Summary of Contents for Belkin 8820AU00394
- Page 1 Share wireleSS MODeM-rOuter User Manual F7D3402au 8820au00394...
-
Page 2: Table Of Contents
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Belkin International, Inc ., Limited 3-Year Product Warranty . . . . . . . . . 29 Regulatory Information . -
Page 3: What's In The Box
ADSL cable (attached to router) Power supply (attached to router) Network information card (attached to router) Belkin Setup CD with User Manual Initial setup Where to Place Your Router For the best results, place the Router in an open location away from large metal objects and magnets such as those found in speakers . - Page 4 GeTTInG sTaRTeD How to set It Up...
-
Page 5: Getting Started
3 . Put the CD into your computer . If the CD doesn’t open automatically, please browse to your CD drive and double-click on the Belkin Setup CD icon . Setup 4 . Click the Setup icon on the CD menu . - Page 6 GeTTInG sTaRTeD 5 . After a brief installation, the setup software will ask you for the network name and password from the network information card that is attached to your Router . Store the card under the base of your Router for future reference .
- Page 7 . This may take a few minutes to complete . Once finished, a “Success” message will appear indicating that you are connected to the Internet via your new Belkin Router . During setup you may be asked for additional information .
-
Page 8: Advanced Tools & Settings
GeTTInG sTaRTeD advanced Tools & settings After the initial setup is complete, you have the option to change settings like your network name, security type, and password . To make these changes and others, click on the Advanced Tools icon at the CD Setup menu and select one of the following settings that you would like to change: network name &... -
Page 9: The Belkin Router Manager
To access the Router settings, click on the icon and select from the menu that appears . The status of your Router is shown by the Belkin Router Manager icon, which closely mimics the light on the front of the Router . -
Page 10: Manual Setup Using Your Browser
GeTTInG sTaRTeD Manual setup Using Your browser In your browser, type “http://router” (you do not need to type in anything else such as “www”) . Then press the Enter key . If you’re still having trouble running the manual setup option, type “192 . -
Page 11: Adding Computers To Your Network
. This may take a few minutes to complete . Once finished, a “Success” message will appear indicating that you are connected to the Internet via your new Belkin Router . note: The setup software runs only on Windows and Mac OS X systems . - Page 12 1 . Locate the wireless-network-connections option on your computer or wireless device . 2 . Select your Belkin Router from the list of available networks . You can identify your Belkin Router by locating the network name (SSID) from the card located underneath the foot of your Router .
-
Page 13: Adding Usb Devices
GeTTInG sTaRTeD adding Usb Devices... - Page 14 . You can manually check the status of your shared drive by visiting the USB Print and Storage Manager, found under the Belkin Router Manager icon displayed in your system tray (Windows) or menu bar (Mac) .
- Page 15 Router . When the light above the USB port is lit, your device is available to computers on your network . Computers running the Belkin USB Print and Storage Manager will be able to make use of the shared device by visiting the USB Print and Storage Manager, found under the Belkin Router Manager icon displayed in your system tray (Windows) or menu bar (Mac) .
-
Page 16: Bundled Software
Router’s USB port and shared across your network . USB Print and Storage Manager is found in the Belkin Router Manager icon displayed in your system tray (Windows) or menu bar (Mac) . -
Page 17: Additional Capabilities
GeTTInG sTaRTeD additional Capabilities Guest access You can allow guests to use your Internet connection without joining your personal network . The network name and password for the guest network is located on the network information card found under the foot of your Router . A person using your guest network will be able to join without a password, but will be shown a login page when they attempt to surf the Web . -
Page 18: Getting To Know Your Router
GeTTInG TO KnOW YOUR ROUTeR front Panel a) Router status light Your Router’s status is shown by the light on the front . Off: The Router is not plugged into a power source . blinking Green: The Router is starting up . solid Green: The Router is connected to the Internet . -
Page 19: Back Panel
GeTTInG TO KnOW YOUR ROUTeR back Panel a) aDsl Connector Connect your Router to your ADSL connection . b) Wired (lan) Connectors Connect computers and other wired network devices to these ports using Ethernet cables . C) Usb Port USB printers, disks, and other USB devices plugged into this port will be shared on your network . -
Page 20: Technical Details
300Mbps across your network . naT IP address sharing To save you the cost of adding IP addresses per computer in your house, your Belkin Router uses Network Address Translation (NAT) technology, allowing you to share a single IP address across your network . -
Page 21: System Requirements
TeCHnICal DeTaIls system Requirements Modem Router Broadband ADSL Internet connection with RJ11 (telephone) connection At least one computer with an installed network interface adapter TCP/IP networking protocol installed on each computer RJ11 ADSL telephone cable Internet browser setup software A computer running Windows XP SP2 or higher, ®... -
Page 22: Troubleshooting, Support, And Warranty
Troubleshooting The setup CD does not automatically start . If Belkin Setup does not run when you insert the CD-ROM, your computer may not be configured to open CDs automatically . If Belkin Setup does not appear within 15 seconds, browse to your CD-ROM drive and open the “Belkin Setup”... - Page 23 TROUblesHOOTInG, sUPPORT, anD WaRRanTY belkin setup cannot connect my Router to the Internet . If Belkin Setup is not able to connect the Router to the Internet, please check the following items: 1 . Use the troubleshooting suggestions within Belkin Setup .
