Page 3 54Mbps Wireless Voip Router with built-in ADSL Modem From SMC’s line of award-winning connectivity solutions 38 Tesla December 2005 Irvine, CA 92618 R.01 F/W 2.04 (SIP) Phone: (949) 679-8000...
Page 4 SMC Networks, Inc. 38 Tesla Irvine, CA 92618 All rights reserved. Trademarks: SMC is a registered trademark; and Barricade is a trademark of SMC Networks, Inc. Other product and company names are trademarks or registered trademarks of their respective holders.
Page 5 All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller. SMC may, at its own discretion, repair or replace any product not operating as warranted with a similar or functionally equivalent product, during the applicable warranty term.
Page 6 RIGHTS, WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.
Page 7 OMPLIANCES Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with instructions, may cause harmful interference to radio communications.
Page 8 OMPLIANCES The REN is used to determine the quantity of devices that may be connected to the telephone line. Excessive RENs on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0).
Page 9 OMPLIANCES EC Conformance Declaration SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, 2o, 4a, 08970 - Sant Joan Despí, Barcelona, Spain. Marking by the above symbol indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/EC).
Page 10 OMPLIANCES Safety Compliance Wichtige Sicherheitshinweise (Germany) 1. Bitte lesen Sie diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie keine Flüssigoder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
Page 11: Table Of Contents
ABLE OF ONTENTS Introduction About the Barricade ......... 1-1 VoIP (Voice over IP) .
Page 12 ABLE OF ONTENTS Configuring the Voice ADSL Router ....4-1 Navigating the Management Interface ......4-2 Making Configuration Changes .
Page 13 ABLE OF ONTENTS Troubleshooting ......A-1 Cables ........B-1 Ethernet Cable .
Page 14 ABLE OF ONTENTS...
Page 15: Introduction
HAPTER NTRODUCTION Congratulations on your purchase of the Barricade g Voice ADSL Router, hereafter referred to as the “Barricade”. We are proud to provide you with a powerful yet simple communication device for connecting your local area network (LAN) to the Internet. For those who want to surf the Internet in the most secure way, this router provides a convenient and powerful solution.
Page 16: Features And Benefits
NTRODUCTION encoding and then compression of the signal into Internet Protocol (IP) packets. The VoIP Router is equipped with a digital signal processor (DSP), which segments the voice signal into frames and stores them in voice packets. These packets are encoded using the industry standard CODECs, G.711, G.723.3 and G.729.
Page 17: Applications
PPLICATIONS Applications Many advanced networking features are provided by the Barricade: • Wireless and Wired LAN The Barricade provides connectivity to 10/100 Mbps devices, and wireless IEEE 802.11b/g compatible devices, making it easy to create a network in small offices or homes. •...
Page 18 NTRODUCTION • DMZ Host Support Allows a networked computer to be fully exposed to the Internet. This function is used when NAT and firewall security prevent an Internet application from functioning correctly. • Security The Barricade supports security features that deny Internet access to specified users, or filter all requests for specific services that the administrator does not want to serve.
Page 19: Installation
HAPTER NSTALLATION Before installing the Barricade g Voice ADSL Router, verify that you have all the items listed under the Package Contents list. If any of the items are missing or damaged, contact your local distributor. Also be sure that you have all the necessary cabling before installing the Barricade.
Page 20: System Requirements
NSTALLATION Note: The ADSL splitter (also called microfilter) is only contained in packages related to specific countries (US, UK, France, The Netherlands). Immediately inform your dealer in the event of any incorrect, missing, or damaged parts. If possible, please retain the carton and original packing materials in case there is a need to return the product.
Page 21: Hardware Description
ARDWARE ESCRIPTION Hardware Description The Barricade contains an integrated ADSL2+ modem and connects to the Internet or to a remote site using its WAN port. This device can be connected directly to your PC or to a local area network using any of the four Fast Ethernet LAN ports.
Page 22 NSTALLATION SMC7908VoWBRA contains the following ports on the rear panel: Figure 2-1. SMC7908VoWBRA Rear Panel Item Description Line Connect the telephone line directly to this port. Phone Connect your regular telephone to this port. Connect your USB storage device or printer to this port. Reset Button Use this button to reset the Barricade and restore the default factory settings.
Page 23 ARDWARE ESCRIPTION SMC7908VoWBRB contains the following ports on the rear panel: Figure 2-2. SMC7908VoWBRB Rear Panel Item Description Phone1 and Connect your regular telephone sets to these ports. Phone 2 Connect your USB storage device or printer to this port. Reset Button Use this button to reset the Barricade and restore the default factory settings.
Page 24: Led Indicators (Smc7908Vowbra)
NSTALLATION LED Indicators (SMC7908VOWBRA) The power and port LED indicators on the front panel for SMC7908VoWBRA are illustrated in the following figure and table. Figure 2-3. SMC7908VoWBRA Front Panel Status Description The Barricade is receiving power. Normal operation. Power off or failure. ADSL ADSL connection is functioning correctly.
Page 25 ARDWARE ESCRIPTION Status Description VoIP The VoIP connection is up and connected. VoIP connection down. Line PSTN call in progress. Flashing Incoming PSTN call. No call in progress. Phone The phone is OFF-Hook talking on a call. Flashing Incoming call. No call in progress.
Page 26: Led Indicators (Smc7908Vowbrb)
NSTALLATION LED Indicators (SMC7908VOWBRB) The power and port LED indicators on the front panel for SMC7908VoWBRB are illustrated in the following figure and table. Figure 2-4. SMC7908VoWBRB Front Panel Status Description The Barricade is receiving power. Normal operation. Power off or failure. ADSL ADSL connection is functioning correctly.
Page 27: Isp Settings
ISP S ETTINGS Status Description VoIP The VoIP connection is up and connected. Phone 1/ VoIP call in progress. Phone 2 No call in progress. ISP Settings Please collect the following information from your ISP before setting up the Barricade: •...
