- Page 1 Player P3100, P3500, and P4300 Product Manual P3100 P3500 P4300...
-
Page 2: Table Of Contents
Amazon Alexa Voice Control Integration NV-P3100-xx 3-Zone Player (Ethernet) NV-P3500-xx 3-Zone Player (Ethernet - Prerequisites B&O ICE Power Amplification) Connecting Alexa to Your Legrand Nuvo Player NV-P4300-xx 3-Zone Player (Ethernet) Setup Additional Music Service Providers Supported Alexa Commands Setup and Installation Network Requirements... -
Page 3: Quick Links
What do all of the options on the settings menu do? What is the Nuvo Player Portfolio System? What is a zone? Where can I can I find more information on my Nuvo Player? How do I add a component to my system? The LED on my Player is flashing. -
Page 4: Overview
OVERVIEW Welcome to the Nuvo Player Portfolio Audio System! This system offers you the opportunity to enjoy your favorite music from any room of your home, at any time, with simplicity of operation. Imagine playing music from your personal library or easily streaming true, high-fidelity music from the Internet by touching a button on your Apple or Android Wi-Fi-enabled portable device. -
Page 5: Product Features
PRODUCT FEATURES NV-P3100-XX 3-ZONE PLAYER (ETHERNET) FRONT PANEL Item Name Description Standby LED Indicator Indicates if the player is on, in active mode, or in standby mode Zone 1 LED Indicator Indicates the status of Zone 1 Zone 2 LED Indicator Indicates the status of Zone 2 Zone 3 LED Indicator Indicates the status of Zone 3... -
Page 6: Nv-P3500-Xx 3-Zone Player (Ethernet - B&O Ice Power Amplification)
NV-P3500-XX 3-ZONE PLAYER (ETHERNET - B&O ICE POWER AMPLIFICATION) FRONT PANEL Item Name Description Power Button Toggles the power on and off. Used in the reset procedure for each zone Setup Buttons Setup button used in the initial system setup process. Used in the zone reset procedure Zone 3 USB** USB connection port for adding digital music files to the system music library. -
Page 7: Nv-P4300-Xx 3-Zone Player (Ethernet)
NV-P4300-XX 3-ZONE PLAYER (ETHERNET) FRONT PANEL Item Name Description Standby LED Indicator Indicates if the player is powered on Power Toggles the power on and off TFT Back-Lit Display Displays zone names, status, meta data, and networking information. Touch-capable for setup Zone 3 USB connection port for adding digital music files to the system music library. -
Page 8: Setup And Installation
SETUP AND INSTALLATION NETWORK REQUIREMENTS A live Internet connection is necessary for initial setup of your Nuvo Player Portfolio System. For wired Ethernet connectivity, a minimum 100 MB wired network is necessary for proper communication. Wireless-compatible devices use dual band 802.11n wireless communication. To ensure that all components are compatible and communicating correctly, it is strongly suggested that network routers using the older 802.11g protocol be upgraded to support... -
Page 9: Setting Up Your System Using The App
Confirm that the component is powered on and has an Ethernet connection to the same network as the mobile device that will be running the Nuvo Player app. Download the Nuvo Player app to a mobile device connected to your home network. The app is available on the App Store or on Google Play. - Page 10 Once a registration option is chosen, the screen displays Setup Complete! (See Figure 12). Select Finish and the app jumps to the HOME screen. NOTE: A software update may be necessary for any Nuvo components. If prompted with an update, select Continue to update the firmware. Player Portfolio Audio System | Product Manual...
