Installation Guide
This Installation Guide will walk you through the easy steps
to set up your ScreenBeamEnterprise Wireless Display
Receiver. During this process, we'll show you how to :
A
Install the Receiver
B
Connect Using Windows 8.1 or Higher
1
B
Connect Using Intel WiDi App
2
B
Connect Using WiFi Miracast-enabled Device
3
C
Switch Display Modes
D
Device Management
Mini Wireless
Display Receiver
Model# SBWD700A
Part No:
Advertisement
Related Manuals for ActionTec ScreenBeam Enterprise SBWD700A
Summary of Contents for ActionTec ScreenBeam Enterprise SBWD700A
-
Page 1: Installation Guide
Mini Wireless Display Receiver Model# SBWD700A Installation Guide This Installation Guide will walk you through the easy steps to set up your ScreenBeamEnterprise Wireless Display Receiver. During this process, we’ll show you how to : Install the Receiver Connect Using Windows 8.1 or Higher Connect Using Intel WiDi App Connect Using WiFi Miracast-enabled Device Switch Display Modes... - Page 2 Meeting ScreenBeam Enterprise LED Indicator: indicates power supply status USB port: for configuring MGT connection data VGA In: reserved On/Off: the power switch VGA Out: connects to HDTV/projector with a VGA port for video output HDMI Out: connects to HDTV/projector with an HDMI port for video and audio output Ethernet: Connects to Ethernet for receiver management with ScreenBeam Central Management System...
- Page 3 Welcome! Thank you for your purchase of a ScreenBeam Enterprise Wire- less Display Receiver (hereinafter referred to as the Receiver). The Receiver connects to your Intel WiDi or Miracast-capable device wirelessly, and displays the device’s screen on your HDTV. Install the Receiver Step Get the Receiver, power adapter, and HDMI cable or VGA cable from the Receiver’s box.
- Page 4 Step Turn on your TV and switch the input source until you see the Ready To Connect screen.
- Page 5 The Receiver is now connected to your HDTV. Proceed to one of the next three sections of this Guide (depending on the device you are using to connect to the Receiver) to finish the connection procedure. For Windows 8.1 devices, please proceed to section B1; For Windows 7/8 devices, please proceed to section B2;...
- Page 6 Note: The PIN for connection is “12345670” by default if no PIN is displayed. Note: If you are running Windows 8.1 and the screens above do not appear, go to http://www.actiontec.com/widi81 for the latest software updates.
- Page 7 Connect Using Intel WiDi App Step Find the Intel Wireless Display application on the device and launch it. To find the application, go to Windows Search on your device and search for “Intel WiDi” in your apps. Step The device scans for available receivers.
- Page 8 Step The HDTV displays messages to show the status of the connection process. Step A Connection Successful screen appears on your device’s screen, as well as on the HDTV. Display Tip: If the edges of the device screen cannot be seen on the HDTV, adjust cropping.
- Page 9 Connect Using Miracast-enabled Device You can connect to the Receiver from a Miracast-enabled Android device, such as a smartphone, tablet, or game console (find the wireless display feature in Settings). Also, the device should be running the latest software for best performance. Step On a Miracast-enabled Android device, locate and open the Wireless Display Application.
- Page 10 Switch Display Modes The Receiver supports three display modes when connected with a compatible wireless display application (Intel WiDi or Windows 8.1 Project, for example). In Windows, press the Windows logo + P keys simultaneously + P) to launch the display options and select the desired display mode from the options.
-
Page 11: Device Management
Device Management The device management webpage provides the ability to manage the receiver’s settings. Log into the IT Management Console Step Find the receiver’s SSID in the lower left corner of the Ready To Con- nect screen. Step Right-click the WiFi network icon on the taskbar of your device and select Open Network and Sharing Center. - Page 12 Device Management (continued) Step The Manually connect to a wire- less network window appears. Type in or select the following information. Network name: The SSID of the Screen- Beam receiver you wish to connect to. Security type: WPA2 Personal Encryption type: AES Security key: 12345678 (default) Step Check Start this connection automatically if you...
- Page 13 Username and Password boxes and click the Login button. Note: By default, the Username is “Administrator” and Password is “Actiontec”. The username and password are case sensitive. Setting up PIN Pairing Method Step Go to the Features tab page, and set the Force PIN...
- Page 14 Device Management (continued) Setting up PIN Pairing Method (continued) Select “Off” to disable the PIN enforcement function. PIN entry or PBC is required when connecting your device to the receiver for the first time. Select “On” to enable the PIN enforcement function. In this case, you must enter a PIN code on the device connecting to the receiver for the first time.
- Page 15 Device Management (continued) Managing HDMI Port Output Step Go to the Features tab page, and select the desired option in the HDMI Port Power management drop-down box. There are three options: Always On, Screensaver, and HDMI Off. Always On: Selecting this option, the HDMI output is always on.
- Page 16 Device Management (continued) Modifying the Receiver’s SSID Step Go to the Wireless Network Settings tab page, and type a new name in the Network Name (SSID) box and a new password in Network Password box. Step Click the “Apply” button to save your settings. Setting up Broadcast LMI Beacon Step Go to the Wireless Network Settings tab page, and...
- Page 17 Device Management (continued) Modifying the Receiver’s Ethernet Settings Step Go to the Ethernet Interface Setting section on the Ethernet Network Settings tab page, and set the IP Policy to Auto or Static. Auto: The receiver will be assigned an IP address by the DHCP server.
- Page 18 Device Management (continued) Defining a DNS Server for the Receiver Step Go to the Ethernet Interface Setting section on the Ethernet Network Settings tab page, and set the DNS Policy to Auto or Static. Auto: The receiver will be assigned a DNS server automat- ically.
- Page 19 Device Management (continued) Defining the SCMS Server (MGT Server) for the Receiver Step Go to the Remote Management Server (MGT) Set- ting section on the Ethernet Network Settings tab page, and define the MGT Host and the MGT Port. MGT Host: It is the IP address/host name/domain name of the server that hosts the SCMS server.
- Page 20 Product Support & Additional Information Go to http://international.actiontec.com/support for product support, updates, and more information including: • Firmware Updates • Troubleshooting • Registration • FAQs...
-
Page 21: Specifications
Specifications Language: English, French, German, Italian, Japanese, Simpli- fied Chinese, Traditional Chinese, Russian, and Spanish A/V Interface: HDMI output (Type-A male connector), VGA input, and VGA output Video Output: up to full HD 1080p30 (H.264) Audio Output: up to 5.1 surround sound Data port: USB 2.0 (Type A) Ethernet: RJ-45, 10/100 Mbps Firmware Upgrade: Wireless upgrade... - Page 22 - Intel WiDi laptops: Ultrabooks and laptops with Intel WiDi 3.5 or higher - Wi-Fi Miracast capable devices: smartphones, tablets, and laptops with Wi-Fi Miracast • Windows 8.1 / Android 4.2 or higher - Actiontec ScreenBeam USB Transmitter • Windows 7 or higher...
- Page 23 FCC Information and Copyright This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