Page 28: Connect The System
NSTALLATION Connect the System The Barricade can be positioned at any convenient location in your office or home. It can also be wall-mounted. No special wiring or cooling requirements are needed. You should, however, comply with the following guidelines: • Keep the Barricade away from any heating devices.
Page 29: Connect The Power Adapter
ONNECT THE YSTEM Warning: Do not plug a phone jack connector into an RJ-45 port. This may damage the Barricade. Note: Use 100-ohm shielded or unshielded twisted-pair cable with RJ-45 connectors for all Ethernet ports. Category 5 cable is recommended. Make sure each twisted-pair cable length does not exceed 100 meters (328 feet).
Page 30: Wall-Mount Installation
NSTALLATION Wall-Mount Installation There are two wall-mount holes at the bottom of the Barricade. Before drilling two holes into the wall, make sure the holes are 112 mm apart. 112 mm 1. Choose a suitable location for the Barricade. Note: It should be accessible for installing, cabling and maintaining the device.
Page 31: Connection Illustration
ONNECT THE YSTEM Connection Illustration The connection diagram shows how to connect the Barricade.For SMC7908VoWBRA, please refer to the following diagram. Figure 2-5. SMC7908VoWBRA Installation Diagram 2-13...
Page 32 NSTALLATION For SMC7908VoWBRB, please refer to the following installation diagram. Figure 2-6. SMC7908VoWBRB Installation Diagram 2-14...
Page 33: Configuring Client Pc
HAPTER ONFIGURING LIENT After completing hardware setup by connecting all your network devices, you need to configure your computer to connect to the Barricade. See: “Windows 2000” on page 3-3 “Windows XP” on page 3-6 “Configuring Your Macintosh Computer” on page 3-8 depending on your operating system.
Page 34: Tcp/Ip Configuration
ONFIGURING LIENT TCP/IP Configuration To access the Internet through the Barricade, you must configure the network settings of the computers on your LAN to use the same IP subnet as the Barricade. The default IP settings for the Barricade are: IP Address: 192.168.2.1 Subnet Mask: 255.255.255.0 Note: These settings can be changed to fit your network requirements,...
Page 35: Windows 2000
2000 INDOWS Windows 2000 1. On the Windows desktop, click Start/Settings/Network and Dial-Up Connections. 2. Click the icon that corresponds to the connection to your Barricade. 3. The connection status screen will open. Click Properties. 4. Double-click Internet Protocol (TCP/IP). 5.
Page 36: Disable Http Proxy
ONFIGURING LIENT Disable HTTP Proxy You need to verify that the “HTTP Proxy” feature of your web browser is disabled. This is so that your browser can view the Barricade’s HTML configuration pages. See page 3-6 for details. Obtain IP Settings from Your Barricade Now that you have configured your computer to connect to your Barricade, it needs to obtain new network settings.
Page 37 2000 INDOWS 3. Type “IPCONFIG /RENEW” and press the ENTER key. Verify that your IP Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.2.1. These values confirm that your ADSL Router is functioning. 4. Type “EXIT” and press the ENTER key to close the Command Prompt window.
Page 38: Windows Xp
ONFIGURING LIENT Windows XP 1. On the Windows desktop, click Start/Control Panel. 2. In the Control Panel window, click Network and Internet Connections. 3. The Network Connections window will open. Double-click the connection for this device. 4. On the connection status screen, click Properties. 5.
Page 39: Obtain Ip Settings From Your Barricade
INDOWS Obtain IP Settings from Your Barricade Now that you have configured your computer to connect to your Barricade, it needs to obtain new network settings. By releasing old DHCP IP settings and renewing them with settings from your Barricade, you can verify that you have configured your computer correctly.
Page 40: Configuring Your Macintosh Computer
ONFIGURING LIENT Configuring Your Macintosh Computer You may find that the instructions here do not exactly match your operating system. This is because these steps and screenshots were created using Mac OS 10.2. Mac OS 7.x and above are similar, but may not be identical to Mac OS 10.2.
Page 41: Disable Http Proxy
ONFIGURING ACINTOSH OMPUTER 3. If “Using DHCP Server” is already selected in the Configure field, your computer is already configured for DHCP. If not, select this Option. 4. Your new settings are shown on the TCP/IP tab. Verify that your IP Address is now 192.168.2.xxx, your Subnet Mask is 255.255.255.0 and your Default Gateway is 192.168.2.1.
Page 42 ONFIGURING LIENT 3. Uncheck all check boxes and click OK. 3-10...
Page 43 HAPTER ONFIGURING THE ADSL R OICE OUTER After you have configured TCP/IP on a client computer, you can configure the Barricade using your web browser. To access the Barricade’s management interface, enter the default IP address of the Barricade in your web browser: http://192.168.2.1. Enter the default password: “smcadmin”, and click LOGIN.
Page 44: Configuring The Voice Adsl Router
ADSL R ONFIGURING THE OICE OUTER Navigating the Management Interface The first screen of the web management is Country Selection. You need to select your country before accessing the management interface.
Page 45: Making Configuration Changes
AVIGATING THE ANAGEMENT NTERFACE The Barricade’s management interface consists of a Setup Wizard and an Advanced Setup section. Setup Wizard: Use the Setup Wizard if you want to quickly set up the Barricade. Go to “SETUP WIZARD” on page 4-4. Advanced Setup: Advanced Setup supports more advanced functions like VoIP, Firewall, IP and MAC address filtering, virtual server setup, virtual DMZ host, as well as other functions.
Page 46: Setup Wizard
Wireless Mode This device supports both 11g and 11b wireless networks. Make your selection depending on the type of wireless network that you have. SMC recommend using “Mixed (11b+11g)” to provide compatibility with both 11b and 11g wireless clients. Channel The radio channel used by the wireless router and its clients to communicate with each other.