-
Page 11: Using The Nuvo Player App
USING THE NUVO PLAYER APP The Nuvo Player app offers wireless system control from any Wi-Fi-enabled mobile device. The Nuvo Player app is available on the App Store or on Google Play. Both versions offer the same look and control options. When used with tablets, the display is optimized for a view of the complete system’s operation on one screen. -
Page 12: Direct Stream
To do this, connect a 3.5 mm stereo audio cable from the audio output on the compatible analog music device into the line in port on the back of the Nuvo component “Product Features”... -
Page 13: Media Servers
MEDIA SERVERS This music streaming service is for DLNA/UPnP media servers on a local network. It is an alternative option to a Windows share when users have a local library to share. Devices include NAS drives, Windows machines, Mac OS machines with additional software, etc. -
Page 14: The Settings Menu
ADD A NUVO COMPONENT When adding a component to an existing system, navigate to the SETTINGS menu, then select Add a Nuvo Component (See Figure 26). Choose your component (See Figure 27), then follow the steps in “New System Setup” on page 9. -
Page 15: Keypads
Figure 28 Figure 29 Figure 30 Figure 31 The ZONE SETTINGS screen contains simple slider adjustments or on/off choices that control the sound for the selected zone. • Bass, Treble, and Balance: These three sliders offer individual control of each sound setting. •... -
Page 16: This App
THIS APP When This App is selected, a page appears with the app’s current software version information, a Reset button that disassociates the app from the system, and scanning options (See Figure 34 – Figure 38). Figure 34 Figure 35 Figure 36 Figure 37 Figure 38... -
Page 17: Music Services
MUSIC SERVICES When Music Services is selected (See Figure 43), the active streaming music services on the system display (See Figure 44) along with a button for adding new services (See Figure 45). Most services require an online subscription account. The associated user name and password for the music service account must be added under this menu selection for the service to be active on the system. -
Page 18: International
Figure 54 Figure 55 Figure 56 HELP The Help option (See Figure 57), displays links to contact Nuvo directly, to reference information on various system components, or to report a problem (See Figure 58–Figure 61). Figure 57 Figure 58 Figure 59... -
Page 19: The Music Share Software
THE MUSIC SHARE SOFTWARE The Music Share Software allows music content from shared network locations and libraries, to be streamed from any zone in the sys tem. From your computer, go to http://www.legrand.us/resources-and-downloads/software-downloads to download the music share software. Follow the prompts for installing the software (See Figure 62). Figure 62 The software connects to the network and displays a blank music share page. - Page 20 You can also choose to share a specific folder or drive on the network. The A specific folder... choice opens a browsing window (See Figure 66). From there you can choose a shared folder with music content or a drive that is shared with the network.
-
Page 21: Troubleshooting
FRONT PANEL LEDS An important indicator of each Nuvo component’s operation is the LED light on the front panel. The color of the LED, and the solid or flashing state, provides a visual reference for the status of operation. Refer to the chart for an explanation of the functions and LED status (See Figure 68). - Page 22 Verify that the mobile device running the app is connected to the correct WLAN (Wireless Local Area Network) Wi-Fi SSID. If using a WAP (Wireless Access Point) make sure it is connected to the same LAN (Local Area Network) router of the component. Verify the router and WAPs are compatible with the component at: http://www.legrand.us/onq/router- compatibility.aspx#.Vo_Zivi-2es.
-
Page 23: Amazon Alexa Voice Control Integration
NOTE: Amazon, Echo, Alexa, and all related logos are trademarks of Amazon.com, Inc. or its affiliates. PREREQUISITES Enabling voice control of your Legrand Nuvo Player through devices with Amazon Alexa requires the following: • A device with Amazon Alexa, such as Amazon Echo, connected to your home network •... - Page 24 Ensure you are in the Select Skills & Games. Devices section of the Alexa app and then click the Menu icon. Search Skills for the Nuvo Select Enable To Use. Player skill, then select the correct application. Player Portfolio Audio System | Product Manual...
- Page 25 Your Samsung ARTIK Cloud Continue. account will link with your Alexa account. This completes your Nuvo Player Alexa skill setup. Close the confirmation Select Discover Devices. window. Alexa begins discovery of After discovery is complete,...
