethernet Gigabit ports to uplink to a server or network backbone. These gigabit switches are designed for Plug and Play installation,...
-
Page 10: Features And Benefits
Features and Benefits The SMC EZ Switch™ 1000 gigabit switch is based on advanced chip designs to maximize throughput and increase the efficiency of your network. It features all standards-based technology, built at leading edge manufacturing facilities for reliability; hence, SMC backs your new product with a Limited Lifetime Warranty. - Page 11 • Internal power supply • Advanced functions include: 1. RS-232 and Console port for changing port configurations 2. Port-base VLAN (not support port-base VLAN overlap) 3. Tagged-base QOS (not support port-base QOS) 4. Trunking 5. Port Mirroring 6. Per port Aging Function setting...
-
Page 12: Hardware Description
Flash: Half-Duplex/ Collision Off: Half-duplex or not connected Rear Panel The rear panel of the SMC8506T has an AC inlet power socket, which accepts input power from 100 to 240VAC, 50- 60Hz. And an RS-232 console port for setting up your new... -
Page 13: Optional Modules
SMC8506T via a connection to a console terminal or PC using a terminal emulation program Also shown in the diagram below are two fans for cooling the unit. Rear panel of SMC8506T Optional Modules There are two optional modules; a 2-port 1000BASE-T and a 2-port 100BASE-FX. -
Page 14: Equipment Checklist
Installing the SMC EZ Switch 1000 Equipment Checklist After unpacking the EZ Switch 1000, check the contents of the box to be sure you have received the following components: Check the contents of your package for following parts: 6 port 10/100/1000 Copper Gigabit Switch Power cord 19”... -
Page 15: Positioning The Switch
Configuring the SMC8506T The SMC8506T can only be accessed through the console port on the rear of the unit. Please use the RS232 cable that came with your unit to ensure proper connection to the SMC8506T. -
Page 16: Rs-232 Serial Cable
You must use the enclosed RS-232 serial cable that came with your switch. Attach the 9-pin female connector to the male connector on the switch. Plug the other side of this cable to your PC. Hyper Terminal Launch a “HyperTerminal”, create a new connection, and adjust... - Page 17 (such as a workstation or server). When a port on the switch is connected to a hub (a 10 or 100 Mbps repeater), the bandwidth provided by that port is shared by all the devices connected to the attached hub. However, when a port is connected to an end node or to a device that breaks up the collision domain (e.g.,...
- Page 18 Storm Control and Trunking, the SMC8506T the most cost effect method for brining speed and service to the desktop. Shown in the application diagram on the next page, the SMC8506T connects to a high speed backbone providing close remote locations with bandwidth and service options once reserved only for a fully managed switch.
- Page 19 Network Application – Corporate LAN connecting to a remote site Corporate LAN Connect users to Corporate LAN Small Remote LAN Router Use copper to connect locations up to 100 meters away at gigabit speeds. Shown with optional copper module...
- Page 20 Mbps (full duplex) connection SMC6924M High Performance workstation Network Administrators will find the SMC8506T an easy solution to integrate into a network as technology migrates toward gigabit. It’s Store-and-Forward architecture combined with a large MAC Address SMC8506T –shown with optional 2 port copper...
- Page 21 Gigabit Ethernet is the perfect solution to bottlenecks at the core of the network that are the inevitable result of data-intensive applications and the proliferation of new users. SMC ’s EZ Switch 1000 provides a seamless migration to higher-speed networking...
-
Page 22: Switch Operation
Switch Operation Address Table The SMC8506T is implemented with a 24K MAC address table. This large address table is used to store the address information of nodes in the network, including MAC address, port no, etc. This information comes from the learning process of this gigabit switch.. - Page 23 Therefore, no error packets occurrence, it is the best choice when a network needs efficiency and stability. The Ethernet Switch scans the destination address from the packet- header, searches the routing table provided for the incoming port and forwards the packet, only if required. The fast forwarding makes the switch attractive for connecting servers directly to the network, thereby increasing throughput and availability.
- Page 24 or Full-Duplex mode. 1000Base-TX and 1000Base-SX can only connected Full-duplex mode.