Page 47: Parameter Setting
ETUP IZARD Parameter Setting Select your Country and Internet Service Provider. This will automatically configure the Barricade with the correct Protocol, Encapsulation and VPI/VCI settings for your ISP. If your Country or Internet Service Provider is not listed in this screen, you will need to manually enter settings.
Page 48: Confirm
ADSL R ONFIGURING THE OICE OUTER Confirm The Confirm screen shows a summary of the configuration parameters. Check ADSL operation mode (WAN), Network Layer Parameters (WAN) and ISP parameters are correct. Parameter Description ADSL Operation Mode (WAN) The name of the ISP you have selected from list. Protocol The WAN protocol of your ISP.
Page 49 ETUP IZARD Parameter Description DNS Server The IP address of the DNS server. If the DNS address field was left blank in previous steps the address will be displayed as 0.0.0.0. ISP Parameters Username The ISP assigned user name. Password The password (hidden).
Page 50: Parameter Setting - Country Or Isp Not Listed
ADSL R ONFIGURING THE OICE OUTER Parameter Setting - Country or ISP Not Listed If your Country or Internet Service Provider is not listed, select Others. This will allow you to manually configure your ISP settings. For manual configuration you will need to know the Protocol, DNS Server, Encapsulation and VPI/VCI settings used by your ISP.
Page 51 ETUP IZARD PPPoE Parameter Description VPI/VCI Enter the Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI) supplied by your ISP. Encapsulation Select the encapsulation used by ISP from the drop down list. Username Enter user name provided by your ISP. Password Enter password provided by your ISP.
Page 52 ADSL R ONFIGURING THE OICE OUTER PPPoA Parameter Description VPI/VCI Enter the Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI) supplied by your ISP. Encapsulation Select the encapsulation used by ISP from the drop down list. Username Enter user name provided by your ISP. Password Enter password provided by your ISP.
Page 53 ETUP IZARD 1483 Bridging (DHCP) Parameter Description DNS Server Enter the DNS Server IP address provided by your ISP. If your ISP has not provided you with a DNS address, leave this field blank. The Barricade will automatically obtain the DNS address from your ISP.
Page 54 ADSL R ONFIGURING THE OICE OUTER 1483 Bridging (Static) Parameter Description IP Address Enter your ISP supplied static IP address here Subnet Mask Enter the subnet mask address provided by your ISP. Default Gateway Enter the gateway address provided by your ISP. DNS Server Enter the DNS Server IP address provided by your ISP.
Page 55 ETUP IZARD 1483 Routing Parameter Description IP Address Enter the IP address provided by your ISP. Subnet Mask Enter the subnet mask address provided by your ISP. Default Gateway Enter the gateway address provided by your ISP. DNS Server Enter the DNS Server IP address provided by your ISP. VPI/VCI Enter the Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI) supplied by your ISP.
Page 56 ADSL R ONFIGURING THE OICE OUTER Bridging Enter the Bridging settings provided by your ISP. Parameter Description Management IP Address Management IP address of the Barricade (Default:192.168.2.1). When configured in "Bridging" mode you will be able to manage the Barricade using this IP address. VPI/VCI Enter the Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI) supplied by your ISP.
Page 57: Advanced Setup
DVANCED ETUP Advanced Setup The left-hand side displays the main menu and the right-hand side shows descriptive information. The advanced management interface contains 16 main menu items as described in the following table. Menu Description System Sets the local time zone, the password for administrator access, and the IP address of a PC that will be allowed to manage the Barricade remotely.
Page 58 ADSL R ONFIGURING THE OICE OUTER Menu Description SNMP Community string and trap server settings. ADSL Sets the ADSL operation type and shows the ADSL status. VoIP Configures VoIP settings for the VoIP function, and view VoIP Status and Call logs. UPnP Enable/disable the Universal Plug and Play function.
Page 59: System
DVANCED ETUP SYSTEM Time Settings Select your local time zone from the drop down list. This information is used for log entries and client filtering. For accurate timing of log entries and system events, you need to set the time zone. Select your time zone from the drop down list. If daylight savings is used in your area, check the box to enable the function, and select the start/end dates.
Page 60 ADSL R ONFIGURING THE OICE OUTER Password Settings Use this screen to change the password for accessing the management interface. Passwords can contain from 3~12 alphanumeric characters and are case sensitive. Note: If you lost the password, or you cannot gain access to the user interface, press the blue reset button on the rear panel, holding it down for at least 10 seconds to restore the factory defaults.
Page 61 DVANCED ETUP Remote Management By default, management access is only available to users on your local network. However, you can also manage the Barricade from a remote host by entering the IP address of a remote computer on this screen. Check the Enabled check box, and enter the IP address of the Host Address and click Save Settings.
Page 62: Wan
ADSL R ONFIGURING THE OICE OUTER Specify the WAN connection parameters provided by your Internet Service Provider (ISP). The Barricade supports the following modes: • ATM PVC • Clone MAC • 4-20...
Page 63 DVANCED ETUP ATM PVC To configure your Internet Connection settings, select ATM PVC, then VC1. Click the VC to set the detailed parameters. Note: The Barricade can support up to 8 Virtual Circuits (VC's). Multiple VC's, in general, are only used in the case of Triple Play (Internet/Voice/Video) services .
Page 64 ADSL R ONFIGURING THE OICE OUTER ATM Interface 1483 Bridging Enter the settings provided by your ISP. In Bridging mode the Barricade will act as a Bridge passing the IP addressing directly to the attached client Parameter Description VPI/VCI Data flows are broken up into fixed length cells, each of which contains a Virtual Path Identifier (VPI) that identifies the path between two nodes, and a Virtual Circuit Identifier (VCI) that identifies...
