SMC Networks ADSL2 Barricade N Pro SMC7904WBRA-N Specification Sheet

WIRELESS
OVERVIEW
The ADSL2 Barricade™ N Pro Modem Router (SMC7904WBRA-N) is the
perfect all-in-one networking solution for connecting and sharing your high
speed ADSL Internet connection. Designed for the home and offi ce, this
platform independent multi-functional router combines a built-in ADSL2/2+
Modem, 4-port 10/100 LAN switch, high speed Wireless-N (draft 802.11n)
access point, NAT fi rewall with Stateful Packet Inspection (SPI) and a user
friendly web-based management interface in one convenient device.
The built-in wireless access point is Wi-Fi certifi ed for full compliance with
the 802.11n draft v2.0 standard, as well as the popular Wireless-G (802.11g)
and Wireless-B (802.11b) standards. This next generation wireless networking
standard utilizes advanced MIMO (Multiple-In, Multiple-Out) technology to
deliver incredible speed and range. With wireless speeds up to 300Mbps and
up to 3x the coverage, there is enough bandwidth to simultaneously stream
video and audio, play online games, transfer large fi les, make VoIP calls and
FEATURES
Built-in ADSL2/2+ Modem
4-port 10/100 LAN switch with auto MDI-MDIX
Built-in Wireless-N (draft 802.11n) access point
WPA/WPA2 Encryption
Wi-Fi Protected Setup™ (WPS)
NAT fi rewall with Stateful Packet Inspection (SPI)
Web-Based management interface
www.smc-asia.com
SMC7904WBRA-N
ADSL2 Barricade™ N Pro
Draft 11n Wireless 4-port ADSL2/2+ Modem Router
surf the Internet. With security being a key consideration, SMC7904WBRA-N
supports the latest WPA and WPA2 wireless encryption standards, which
prevent unauthorized access to wireless networks and ensure data is secure.
Wireless security can also be set up easily using Wi-Fi Protected Setup™
(WPS) that enables push button or PIN confi guration.
The integrated NAT fi rewall with SPI provides protection from hackers and
Denial of Service attacks by analyzing individual data packets, to ensure
that only authorized packets are allowed access to the network. Using the
Access Control feature parents or network administrators can block certain
websites, limit web access based on time or dates, and/or block internet
access for applications like P2P utilities or games. Finally, confi guration of
your internet connection and advanced router functions is made simple and
straightforward with the EZ™ Installation Wizard and intuitive web-based
management interface.
BENEFITS
Plugs directly into your ADSL line for always on high speed Internet access – up
to 24Mbps download speeds.
Directly connect four computers or expand your network by connecting additional
switches. Auto MDI-MDIX means you do not need to worry about cross-over cables.
With wireless speeds up to 300Mbps and extended coverage, there is enough
bandwidth to simultaneously stream video and audio, play online games, transfer
large fi les, make VoIP calls and surf the Internet.
Prevents unauthorized access to your wireless network and insures your data is
secure.
Makes wireless security setup easy with push button and PIN confi guration
methods.
Provides protection from hackers and Denial of Service attacks by analyzing indi-
vidual data packets, to ensure that only authorized packets are allowed access to
your network.
Simple and straightforward set-up with the intuitive web-based management
interface and Installation Wizard.