-
Page 25: Main Menu
Configuring the SMC8506T Configuration Operation Document Launch your “HyperTerminal” program and create a new connection with the following settings. After this is done, you’ll see the “Main Menu” which is shown below. Bits per second: 19200 Data bits: 8 Parity: None... -
Page 26: Submenu: (0) Port Setting
Submenu: (0) Port Setting [Port Setting] Auto Neg. Speed 1000 1000 1000 1000 1000 1000 1000 1000 Duplex Flow Control [Tab] : Move to next item [Space Bar] : Toggle item : Save & Exit : Quit [U]:Up, [L]:Left [D]:Down, [R]:Right Use Tab or the “U”,”D”,”L”,”R”... -
Page 27: Submenu :(1) Vlan
Submenu :(1) VLAN [Port base VLAN] [Group 1] [Group 2] [Group 3] [Group 4] [Group 5] [Group 6] [Group 7] [Group 8] member port of trunk group must belong to same VLAN [Tab] : Move to next item [Space Bar] : Toggle item : Save &... -
Page 28: Submenu: (2) Trunk
Submenu: (2) TRUNK [GROUP 1] [GROUP 2] [GROUP 3] [GROUP 4] member port of trunk group must belong to same VLAN [Tab] [Space Bar] : Toggle item [U]:Up, [D]:Down, enables the port you select disables the port you select Trunk port members must belong to same VLAN group. Use Tab or the “U”,”D”,”L”,”R”... -
Page 29: Submenu: (3) Aging Control
Submenu: (3) Aging Control [Port aging] aging time /minutes/ [Tab] : Move to next item [Space Bar] : Toggle item : Save & Exit : Quit Use Tab or the ”L” or”R” keys to move to the item needing to be changed, press the space bar to change it, and ”S”... -
Page 30: Submenu: (5) Port Mirroring
Submenu: (5) Port Mirroring Monitoring Port Egress Port Ingress Port Egress Port : the packets out-going this port Ingress Port: the packets in-coming this port [Tab] : Move to next item [Space Bar] : Toggle item : Save & Exit : Quit [U]:Up, [D]:Down,... - Page 31 Submenu: (6) Port-based Priority [1] [2] [3] [4] [5] [6] [7] [8] level / T : the priority depend on 802.1p / / 1 : lowest / 4 : highest ingress priority / [Tab] [Space Bar] : Toggle item Use Tab or the ”L” or ”R” keys to move to the item needing to be changed, press the space bar to change it, and ”S”...
-
Page 32: Submenu: (7) Mac Address Filter
Submenu: (7) Mac address filter 00-00-00-00-00-00 00-00-00-00-00-00 00-00-00-00-00-00 00-00-00-00-00-00 00-00-00-00-00-00 00-00-00-00-00-00 00-00-00-00-00-00 00-00-00-00-00-00 Packets with source Mac address not equal to 00-00-00-00-00-00 will be discarded [Tab] : Move to next item [Space Bar] : Modify Mac Address : Save & Exit : Quit Use Tab or the “U”,”D”,”L”,”R”... -
Page 33: Submenu: (8) Change Password
Submenu: (8) Change password / 6 characters max. / / Enter key to delete password / new password : ***** reconfirm : ***** User can set password for security , press enter key to disable password check when system boot Submenu: (9) Restore to Factory Default This item will restore configuration to such setting 1 Port with auto-negotiation, 1000M, full duplex, flow-control... - Page 34 Chapter 3 Glossary 10BASE2: IEEE 802.3 Physical Layer Specification for thin cable Ethernet (also called Thin Ethernet) using standard coaxial cable. It is a cost effective network cable that extends up to 200 meters (hence the 2), however, the safety limit is 185 meters before the signal attenuates.
- Page 35 plugs) connectors and has a cable length span of up to 100 meters. It has two versions, STP (Shielded Twisted Pair) which is more expensive and UTP (Unshielded Twisted Pair), the most popular cable. Both these cables come in 5 different categories.