Page 65 DVANCED ETUP Parameter Description QoS Class ATM QoS classes including CBR, UBR and VBR PCR/SCR/MBS QoS Parameters - PCR (Peak Cell Rate), SCR (Sustainable Cell Rate) and MBS (Maximum Burst Size) are configurable. PPPoA Parameter Description VPI/VCI Enter the Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI) supplied by your ISP.
Page 66 ADSL R ONFIGURING THE OICE OUTER Parameter Description Idle Time (Minute) Enter the maximum idle time for the Internet connection. After this time has been exceeded the connection will be terminated. Username Enter user name. Password Enter password. Confirm Password Confirm password Leave the Maximum Transmission Unit (MTU) at the default value (1500) unless you have a...
Page 67 DVANCED ETUP PPPoE Parameter Description IP Address Enter the IP address provided by your ISP. Subnet Mask Enter the subnet mask address provided by your ISP. VPI/VCI Enter the Virtual Path Identifier (VPI) and Virtual Circuit Identifier (VCI) supplied by your ISP. Encapsulation Select the encapsulation used by ISP from the drop down list.
Page 68 ADSL R ONFIGURING THE OICE OUTER Parameter Description Confirm Password Confirm password Leave the Maximum Transmission Unit (MTU) at the default value (1500) unless you have a particular reason to change it. MAC Encapsulated Routing Parameter Description IP Address Enter the IP address provided by your ISP. Subnet Mask Enter the subnet mask address provided by your ISP.
Page 69 DVANCED ETUP Clone MAC Address Some ISPs require you to register your MAC address with them. If this is the case, and you have previously registered the MAC address of another device, the MAC address of the Barricade must be changed to the MAC address that you have registered with your ISP.
Page 70 A Domain Name Server (DNS) is an index of IP addresses and Web addresses. If you type a Web address into your browser, such as www.smc.com, a DNS server will find that name in its index and find the matching IP address: xxx.xxx.xxx.xxx. Most ISPs provide a DNS server for speed and convenience.
Page 71: Lan
DVANCED ETUP The LAN settings menu allows you to change the default IP address of the Barricade, modify the DHCP server settings and create VLAN's. Parameter Description LAN IP IP Address The IP address of the Barricade. IP Subnet Mask The subnet mask of the Barricade. DHCP Server This option allows you to enable or disable the DHCP server function.
Page 72 ADSL R ONFIGURING THE OICE OUTER Parameter Description Lease Time Allows you to select a pre-defined lease time for IP addresses assigned using DHCP. For home networks this may be set to Forever, which means there is no time limit on the IP address lease.
Page 73 DVANCED ETUP VLAN Profile Configure the VLAN settings in this screen. • Description: Enter a description for the VLAN group, for example: Admin PC's • IP Address: Enter IP address for the VLAN. • Subnet Mask: Enter Subnet Mask address for the VLAN. •...
Page 74: Wireless
ADSL R ONFIGURING THE OICE OUTER WIRELESS The Barricade also operates as a wireless access point, allowing wireless computers to communicate with each other. To configure this function, all you need to do is enable the wireless function, define the radio channel, the SSID, and the security options.
Page 75 Wireless Mode This device supports both 11g and 11b wireless networks. Make your selection depending on the type of wireless network that you have. SMC recommend using "Mixed (11b+11g)" to provide compatibility with both 11b and 11g wireless clients. Channel The radio channel used by the wireless router and its clients to communicate with each other.
Page 76 ADSL R ONFIGURING THE OICE OUTER Access Control Using the Access Control functionality, you can restrict access based on MAC address. Each PC has a unique identifier known as a Medium Access Control (MAC) address. With MAC filtering enabled, the computers whose MAC address you have listed in the filtering table will be able to connect (or will be denied access) to the Barricade.
Page 77 DVANCED ETUP Security To make your wireless network safe, you should turn on the security function. The Barricade supports the following security mechanism: • WPA/WPA2 • WPA2 Only • 4-35...
Page 78 ADSL R ONFIGURING THE OICE OUTER WPA/WPA2 Wi-Fi Protected Access (WPA) combines temporal key integrity protocol (TKIP) and 802.1X mechanisms. It provides dynamic key encryption and 802.1X authentication service. Wi-Fi Protected Access 2 (WPA2) is a product certification that is available through the Wi-Fi Alliance.
Page 79 DVANCED ETUP WPA2 Only WPA2 is a product certification that is available through the Wi-Fi Alliance. WPA2 certifies that wireless equipment is compatible with the IEEE 802.11i standard. The WPA2 product certification formally replaces Wired Equivalent Privacy (WEP) and the other security features of the original IEEE 802.11 standard.
Page 80 ADSL R ONFIGURING THE OICE OUTER 802.1X If 802.1X is used in your network, then you should enable this function for the Barricade. Parameter Description Authentication Choose 802.1X authentication option. Session Idle Defines a maximum period of time for which the connection is timeout maintained during inactivity.
Page 81 DVANCED ETUP If you want to use WEP to protect your wireless network, you need to set the same parameters for the Barricade and all your wireless clients. Parameter Description WEP Mode Select 64 bit or 128 bit key to use for encryption. Key Entry Method Select Hex or ASCII to use for encryption key.
Page 82 ADSL R ONFIGURING THE OICE OUTER Note: WEP protects data transmitted between wireless nodes, but does not protect any transmissions over your wired network or over the Internet. The Wireless Distribution System (WDS) provides a means to extend the range of a Wireless Local Area Network (WLAN). WDS allows an Access Point (AP) to establish a direct link to other APs and to allows stations to roam freely within the area covered by the WDS.
Page 83: Nat
DVANCED ETUP Network Address Translation allows multiple users to access the Internet sharing one public IP. 4-41...
Page 84 ADSL R ONFIGURING THE OICE OUTER Address Mapping Allows one or more public IP addresses to be shared by multiple internal users. This also hides the internal network for increased privacy and security. Enter the Public IP address you wish to share into the Global IP field.
