- Page 1 M18 / M30 Cylindrical type transceiver for 1732 series User’s Manual...
- Page 2 Federal Communication Commission Interference Statement NOTICE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 3 Bulgarian със съществените изисквания и другитеприложими разпоредби на Директива 1999/5/EC. [HR] Ovim DENSO WAVE INCORPORATED, izjavljuje da je M18/M30 Type Transceiver u sklau s bitnim zahtjevima i Croatian drugim relevantnim odredbama Direktive 1999/5/EC i Pravilnika o RiTT opremi (NN25/2012). [CS] DENSO WAVE INCORPORATED tímto prohlašuje, že M18/M30 Type Transceiver splňuje základní...
- Page 4 NOTICE: This M18/M30 Type Transceiver may be operated in below country: Properly shielded cables must be used for connection to host computers and / or peripherals in order to meet CE emission limits. CE marking...
-
Page 5: Table Of Contents
Table of contents Preface Applicable Standards and Regulations About this Manual SAFETY PRECAUTIONS Chapter 1 Outline 1.1 Hardware Configuration 1.2 System Configuration Chapter 2 Hardware Specifications 2.1 M18 Type Transceiver 2.1.1 Components and Functions 2.1.2 External Dimensions 2.1.3 Environmental Specifications 2.2 M30 Type Transceiver 2.2.1 Components and Functions 2.2.2 External Dimensions... -
Page 6: Preface
DENSO WAVE. 2) The use of DENSO WAVE's products in a manner for which they were not intended nor designed. 3) The modification of DENSO WAVE's products by parties other than DENSO WAVE. -
Page 7: Applicable Standards And Regulations
Applicable Standards and Regulations Standards and Regulations in Other countries Standards Applicability Remarks Radio Regulations FCC (USA) FCC Part 15 Subpart C ✔ *1 FCC ID : PZWAN22R01 FCC ID : PZWAN23R01 R&TTE (Europe) EN 302 291-1, -2 ✔ *1 RSS-Gen RSS-210(Canada) EMC Regulations EC/R&TTE Directive (Europe) -
Page 8: About This Manual
• Every attempt has been made to ensure that the content of this manual is thorough and up to date, however, we kindly ask that any questionable content, mistakes, or omissions be reported to DENSO WAVE. • The copyright for this User’s Manual belongs to DENSO WAVE INCORPORATED. -
Page 9: Safety Precautions
SAFETY PRECAUTIONS Be sure to observe the safety precautions. Read through this manual carefully. It will enable you to use the product correctly. Always keep this manual in a handy place for easy reference. Strict observance of these warnings and cautions is a MUST for preventing accidents that could result in bodily injury and property damage. - Page 10 This is a general characteristic of those systems using radio waves, and not a unique feature of DENSO WAVE’s products or this product itself. More information is available from the website by Ministry of Internal Affairs and Communications at: http:www.soumu.go.jp/s-news/2003/030620_1.html.
- Page 11 Precautions when Handling • Connect the cable to the connector firmly with a clamp. A loose cable could cause a fire or electrical shock. • Replace the damaged cable to a new one, when a connection cable or a device cable are damaged (e.g., exposed or broken lead wires).
- Page 12 Operating Environments • Never leave the product in places where there are excessively high temperatures, radiant heat, or in places exposed to direct sunlight. comply could affect the parts, and cause a fire. Failure to • Do not use the product in places where there are drastic temperature changes. Failure to comply could cause a malfunction, a fire or electrical shock.