-
Page 36: Adaptive Cut-Through
PCMCIA, CardBus, etc. ADAPTIVE CUT-THROUGH A switch forwarding cut-through technology that adapts its data forwarding process (Cut-Through, Fragment-Free, Store & Forward) according to the data error rate within the network. ATTACHMENT UNIT INTERFACE (AUI) Connector found on many network cards and 10BASE-T hubs, used to attach network cable via a transceiver. -
Page 37: Class Of Service (Cos)
Only two Class II repeaters can be located in the same collision domain. CLASS OF SERVICE (COS) Data delivery can be priorited by using multiple transmit queues on each switch port. This can provide independent priorities for various types of data such as realtime... -
Page 38: Cut-Through
COLLISION DOMAIN See CSMA/CD. COMBINATION CARDS Combo cards combine two or more functions in one card, thereby extending the applications available from the single slot found in most platforms. The most common are data/fax modems combined with network interface cards (NICs). CSMA/CD (Customer Sense Multiple Access/Collision Detection) Baseband communications access method that uses a collision-detection technique. -
Page 39: Fault Tolerant
Network interface card that is in compliance with the IEEE 802.3u standard. This card functions at the media access control (MAC) layer, using carrier sense multiple access with collision detection (CSMA/CD). FAST ETHERNET SWITCH A device that provides full 10 or 100 Mbps bandwidth to each port (segment). FAULT TOLERANT A method of making a computer or network system resistant to software errors and hardware problems. -
Page 40: Full-Duplex
Defines a way for switches to exchange VLAN information in order to register necessary VLAN members on ports along the Spanning Tree so that VLANs defined in each switch can work automatically over a Spanning Tree network. Central connection device for shared media in a star topology. It may add nothing to the transmission (passive hub) or may contain electronics that regenerate signals to boost strength as well as monitor activity (active/intelligent hub). -
Page 41: Igmp Snooping
Multicast Routers and IP Multicast host groups to learn IP Multicast group members. IP MULTICAST FILTERING A protocol that allows a host to inform its local router or switch that it wants to receive transmissions addressed to a specific multicast group. INTERNET... -
Page 42: Interrupt Request (Irq)
CPU on a single chip. In order to function as a computer, it requires a power supply, clock, and memory. MULTICAST SWITCHING A process whereby the switch decides to filter incoming multicast frames, or forward them to all ports contained within the designated multicast VLAN group. - Page 43 NETWARE Novell's family of network operating systems that runs on 286 PCs and up and supports DOS, Windows, OS/2 and Mac workstations. It works with a variety of LAN access methods, including Token Ring, Ethernet, ARCNET and Starlan. NETWORK A set of communication channels interconnecting several or many locations. NETWORK INTERFACE CARD (NIC) Interface card required in the expansion bus of a personal computer to connect to the cabling of a LAN.
-
Page 44: Peripheral Component Interconnect (Pci)
PERIPHERAL COMPONENT INTERCONNECT (PCI) Local bus for PCs from Intel that provides a high-speed data path between the CPU and up to 10 peripherals (video, disk, network, etc.). The PCI bus runs at 33MHz, support s 32-bit and 64-bit data paths, and bus mastering. PCMCIA Personal Computer Memory Card International Association. -
Page 45: Remote Monitoring (Rmon)
Network Interface Card or adapter that enables terminals to connect to a network line. PORT (1) The entrance or physical access point to a repeater, computer, multiplexer, device or network where signals may be supplied, extracted or observed. (2) To convert software to run in a different computer environment. -
Page 46: Simple Network Management Protocol (Snmp)
and selects the most effective route. A router receives physical layer signals from a network, performs data link and network layer protocol processing, then sends the signals via an appropriate data link and physical layer protocols to another network. SEGMENT A separate LAN or collision domain. -
Page 47: Spanning Tree Algorithm
The term for display indicators used to monitor all critical activities in an Accton or switch. SPANNING-TREE ALGORITHM A technology that checks your network for any loop configurations. A loop can often occur in complicated or back-up linked network systems. Spanning-tree detects and directs data along the shortest line to its destination, maximizing the performance and efficiency of the network. -
Page 48: Switched Ports
network into smaller networks and then interconnects the segments to enable them to communicate with each other. SWITCHED PORTS Ports that are on separate collision domains or segments. Twisted pair and fiber optic cable compatible Twisted pair cable TWISTED-PAIR CABLE SEGMENT The cable used to join a repeater and an adapter. - Page 49 Communication network that covers wide geographic areas, such as states and countries. WORKGROUP Two or more individuals who share files and databases. LANs designed around workgroups provide electronic sharing of required data. WORKSTATION (1) High-performance, single user computer that has been specialized for graphics, CAD, CAE or scientific applications.
- Page 50 FOR TECHNICAL SUPPORT, CALL: From U.S.A. and Canada (24 hours, 7 days a week) (800) SMC-4-YOU; (949) 707-2400; (949) 707-2460 (Fax) From Europe (8:00 AM - 5:30 PM UK Greenwich Mean Time) 44 (0) 1188 748740; 44 (0) 1189 748741 (Fax) INTERNET E-mail address: techsupport@smc.com...