-
Page 26: Setup Additional Music Service Providers
SETUP ADDITIONAL MUSIC SERVICE PROVIDERS To play selections from Music Service Providers (MSPs) other than Amazon Music, link your account for the MSP with Alexa. Each service has a different setup. IMPORTANT: Use the same account information that you use for your MSP app when linking to Alexa using the ARTIK Cloud account. If you do not, you will not be able to access the features unique to your MSP account, such as playlists IHEARTRADIO No account setup is required. -
Page 27: Specifications
English, French, German, Italian, Portuguese, Spanish Rated Output Power (8 ohm) 40 W (20 W x 2) Two Channels Driven 20 Hz–20 KHz @ 0.5% distortion Nuvo reserves the right to change specifications without notice. Rated Distortion (1/2 Power) 0.20% Speaker Impedance 8 Ohms Frequency Response +/-0.5 dB... -
Page 28: Nv-P3500-Xx Amplifier
English, French, German, Italian, Portuguese, Spanish 6 Ohm 150 W (75 w x 2) 8 Ohm 100 W (50 W x2) Nuvo reserves the right to change specifications without notice. Total Harmonic Distortion (1/2 Power) 100 Hz 0.003% 1 KHz 0.003% 6.67 KHz 0.020%... -
Page 29: Nv-P4300-Xx Amplifier
Languages Supported Damping Factor English, French, German, Italian, Portuguese, Spanish Signal-to-Noise Ratio, 104 dB Rated Output: 4 Ohms Nuvo reserves the right to change specifications without notice. Line Output (Digital) Sample Rates 44.1 KHz–192KHz Bit Rate 24 B Signal-to-Noise Ratio, 120 dBA... -
Page 30: Regulatory Compliance
Ce document contient des informations importantes sur la sécurité et la conformité réglementaire du produit. Pour plus de détails concernant les instructions d’utilisation et d’installation, veuillez consulter notre site Web à l’adresse http://www.legrand.us/nuvo. aspx. Pour nous joindre : Soutien technique :... - Page 31 (That is, make certain the audio device and the television or radio are on circuits controlled by different circuit breakers or fuses.) If necessary, consult Nuvo Technical Support, refer to the service and support information available for your Nuvo product, or consult an experienced radio/television technician for additional suggestions.
- Page 32 However, this device should be operated with a minimum distance of at least 20 cm between the Nuvo Player antennas and a person's body, and must not be collocated or operated in conjunction with any other antenna or transmitter subject to the conditions of the FCC Grant.
- Page 33 Europe - EU Declaration of Conformity A copy of the EU Declaration of Conformity is available at: www.legrand.us/aboutus/sustainability/high-performance-buildings/eco-iconography.aspx This equipment can be used in the following countries: Player Portfolio Audio System | Product Manual...
- Page 34 Important Safety Information (English) Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this product near water or moisture or let objects or liquids enter the product. Install according to manufacturer's instructions. Clean only with a dry, soft cloth. Do not block the ventilation openings.
- Page 35 Wichtige Sicherheit Auskunft (Deutsch) Lesen Sie diese Anweisungen. Behalten Sie diese Anweisungen. Beachten Sie alle Warnungen. Folgen Sie allen Anweisungen. Verwenden Sie dieses Produkt nicht in Wassernähe oder bei Feuchtigkeit und vermeiden Sie das Eindringen von Gegenständen oder Flüssigkeiten in das Produkt. lnstallieren Sie immer nach den Anweisungen des Herstellers.
- Page 36 Informações importantes de segurança (Português) Leia estas instruções. Guarde estas instruções. Tenha em atenção todos os avisos. Siga todas as instruções. Não utilize este produto junto de água ou humidade, nem deixe que os objetos ou líquidos entrem em contacto com o produto. Instale de acordo com as instruções do fabricante.
- Page 37 Disposal and Recycling Information This symbol indicates that your product must be disposed of properly according to local laws and regulations. When your product reaches its end of life, contact Nuvo Technologies or your local authorities to learn about recycling options.
- Page 38 3015 Kustom Drive Hebron, KY 41048 United States 844.334.8044 www.legrand.us/nuvo...
