Belkin Range Extender/ Access Point User Manual page 20

Using the Web-Based Advanced User Interface
(2) Home Button
The home button is available in every page of the UI. Pressing this
button will take you back to the home page.
(3) Help Button
The "Help" button gives you access to the WURE's help pages. Help
is also available on many pages by clicking "more info" next to certain
sections of each page.
(4) Login/Logout Button
This button enables you to log in and out of the WURE with the press
of one button. When you are logged in, this button will change to
read "Logout". Logging into the WURE will take you to a separate
login page where you must enter a password. When you are logged
in, you can make changes to the settings. When you are finished
making changes, you can log out by clicking the "Logout" button. For
more information about logging into the WURE, see the section called
"Logging into the WURE".
(5) Version Info
Shows the firmware version, boot-code version, hardware version,
and serial number of the WURE.
(6) LAN Settings
Shows you the settings of the Local Area Network (LAN) side of the
WURE. Changes can be made to the settings by clicking on any one
of the links (IP Address, Subnet Mask) or by clicking the "LAN" Quick
Navigation link on the left side of the screen.
(7) Features
Shows the status of the WURE's wireless setting. Changes can be
made to the settings by clicking on any one of the links or by clicking
the "Quick Navigation" links on the left side of the screen.
Using your Internet browser, you can access the WURE's Web-Based
Advanced User Interface. In your browser, type "192.168.2.254" (do
not type in anything else such as "http://" or "www"). Then press the
"Enter" key.
17 17
1
2
3
4
5
6
7