Page 85 DVANCED ETUP Virtual Server If you configure the Barricade as a virtual server, remote users accessing services such as web or FTP at your local site via public IP addresses can be automatically redirected to local servers configured with private IP addresses.
Page 86 ADSL R ONFIGURING THE OICE OUTER Special Application Some applications require multiple connections, such as Internet gaming, video-conferencing, and Internet telephony. These applications may not work when Network Address Translation (NAT) is enabled. If you need to run applications that require multiple connections, use these screens to specify the additional public ports to be opened for each application.
Page 87 DVANCED ETUP NAT Mapping Table This screen displays the current NAPT (Network Address Port Translation) address mappings. 4-45...
Page 88: Route
ADSL R ONFIGURING THE OICE OUTER ROUTE These screens define routing related parameters, including static routes and RIP (Routing Information Protocol) parameters. Static Route Parameter Description Index Check the box of the route you wish to delete or modify. Network Address Enter the IP address of the remote computer for which to set a static route.
Page 89 DVANCED ETUP Parameter Description General RIP Parameters RIP mode Globally enables or disables RIP. Auto summary If Auto summary is disabled, then RIP packets will include sub-network information from all sub- networks connected to the router. If enabled, this sub-network information will be summarized to one piece of information covering all sub- networks.
Page 90 ADSL R ONFIGURING THE OICE OUTER Parameter Description Poison Reverse A method for preventing loops that would cause endless retransmission of data traffic. Authentication Required • None: No authentication. • Password: A password authentication key is included in the packet. If this does not match what is expected, the packet will be discarded.
Page 91 DVANCED ETUP Routing Table Parameter Description Flags Indicates the route status: C = Direct connection on the same subnet. S = Static route. R = RIP (Routing Information Protocol) assigned route. I = ICMP (Internet Control Message Protocol) Redirect route. Network Destination IP address.
Page 92: Firewall
ADSL R ONFIGURING THE OICE OUTER FIREWALL The Barricade Router’s firewall inspects packets at the application layer, maintains TCP and UDP session information including time-outs and the number of active sessions, and provides the ability to detect and prevent certain types of network attacks. Network attacks that deny access to a network device are called Denial-of-Service (DoS) attacks.
Page 93 DVANCED ETUP Access Control Access Control allows users to define the outgoing traffic permitted or not-permitted through the WAN interface. The default is to permit all outgoing traffic. The following items are on the Access Control screen: Parameter Description Enable Filtering Enable or Disable Access control function.
Page 94 ADSL R ONFIGURING THE OICE OUTER To create a new access control rule: 1. Click Add PC on the Access Control screen. The Access Control Add PC screen will appear. 2. Define the appropriate settings for client PC services. 3. Click OK and then click SAVE SETTINGS to save your settings. 4-52...
Page 95 DVANCED ETUP MAC Filter The MAC Filter allows you to define what client PC's can access the Internet. When enabled only the MAC addresses defined in the MAC Filtering table will have access to the Internet. All other client devices will be denied access.
Page 96 ADSL R ONFIGURING THE OICE OUTER URL Blocking The Barricade allows the user to block access to web sites by entering either a full URL address or just a keyword. This feature can be used to protect children from accessing violent or pornographic web sites. You can define up to 30 sites here.
Page 97 DVANCED ETUP Schedule Rule You may filter Internet access for local clients based on rules. Each access control rule may be activated at a scheduled time. Define the schedule on the Schedule Rule screen, and apply the rule on the Access Control screen. 4-55...
Page 98 ADSL R ONFIGURING THE OICE OUTER Follow these steps to add a schedule rule: 1. Click Add Schedule Rule on the Schedule Rule screen. The Edit Schedule Rule screen will appear. 2. Define the appropriate settings for a schedule rule. 3.
Page 99 DVANCED ETUP Intrusion Detection • Intrusion Detection Feature Stateful Packet Inspection (SPI) and Anti-DoS firewall protection (Default: Enabled) — The Intrusion Detection Feature of the Barricade Router limits access for incoming traffic at the WAN port. When the SPI feature is turned on, all incoming packets will be blocked except for those types marked in the Stateful Packet Inspection section.
Page 100 ADSL R ONFIGURING THE OICE OUTER 4-58...
Page 101 DVANCED ETUP • Stateful Packet Inspection This is called a “stateful” packet inspection because it examines the contents of the packet to determine the state of the communications; i.e., it ensures that the stated destination computer has previously requested the current communication.
Page 102 ADSL R ONFIGURING THE OICE OUTER • Connection Policy Enter the appropriate values for TCP/UDP sessions as described in the following table. Parameter Defaults Description Fragmentation 10 sec Configures the number of seconds that a packet half-open wait state structure remains active. When the timeout value expires, the router drops the unassembled packet, freeing that structure for use by another packet.
Page 103 DVANCED ETUP • DoS Criteria and Port Scan Criteria Set up DoS and port scan criteria in the spaces provided (as shown below). Parameter Defaults Description Total incomplete Defines the rate of new unestablished sessions TCP/UDP sessions sessions that will cause the software to start deleting HIGH half-open sessions.
Page 104 ADSL R ONFIGURING THE OICE OUTER If you have a client PC that cannot run an Internet application properly from behind the firewall, you can open the client up to unrestricted two- way Internet access. Enter the IP address of a DMZ (Demilitarized Zone) host on this screen.
Page 105: Snmp
DVANCED ETUP SNMP Use the SNMP configuration screen to display and modify parameters for the Simple Network Management Protocol (SNMP). Community A computer attached to the network, called a Network Management Station (NMS), can be used to access this information. Access rights to the agent are controlled by community strings.
