Cassette only
Basic cassette with fl at copper terminals rear connected (800-3200A), integral racking handle,
safety shutters and lockable safety features.
4000A units fi tted with rear vertical terminals as standard (not to be removed).
Frame size Rating (A) Poles
2 800 to 3200 3
4
2 4000 3
4
Moving portion only
Basic circuit breaker manually operated, non automatic (switch only, no protection unit option
available), 5 NO and 3 NC auxiliary switches and cluster contacts.
Frame size Rating (A) Poles
2 800 3
4
4
2 1000 3
4
4
2 1250 3
4
4
2 1600 3
4
4
2 2000 3
4
4
2 2500 3
4
4
2 3200 3
4
4
2 4000 3
4
4
Earthing device
Frame size Rating (A) Poles
1 800 to 4000 3
4
Cat. no. Ref. No.
MH32C32 405357
MH42C32 405356
MH32C40 405359
MH42C40 405358
Position
of the neutral Cat. no. Ref. No.
MH32M08-A 405997
Left MH4L2M08-A 405998
Right MH4R2M08-A 406244
MH32M10-A 405999
Left MH4L2M10-A 406000
Right MH4R2M10-A 406246
MH32M12-A 406001
Left MH4L2M12-A 406002
Right MH4R2M12-A 406248
MH32M16-A 406003
Left MH4L2M16-A 406004
Right MH4R2M16-A 406250
MH32M20-A 406005
Left MH4L2M20-A 406006
Right MH4R2M20-A 406252
MH32M25-A 406007
Left MH4L2M25-A 406008
Right MH4R2M25-A 406254
MH32M32-A 406009
Left MH4L2M32-A 406010
Right MH4R2M32-A 406256
MH32M40-A 406011
Left MH4L2M40-A 406012
Right MH4R2M40-A 406258
Cat. no. Ref. No.
EDF23P40 405665
EDF24P40 405664
