SMC Networks SMC EZ Connect SMC70032AE Specifications

Broadband
The EZ Connect ADSL Ethernet Modem is an ideal high-
speed Internet access solution for home and small business
users. This platform independent ADSL modem allows the
user to enjoy high-speed Internet access and voice transmis-
sion over the existing telephone lines. The SMC70032AE is
compliant with ADSL standards and will operate with the
major DSLAMs worldwide. With up to 8Mbps downstream
and 1Mbps upstream data transfer rates, the SMC70032AE is
the ideal solution for high-bandwidth applications. Accessing
the corporate network, surfing the Internet, and enjoying
multimedia applications has never been easier.
Benefits
Features
• Supports both voice and fast Internet
access over the existing telephone lines.
• ST Microelectronic/Virata chipset
• Compliant to G.dmt (ITU G.992.1),
ANSI T1.413 Issue 2,and G.lite
(ITU G.992.2)
• Built-in micro-filter. 2 port RJ-11
connector (ADSL line and phone
interface)
• One 10Mbps Ethernet port for LAN
connection and one console port for
local management
• Easy installation with Windows 95,98,
6 H u g h e s
98SE, NT, 2000,ME, XP, Linux,and Mac OS
Irv i n e, CA 92618
8.x and up.
1-800-SMC-4YOU • Management: SNMP, MIB II, Telnet, GUI
w w w. s m c. co m
EZ Connect
ADSL Ethernet Modem
Benefits
• Efficiency - share fast Internet access and
voice over the existing phone lines
• Flexible - its versatile chipset is fully
interoperable with a variety of DSLAMs
and FLC
• Fast speeds -
downstream:up to 8Mbps,
upstream:up to 1Mbps
• Easy installation – works with most
Windows operating systems
• Reduce costly truck rolls- service
providers can remotely troubleshoot
connection issues
TM
Model Number::
The SMC70032AE is an easy and flexible solution for the end
user and the Service Provider. The WebConsole utility allows
for simple installation with any Windows based operating sys-
tem and the SMC70032AE's remote management features
allow the service provider to limit expensive truck rolls. By
supporting both bridging and routing, the EZ Connect ADSL
Ethernet Modem allows the user the flexibility to grow with
their network.
This modem is a complete high-speed Internet solution for
any home or small office and is backed by SMC' s limited life-
time warranty and 24/7 technical support.
SMC70032AE
Compatibility
• IEEE 802.3
• G.dmt (ITU G.992.1)
• ANSI T1.413 Issue 2
• G.lite (ITU G.992.2)
