Front access connection
Withdrawable pattern
Type S, N - 3 pole - Frame size 1, ln = 2000A to 2500A
Minimum clearance to cassette side
Center line of
operating panel
Center line of
operating panel
Type S, N - 4 pole - Frame size 1, ln = 2000A to 2500A
Minimum clearance to cassette side
Center line of
operating panel
Center line of
operating panel
Test
Copperwork must be supported within 200 mm of breaker
connections-busbars or cables. All connections to be tightened to 50Nm.
Disconnected
Test
Copperwork must be supported within 200 mm of breaker
connections-busbars or cables. All connections to be tightened to 50Nm.
Connected
Disconnected
Connected
M-PACT Plus
A
B
C
X
C.15