Page 106 ADSL R ONFIGURING THE OICE OUTER Trap Specify the IP address of the NMS to notify when a significant event is detected by the agent. When a trap condition occurs, the SNMP agent sends an SNMP trap message to any NMS specified as a trap receiver. Parameter Description IP Address Traps are sent to this address when errors or specific events occur on...
Page 107: Adsl
DVANCED ETUP ADSL ADSL (Asymmetric Digital Subscriber Line) is designed to deliver more bandwidth downstream (from the central office to the customer site) than upstream. This section is used to configure the ADSL operation type and shows the ADSL status. ADSL Parameters This screen is designed for the engineer to test the ADSL loop condition.
Page 108 ADSL R ONFIGURING THE OICE OUTER ADSL Status The Status screen displays information on connection line status, data rate, operation data and defect indication, and statistics. The following items are included on this information screen: Parameter Description Status Line Status Shows the current status of the ADSL line connection.
Page 109 DVANCED ETUP Parameter Description Fast Path FEC There are two latency paths that may be used: fast and Correction interleaved. For either path, a forward error correction (FEC) scheme is employed to ensure higher data integrity. For maximum noise immunity, an interleaver may be used to supplement FEC.
Page 110: Voip (Smc7908Vowbra)
ADSL R ONFIGURING THE OICE OUTER VOIP (SMC7908VOWBRA) Voice over Internet Protocol (VoIP) is the routing of voice conversations over the Internet or any other IP-based network. The voice data flows over a general-purpose packet-switched network, instead of traditional dedicated, circuit-switched voice transmission lines. VoIP Account Configure your VoIP account settings on this screen.
Page 111 DVANCED ETUP • Select the account form the Account Profile drop-down menu. To set-up a second VoIP account, select Account 2. Up to 4 accounts can be configured. • Check the Activated check box to enable the account. If the box is unchecked the account is disabled.
Page 112 ADSL R ONFIGURING THE OICE OUTER • Input the SIP Domain, Realm, Proxy Address, Proxy Port, Registrar Address and Registrar Port. If your VoIP provider was listed and selected, these settings should already be configured. • Use the Up and Down buttons to change Codec priority. The preferred Codec goes at the top.
Page 113 DVANCED ETUP Parameter Description Support User-Agent Header Enable or disables user-agent header support. Enabling this feature includes user agent information in the packet, e.g., the caller's ID may be displayed. Support Out of Band DTMF Check this box to enable support for Out of Band Dual Tone Multi-Frequency (DTMF).
Page 114 ADSL R ONFIGURING THE OICE OUTER VoIP Extensions You can configure the Line and Phone port settings on this screen. Parameter Description Telephony Tone Country Setting Configures telephony tone set for the selected country. Extension Number Select Extension Number to assign to the phone.
Page 115 DVANCED ETUP Parameter Description For the following 4 items, check the box to enable the function: • Answer calls for all numbers Check this box to answer all incoming calls. • Call Waiting Call Waiting plays audible tone to notify the user that a second call is in waiting.
Page 116 ADSL R ONFIGURING THE OICE OUTER SIP Setting The following SIP related parameters are configurable. Parameter Description SIP Parameters SIP Listen Port This option allows you to change the default SIP Listen Port. The default setting is 5060. It is recommended to leave this value unchanged.
Page 117 DVANCED ETUP Port Advanced Setting There are 11 advanced functions that can be configured in this screen. • Volume Gain Control: Two modes are available. The fixed gain control means the device is supported to supply a constant level of amplification.
Page 118 ADSL R ONFIGURING THE OICE OUTER • PLC (Packet Loss Compensation): During the transmission of a series of packets, if one of them is lost, then the device will use the mathematical algorithm to calculate a value to make up the lost packet. This function is designed to make the voice conversation more smooth.
Page 119 DVANCED ETUP Parameter Description • Volume Gain It is recommended leaving these four settings at the Control default value. Changing the settings may affect the performance of VoIP and the voice quality. • Jitter Buffer Mode If you should need to change these settings, consult an •...
Page 120 ADSL R ONFIGURING THE OICE OUTER Dialing plans Dialing plans allow you to define the connection type used when a specified number is dialed. For example you may want numbers beginning “0800” to dial out over PSTN. Alternatively you may want numbers beginning “012”...
Page 121 DVANCED ETUP To set-up a dialing plan, take the following steps: 1. In the Phone number column enter a specific phone number, or the starting digits of a phone number that you want to create a dialing plan for. Example: If you enter "012" all phone numbers beginning "012" will dial out using the connection type defined.
Page 122 ADSL R ONFIGURING THE OICE OUTER Quick Dialing Plans This function allows you to configure up to 20 quick dialing plans. This is done by assigning a quick dial code for a specified phone number. • Quick Dial Code: Enter quick dial code in the range of 01 to 20. To call the phone number associated with the quick dial code you would need to dial *7[Quick Dial Code]# .
Page 123 DVANCED ETUP The following example shows how to set up a quick dialing plan for Frank who has the phone number 6194621719: 1. Select the vanity keypad style from the pull-down menu. 2. Enter the number "01" for the Quick Dial Code. 3.
Page 124 ADSL R ONFIGURING THE OICE OUTER VOIP Status and Call logs This page displays the VoIP registration status for accounts 1 - 4 and the call logs. Parameter Description Account SIP accounts 1 to 4. SIP URL Displays SIP URL for the corresponding account. Registration Displays SIP registration status for the corresponding account.
Page 125: Voip (Smc7908Vowbrb)
DVANCED ETUP VOIP (SMC7908VOWBRB) Voice over Internet Protocol (VoIP) is the routing of voice conversations over the Internet or any other IP-based network. The voice data flows over a general-purpose packet-switched network, instead of traditional dedicated, circuit-switched voice transmission lines. VoIP Account Configure your VoIP account settings on this screen.
Page 126 ADSL R ONFIGURING THE OICE OUTER • Select the account form the Account Profile drop-down menu. To set-up a second VoIP account, select Account 2. Up to 4 accounts can be configured. • Check the Activated check box to enable the account. If the box is unchecked the account is disabled.