-
Page 13: Chapter 1 Outline
1.1 Hardware Configuration This product line (hereinafter referred to as the Transceiver) is developed for the Rockwell Automation “1732 series” products to read and write the HF (High Frequency) RFID tag. As listed below, two versions of the transceivers are added. -
Page 14: Chapter 2 Hardware Specifications
Chapter 2 Hardware Specifications 2.1 M18 Type Transceiver 2.1.1 Components and Functions Power LED Connector Antenna surface Operation LED ・Connector Pin No. Signal Pin1 Pin2 Pin1 DC24V Pin2 Pin3 Pin4 Pin3 Pin4 ・LED light patterns Light Explanation Solid Green Power ON Power LED No light Power OFF... -
Page 15: External Dimensions
2.1.2 External Dimensions Unit: mm... -
Page 16: Environmental Specifications
2.1.3 Environmental specifications Item Specification Maximum surrounding air 70℃ temperature rating Minimum surrounding air -25℃ (With no icing or condensation) temperature rating Operating Humidity 35 to 95%RH (With no icing or condensation) Storage Temperature -40℃ to +85℃ (With no icing or condensation) Storage Humidity 25 to 85%RH (With no icing or condensation) Insulation Resistance... -
Page 17: M30 Type Transceiver
2.2 M30 Type Transceiver 2.2.1 Components and Functions Power LED Connector Antenna surface Operation LED ・Connector Pin No. Signal Pin1 Pin2 Pin1 DC24V Pin2 Pin3 Pin4 Pin3 Pin4 ・LED light patterns Light Explanation Solid Green Power ON Power LED No light Power OFF Blinking Red (short intervals) Nothing Communication... -
Page 18: External Dimensions
2.2.2 External Dimensions Unit: mm M30×1.5... -
Page 19: Environmental Specifications
2.2.3 Environmental specifications Item Specification Maximum surrounding air 70℃ temperature rating Minimum surrounding air -25℃ (With no icing or condensation) temperature rating Operating Humidity 35 to 95%RH (With no icing or condensation) Storage Temperature -40℃ to +85℃ (With no icing or condensation) Storage Humidity 25 to 85%RH (With no icing or condensation) Insulation Resistance... -
Page 20: Chapter 3 Power Supply Specifications
Chapter 3 Power Supply Specifications 3.1 Supply Voltage and Current Consumption Item Specification Supply Voltage DC24V (DC10 to 30V, Ripple is less than 1%) Carrier off 10mA at.DC24V (Excluding inrush) 40mA (Max. 0.1A) M18 type Current Consumption at DC24V Carrirer on 40mA (Max. -
Page 21: Power Off Duration
3.3 Power OFF Duration OFF duration (referred to as “TvccOFF” in the figure) is required to re-power ON. “TvccOFF” must be (1 second) or more. ON duration (referred to as “TvccON” in the figure) is required before sending any command to the transceiver. -
Page 22: Chapter 4 Upper Communication Specifications
Chapter 4 Upper Communication Specifications 4.1 Specifications to communicate with the host device Item Specification Connector M12, 4-pin male connector Communication System Half Duplex (RS-485) Baud Rates 9600/19200/38400/115200bps selectable (Default: 38400bps) Data Length 8bit Stop Bit Length 1bit Error Detection Parity bit even Cable Length Max. -
Page 23: I/F Circuit
4.2 I/F Circuit IF EN 120ohm 4.3 Response Timing Output form the upper driver Command variable variable variable Command Response... -
Page 24: Chapter 5 Tag Communication Specifications
Chapter 5 Tag Communication Specifications 5.1 Specifications to communicate with the RF tag The following is the communication specifications between the transceiver and the RFID tag. Item Specification Tag Type ISO/IEC 15693 Communication System Half Duplex Synchronization scheme Bit Synchronization Transceiver Baud Rate 26.48kbit/s (Carrier:13.56MHz) -
Page 25: Communication Area (Reference)
5.3 Communication Area (reference) M18 Type φ50 tag distance 40mm [mm] T.B.D -60 -50 -40 -30 -20 -10 0 10 20 30 40 50 60 10 20 30 40 50 60 70 80 90 100 110 [mm] M30 Type φ50 tag [mm] distance 60mm T.B.D... -
Page 26: Chapter 6 Installation
Chapter 6 Installation 6.1 Tightening Torque The tightening torque must be 19.8N･m for M18 nut, and 33.9N･m for M30 nut. Washer 6.2 Surrounding Metal M18 Type: Communication distance will drop significantly when the distance between the transceiver and any surrounding metal is less than 25mm. M30 Type: Communication distance will drop significantly when the distance between the transceiver and any surrounding metal is less than 30mm. -
Page 27: Interference Between The Transceivers
6.3 Interference between the transceivers Installing more than one transceiver causes radio frequency interference and may result in the difficulty of the tag communication. Keep a sufficient distance between the transceivers as shown in the figure below. ・face to face For M18: more than 180mm For M30: more than 200mm ・side by side... -
Page 28: Chapter 7 Troubleshooting
Chapter 7 Troubleshooting Examine the cause of the problem by using the flowchart below and take appropriate countermeasures when any problems occur. Check flow Do the operating and Read “Chapter 2 Hardware Specifications” , environmental conditions and confirm that the transceiver is used in the comply with the proper operating and environmental conditions. - Page 29 M18 type transceiver (56RF-TR-M18) M30 type transceiver (56RF-TR-M30) for 1732 series User’s Manual Ver : 0.92 Jul. 2012 1, Yoshiike, Kusagi, Agui-cho, Chita-gun, Aichi 470-2297, Japan 105-0001 http://www.denso-wave.com/...
