FL-net(OPCN-2)
Interface Module
Thank you for purchasing the Mitsubishi programmable controller
MELSEC-Q series.
Prior to use, please read this and relevant manuals thoroughly to
fully understand the product.
©2002 MITSUBISHI ELECTRIC CORPORATION
User's Manual
QJ71FL71-T-F01
QJ71FL71-B5-F01
QJ71FL71-B2-F01
MODEL QJFL71-F01-U-HW
MODEL
CODE
IB(NA)-0800239-E(0809)MEE
(Hardware)
13JP09

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi MELSEC-Q series

Summary of Contents for Mitsubishi MELSEC-Q series

  • Page 1 FL-net(OPCN-2) Interface Module User’s Manual (Hardware) QJ71FL71-T-F01 QJ71FL71-B5-F01 QJ71FL71-B2-F01 Thank you for purchasing the Mitsubishi programmable controller MELSEC-Q series. Prior to use, please read this and relevant manuals thoroughly to fully understand the product. MODEL QJFL71-F01-U-HW MODEL 13JP09 CODE IB(NA)-0800239-E(0809)MEE...
  • Page 2 SAFETY PRECAUTIONS (Always read these instructions before using this equipment.) Before using this product, please read this manual and the relevant manuals introduced in this manual carefully and pay full attention to safety to handle the product correctly. The instructions given in this manual are concerned with this product. For safety instructions of the programmable controller system, please read the CPU module user's manual.
  • Page 3 [Design Precautions] CAUTION Do not bunch the control wires or communication cables with the main circuit or power wires, or install them close to each other. They should be installed 100 mm (3.94 inch) or more from each other. Not doing so could result in noise that would cause erroneous operation. [Installation Precautions] CAUTION Use the programmable controller in an environment that meets the general...
  • Page 4 [Wiring Precautions] CAUTION When wiring the connectors for external cable connection, crimp or clamp the wires with a tool specified by the manufacture or solder them. An incomplete connection could cause malfunctions. Do not connect AUI cables when the programmable controllers on the station where the module is mounted and the FL-net (OPCN-2) system are powered Install the connector to the module securely.
  • Page 5 This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 6: Table Of Contents

    (1) For programmable controller system To configure a system meeting the requirements of the EMC and Low Voltage Directives when incorporating the Mitsubishi programmable controller (EMC and Low Voltage Directives compliant) into other machinery or equipment, refer to Chapter 9 "EMC AND LOW VOLTAGE DIRECTIVES"...

  • Page 7: Overview

    1. Overview This manual explains how to handle the FL-net (OPCN-2) interface module, model numbers QJ71FL71-T-F01, QJ71FL71-B5-F01 and QJ71FL71-B2-F01 (hereinafter referred to as the FL-net module). (Product composition) Model name Product name Quantity QJ71FL71-T-F01 QJ71FL71-T-F01 FL-net (OPCN-2) interface module QJ71FL71-B5-F01 QJ71FL71-B5-F01 FL-net (OPCN-2) interface module QJ71FL71-B2-F01 QJ71FL71-B2-F01 FL-net (OPCN-2) interface module...
  • Page 8 Specifications QJ71FL71-B5 QJ71FL71-T QJ71FL71-B2 Items -F01 -F01 -F01 10BASE-T/ 10BASE5 10BASE2 100BASE-TX Area 1 (bit area): 8 k bits Common memory area Area 2 (word area): 8 k words Virtual address space and — physical memory Error log memory area 512 words Bit area: 2 k bits Status memory area...

  • Page 9: Mounting And Installation

    3. Mounting and Installation 3.1 Precautions when handling This section explains the precautions for the FL-net module itself. (1) The case for the FL-net module is plastic. Do not drop it or expose it to strong impact. (2) Before touching the module, always touch grounded metal, etc. to discharge static electricity from human body, etc.
  • Page 10 Name Description 1) LED indicator Refer to (1) LED indication. 10BASE-T/100BASE-TX Connector for connecting FL-net module to connector (RJ45) (*2) 10BASE-T/100BASE-TX. (The FL-net module (for QJ71FL71-T-F01 detects the 10BASE-T or 100BASE-TX only) according to the hub.) 10BASE5 connector Connector for connecting FL-net module to (for QJ71FL71-B5-F01 10BASE5.
  • Page 11 (1) LED indications 1) LED indicators QJ71FL71-T-F01 100M LED name Indication LED on LED off Normal operation Normal Error (*1) (Green) Token passing Token passing No token passing (Green) indicator status Data send status TX (Green) Sending data Not sending data indicator Network parameter PER (Red)

  • Page 12: Connection To A Network

    5. Connection to a Network This chapter explains the methods of connecting the FL-net module to a 10BASE5, 10BASE-T/100BASE-TX or 10BASE2 network. POINT The installation of 10BASE5, 10BASE-T/100BASE-TX or 10BASE2 network requires strict adherence to safety precautions. Consult a specialist when connecting cable terminals or installing trunk line cables, etc.

  • Page 13: Connecting To 10Base5 Network

    5.2 Connecting to 10BASE5 network (1) Connecting an AUI cable <Operating procedure> (Step 1) Slide the retainer in Retainer direction B (Step 2) Insert the AUI connector all the way. AUI cable (*1) (Step 3) Slide the retainer in direction A (Step 4) Check that the AUI cable is locked.
  • Page 14 POINT (1) To prevent a communication error caused by high frequency noise in the installation environment, installing a ferrite core is one of the preventive measures. (2) When 10BASE5 is used and countermeasures against noise and high frequency waves are required for the installation environment of the QJ71FL71-B5-F01, attaching a ferrite core (*1) to the transceiver side of the AUI cable is often effective.

  • Page 15: Connecting To 10Base2 Network

    5.3 Connecting to 10BASE2 network <Operating procedure> 1) As shown in figure, align the grooves [1] and tab [2] and push in. 2) While pushing the connector in, turn the connector to the right until it locks. 3) Confirm that the connector has been locked.

  • Page 16: External Dimensions

    6. External Dimensions (1) QJ71FL71-T-F01 (*1) (0.91) 90(3.54) 27.4 (1.08) (Unit :mm (in.)) *1: When connecting a twisted pair cable, the bending radius near the connector (reference value: R1) must be four times the cable's outside diameter or larger. (2) QJ71FL71-B5-F01 (*1) DC power supply for...
  • Page 17 (3) QJ71FL71-B2-F01 29.2(1.15) 23.65 (0.93) 90(3.54) (0.91) 11.5 27.4 (0.45) (1.08) (Unit :mm (in.))
  • Page 18 Warranty Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi;...