Page 127 DVANCED ETUP • Input the SIP Domain, Realm, Proxy Address, Proxy Port, Registrar Address and Registrar Port. If your VoIP provider was listed and selected, these settings should already be configured. • Use the Up and Down buttons to change Codec priority. The preferred Codec goes at the top.
Page 128 ADSL R ONFIGURING THE OICE OUTER Parameter Description Support User-Agent Header Enable or disables user-agent header support. Enabling this feature includes user agent information in the packet, e.g., the caller's ID may be displayed. Support Out of Band DTMF Check this box to enable support for Out of Band Dual Tone Multi-Frequency (DTMF).
Page 129 DVANCED ETUP VoIP Extensions You can configure the Phone1 and Phone2 port settings on this screen. Parameter Description Extension Number Select Extension Number to assign to the phone. This should be your VoIP phone number. The extension number selected will be the default number used for making outgoing calls.
Page 130 ADSL R ONFIGURING THE OICE OUTER Parameter Description For the following 4 items, check the box to enable the function: • Answer calls for all numbers Check this box to answer all incoming calls. • Call Waiting Call Waiting plays audible tone to notify the user that a second call is in waiting.
Page 131 DVANCED ETUP SIP Setting The following SIP related parameters are configurable. To save changes click the SAVE SETTINGS button. Parameter Description SIP Parameters SIP Listen Port This option allows you to change the default SIP Listen Port. The default setting is 5060. It is recommended to leave this value unchanged.
Page 132 ADSL R ONFIGURING THE OICE OUTER Port Advanced Setting There are 10 advanced functions that can be configured in this screen for phone1/phone2. • Volume Gain Control: Two modes are available. The fixed gain control means the device is supported to supply a constant level of amplification.
Page 133 DVANCED ETUP • PLC (Packet Loss Compensation): During the transmission of a series of packets, if one of them is lost, then the device will use the mathematical algorithm to calculate a value to make up the lost packet. This function is designed to make the voice conversation more smooth.
Page 134 ADSL R ONFIGURING THE OICE OUTER Parameter Description • Volume Gain It is recommended leaving these four settings at the Control default value. Changing the settings may affect the performance of VoIP and the voice quality. • Jitter Buffer Mode If you should need to change these settings, consult an •...
Page 135 DVANCED ETUP VOIP Status and Call logs This page displays the VoIP registration status for accounts 1 - 4 and the call logs. Parameter Description Account SIP accounts 1 to 4. SIP URL Displays SIP URL for the corresponding account. Registration Displays SIP registration status for the corresponding account.
Page 136: Upnp
ADSL R ONFIGURING THE OICE OUTER UPNP The Universal Plug and Play architecture offers pervasive peer-to-peer network connectivity of PCs of all form factors, intelligent appliances, and wireless devices. UPnP enables seamless proximity network in addition to control and data transfer among networked devices in the office, home and everywhere within your network.
Page 137: Qos
DVANCED ETUP The QoS (Quality of Service) function allows you to differentiate VoIP traffic and provide it with high-priority forwarding service. In addition, you can specify the outgoing VC of VoIP packets to further guarantee the voice quality. Parameter Description Enable or disable QoS Check to enable or disable this function.
Page 138 ADSL R ONFIGURING THE OICE OUTER • Assured forwarding, defined in RFC 2597 • Expedited forwarding, defined in RFC 2598 Traffic Mapping Use this screen to classify traffic into Diffserv forwarding groups and outgoing VCs. 4-96...
Page 139 DVANCED ETUP Traffic Statistics This screen shows the WAN outbound traffic statistics of all the Diffserv forwarding groups in the last 12 hours. 4-97...
Page 140: Ddns
ADSL R ONFIGURING THE OICE OUTER DDNS Dynamic Domain Name Service (DDNS) provides users on the Internet with a method to tie their domain name to a computer or server. DDNS allows your domain name to follow your IP address automatically by having your DNS records changed when your IP address changes.
Page 141: File Server
DVANCED ETUP FILE SERVER The Barricade also functions as a file server. Parameter Description Enable or Disable File Check to enable or disable. Server function Server Name Enter the server name here. Server Description Define the type of function for the server. Group Name Enter the group name here.
Page 142: Tools
ADSL R ONFIGURING THE OICE OUTER TOOLS Use the Tools menu to backup the current configuration, restore a previously saved configuration, update firmware, and reset the Barricade. Ping Utility This tool allows you to test your network connection. You can specify a domain name or a valid IP address of the remote host for ping test.
Page 143 DVANCED ETUP Configuration Tools Choose a function and click Next. • Backup Router Configuration: this allows you to save the Barricade’s configuration to a file. • Restore from saved Configuration file: this function is used to restore the previously saved backup configuration file. •...
Page 144 Use this screen to update the firmware or user interface to the latest versions. 1. Download the upgrade file from the SMC web site first, and save it to your hard drive. 2. Then click Browse... to look for the downloaded file. Click BEGIN UPGRADE.
Page 145 DVANCED ETUP Reset Click REBOOT ROUTER to reset the Barricade. The reset will be complete when the power LED stops blinking. If you perform a reset from this screen, the configurations will not be changed back to the factory default settings. Note: If you use the Reset button on the back panel, the Barricade performs a power reset.
Page 146: Status
ADSL R ONFIGURING THE OICE OUTER STATUS The Status screen displays WAN/LAN connection status, firmware, and hardware version numbers, illegal attempts to access your network, as well as information on DHCP clients connected to your network. The security log may be saved to a file by clicking Save and choosing a location. Scroll down to view more information on the Status screen.
Page 147 DVANCED ETUP 4-105...