- Page 24 TROUblesHOOTInG, sUPPORT, anD WaRRanTY I can’t connect to the Internet wirelessly . If the light on the front of the Router is solid green, then your Router is connected to the Internet . You may not be connected to the Router’s wireless network . Please refer to “Adding Computers to Your Network”...
- Page 25 TROUblesHOOTInG, sUPPORT, anD WaRRanTY My wireless network per formance is slow, inconsistent, suffers from weak signal, or I’m having difficulty maintaining a VPn connection . Wireless technology is radio-based, which means connectivity and the throughput performance between devices decreases when the distance between devices increases . Other factors that will cause signal degradation (metal is generally the worst culprit) are obstructions such as walls and metal appliances .
- Page 26 TROUblesHOOTInG, sUPPORT, anD WaRRanTY I’ve installed this new Router and some of my network clients (computers, game consoles, etc .) are now unable to connect . Your new Router came pre-configured with a network name and password, found printed on an attached card . All clients must use this network name and password to connect wirelessly to your Router .
- Page 27 TROUblesHOOTInG, sUPPORT, anD WaRRanTY 5 . Click “Apply Changes” to finish . Your wireless connection is now encrypted . Each computer using your wireless network will need to use the new key . note: If you are configuring the Router over a wireless connection, you will have to re-connect to the Router after changing any security settings .
- Page 28 TROUblesHOOTInG, sUPPORT, anD WaRRanTY 5 . Click “Apply Changes” to finish . Your wireless activity is now encrypted . Each computer using your wireless network will need to use the new key . note: If you are configuring the Router over a wireless connection, you will have to re-connect to the Router after changing any security settings .
- Page 29 . Please check that the driver is installed . 3 . The printer may not be set to auto-connect . Via the Belkin Router Manager, open the USB Print and Storage Center . Check that the printer appears in the list of available devices .
-
Page 30: Technical Support
TROUblesHOOTInG, sUPPORT, anD WaRRanTY Technical support http://www .belkin .com/support http://www .belkin .com/uk/support australia http://www .belkin .com/au/support new Zealand http://www .belkin .com/au/support europe http://www .belkin .com/uk/support singapore 1800 622 1130 Malaysia 1 800 812 076 India 1800-419-5546 Thailand 0018004413318 Philippines 180014410282... -
Page 31: Belkin International, Inc ., Limited 3-Year Product Warranty
Belkin reserves the right to discontinue any of its products without notice, and disclaims any limited warranty to repair or replace any such discontinued products . In the event that Belkin is unable to repair or replace the product (for example, because it has been discontinued), Belkin will offer either a refund or a credit toward the purchase of another product from Belkin .com in an amount... - Page 32 Belkin product and how to proceed with your claim . Belkin reserves the right to review the damaged Belkin product . All costs of shipping the Belkin product to Belkin for inspection shall be borne solely by the purchaser .
- Page 33 Some states do not allow limitations on how long an implied warranty lasts, so the above limitations may not apply to you . IN NO EVENT SHALL BELKIN BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS, BUT NOT LIMITED TO,...
-
Page 34: Regulatory Information
DeClaRaTIOn Of COnfORMITY WITH fCC RUles fOR eleCTROMaGneTIC COMPaTIbIlITY We, Belkin International, Inc ., of 12045 Waterfront Drive, Los Angeles, CA 90094, declare under our sole responsibility that the device, , f7D3402 v1, complies with Part 15 of the FCC Rules . Operation is... - Page 35 ReGUlaTORY InfORMaTIOn Canada-Industry Canada (IC) The wireless radio of this device complies with RSS 139 & RSS 210 Industry Canada . This Class B digital apparatus complies with Canadian ICES-003 . Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device .
- Page 36 © 2010 Belkin International, Inc . All rights reserved . All trade names are registered trademarks of respective manufacturers listed . Mac and Mac OS are trademarks of Apple Inc ., registered in the U .S . and other countries . Windows, Windows Vista, and Internet Explorer are either registered...