Page 148 ADSL R ONFIGURING THE OICE OUTER The following items are included on the Status screen: Parameter Description INTERNET Displays WAN connection type and status. Release Click on this button to disconnect from the WAN. Renew Click on this button to establish a connection to the WAN. GATEWAY Displays system IP settings, as well as DHCP Server and Firewall status.
Page 149: Finding The Mac Address Of A Network Card
INDING THE ADDRESS OF A ETWORK Finding the MAC address of a Network Card WINDOWS NT4/2000/XP Click Start/Programs/Command Prompt. Type “ipconfig /all” and press “ENTER”. The MAC address is listed as the “Physical Address.” MACINTOSH Click System Preferences/Network. The MAC address is listed as the “Ethernet Address” on the TCP/IP tab. LINUX Run the command “/sbin/ifconfig.”...
Page 150 ADSL R ONFIGURING THE OICE OUTER 4-108...
Page 151 PPENDIX ROUBLESHOOTING This section describes common problems you may encounter and possible solutions to them. The Barricade can be easily monitored through panel indicators to identify problems. Troubleshooting Chart Symptom Action LED Indicators Power LED is • Check connections between the Barricade, the external power supply, and the wall outlet.
Page 152: Troubleshooting
ROUBLESHOOTING Troubleshooting Chart Symptom Action LED Indicators Link LED is Off • Verify that the Barricade and attached device are powered on. • Be sure the cable is plugged into both the Barricade and the corresponding device. • Verify that the proper cable type is used and that its length does not exceed the specified limits.
Page 153 ROUBLESHOOTING Troubleshooting Chart Symptom Action Management Problems Cannot connect • Be sure to have configured the Barricade with a valid IP address, subnet mask, and default gateway. using the web browser • Check that you have a valid network connection to the Barricade and that the port you are using has not been disabled.
Page 154 ROUBLESHOOTING Troubleshooting Chart Symptom Action Wireless Problems A wireless PC • Make sure the wireless PC has the same SSID settings as the Barricade. See “Channel and SSID” on cannot associate page 4-33 with the Barricade. • You need to have the same security settings on the clients and the Barricade.
Page 155 PPENDIX ABLES Ethernet Cable Caution: DO NOT plug a phone jack connector into any RJ-45 port. Use only twisted-pair cables with RJ-45 connectors that conform with FCC standards. Specifications Cable Types and Specifications Cable Type Max. Length Connector 10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft) RJ-45 100BASE-TX Cat.
Page 156: Cables
ABLES Each wire pair must be attached to the RJ-45 connectors in a specific orientation. The following figure illustrates how the pins on an Ethernet RJ-45 connector are numbered. Be sure to hold the connectors in the same orientation when attaching the wires to the pins. Figure B-1.
Page 157: Ethernet Cable
THERNET ABLE Pin Assignments With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data. RJ-45 Pin Assignments Pin Number Assignment 1: The “+” and “-” signs represent the polarity of the wires that make up each wire pair.
Page 158 ABLES Crossover Wiring If the port on the attached device has straight-through wiring (MDI), use crossover cable. Crossover Cable Pin Assignments End 1 End 2 1 (Tx+) 3 (Rx+) 2 (Tx-) 6 (Rx-) 3 (Rx+) 1 (Tx+) 6 (Rx-) 2 (Tx-)
Page 159: Specifications
ADSL C ABLE ADSL Cable Use standard telephone cable to connect the RJ-11 telephone wall outlet to the RJ-45 ADSL port on the ADSL Router. Caution: Do not plug a phone jack connector into an RJ-45 port. Specifications Cable Types and Specifications Cable Type Connector...
Page 160 ABLES R1 T1 R1 T1 R2 R1 T1 R2 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 6x2 Jack 6x4 Jack 6x4 Jack T = Tip R = Ring Signal Name Wire Color Not used Line 2 Tip...
Page 161: Specifications
PPENDIX PECIFICATIONS Physical Characteristics Ports Four 10/100Mbps RJ-45 ports One ADSL RJ-11 port One Phone port One Line port ADSL Features Supports DMT line modulation Supports Annex A Full-Rate ADSL: up to 8 Mbps downstream, up to 1 Mbps upstream (G.992.1 &T1.413, Issue 2) and ADSL2 (G.992.3) and ADSl2+ (G.992.5) Supports G.Lite ADSL: up to 1.5 Mbps downstream, up to 512 Kbps upstream...
Page 162 PECIFICATIONS Network Ping Security Features Password protected configuration access User authentication (PAP/CHAP) with PPP Firewall NAT NAPT VPN pass through (IPSec-ESP Tunnel mode,L2TP, PPTP) LAN Features IEEE 802.1D (self-learning transparent Bridging) DHCP Server DNS Proxy Static Routing, RIPv1 and RIP VoIP Features Codec - G.711, G.723, G.729a, G.168 Modulation Type...
Page 163 PECIFICATIONS 2412~2484MHz (Ch1~Ch14) Operating Channels IEEE 802.11b compliant: 11 channels (US, Canada) 13 channels (ETSI) 2 Channels (Spain) 4 Channels (France) 14 channels (Japan) Operating Channels IEEE 802.11g compliant: 13 channels (US, Canada, Europe, Japan) RF Output Power Modulation Rate-Output Power (dBm) 802.11b - 1Mbps 16 802.11b - 2Mbps 16 802.11b - 5.5Mbps 16...
Page 164 PECIFICATIONS Modulation Rate-Receiver Sensitivity Typical (dBm) 802.11g - 6Mbps -88 802.11g - 9Mbps -87 802.11g - 12Mbps -84 802.11g - 18Mbps -82 802.11g - 24Mbps -79 802.11g - 36Mbps -75 802.11g - 48Mbps -68 802.11g - 54Mbps -68 Temperature: IEC 68-2-14 0 to 50 degrees C (Standard Operating) -40 to 70 degree C (Non-operation) Humidity...
