f i r e - p a r t s . c o m
SAFETY NOTICE: IF THIS APPLIANCE IS NOT PROPERLY INSTALLED,
OPERATED AND MAINTAINED, A HOUSE FIRE MAY RESULT.
TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS.
FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE,
BODILY INJURY OR EVEN DEATH. CONTACT LOCAL BUILDING OFFICIALS
ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN
YOUR AREA.
Do Not Discard This Manual: Retain for Future Use
The Seville Insert
Models 1600, 1601
Surround Models 1602, 1603
Homeowner's
Installation and
Operating
Manual
For use in the
1586
United States and Canada
30001586 10/03 Rev. 4
Advertisement
Related Manuals for Vermont Castings 1601
Summary of Contents for Vermont Castings 1601
- Page 1 The Seville Insert Models 1600, 1601 Surround Models 1602, 1603 f i r e - p a r t s . c o m Homeowner’s Installation and Operating Manual For use in the 1586 United States and Canada SAFETY NOTICE: IF THIS APPLIANCE IS NOT PROPERLY INSTALLED, OPERATED AND MAINTAINED, A HOUSE FIRE MAY RESULT.
-
Page 2: Table Of Contents
Vermont Castings Seville Insert Introduction Thank you for choosing a Vermont Castings Seville Insert to meet your heating needs. We're confident you will find the Seville Insert to be an effective wood-burning heater incorporating modern, non-catalytic combustion technology with the classic aesthetic appeal of its Vermont Castings lineage. -
Page 3: Specifications
Glass panel ......High-temperature Infra-red not apply. Since so many variables affect performance, Weight ............... 420lbs. consult your Vermont Castings authorized dealer to Width ............. 29¹⁄₂” (749mm) determine realistic expectations for your home. f i r e - p a r t s . c o m Depth (Front of Ash Lip - Rear Shroud) 29¹⁄₄”... -
Page 4: Installation
Vermont Castings Seville Insert Installation IMPORTANT: FAILURE TO FOLLOW THESE SAFETY NOTICE: IF YOUR INSERT IS NOT PROP- INSTALLATION INSTRUCTIONS MAY RESULT IN A ERLY INSTALLED, OPERATED AND MAINTAINED, DANGEROUS SITUATION, INCLUDING A CHIMNEY A HOUSE FIRE MAY RESULT. FOR SAFETY, OR HOUSE FIRE. - Page 5 • A newly-built masonry chimney must conform to the materials. standards of local building code, or, in the absence The Vermont Castings' Seville Insert is not listed of a local code, to a recognized national code. for use in “zero-clearance” prefabricated fire- Masonry chimneys must be lined, either with code- places.
- Page 6 Vermont Castings Seville Insert Clearance Requirements Minimum Fireplace Dimensions The Seville Insert will fit most masonry fireplaces. To After confirming that your fireplace is the right size, confirm that it will fit yours, measure the lintel depth, check the clearances to combustibles. First mark with...
- Page 7 A Relined Chimney decorative material if desired. There are a number of fittings available from your Vermont Castings’ Authorized Dealer that are designed to form the connection between the insert and chimney liner. Your dealer as well as your local chimney sweep can advise you on the types of lining systems currently available.
- Page 8 Vermont Castings Seville Insert 2. Install the Floor Protector 2. Insert the longer threaded end of the thermostat rod into the control lever located on the left side of the Make sure the floor protector satisfies the requirements Seville Insert and through the 1/4-20 nut. (Fig. 8 & 9) discussed on Page 7.
-
Page 9: Operation
Vermont Castings Seville Insert 5. Carefully lift the assembled panels into the upright position. Locate the assembly directly in front of the 39¹⁄₂" (1003mm) Seville Insert. Move the panel assembly into position Seville Insert by carefully moving it straight back against the fire- Surround place front. - Page 10 Vermont Castings Seville Insert For areas that do not have a supply of hardwood, Use the following air control settings as a starting point commonly burned softwoods include tamarack, yellow to help determine the best settings for your installation. pine, white pine, Eastern red cedar, fir, and redwood.
- Page 11 Vermont Castings Seville Insert BURN SOLID WOOD FUEL ONLY, AND BURN IT DIRECTLY ON THE GRATE. DO NOT ELEVATE THE FUEL. DO NOT BURN COAL OR OTHER FUELS. WARNING: OPERATE THIS STOVE ONLY WITH THE DOOR FULLY CLOSED. The Primary Air Inlet must be open when starting a fire or when refueling.
- Page 12 Vermont Castings Seville Insert Ash Disposal CAUTION: AVOID SLAMMING THE STOVE DOOR OR STRIKING THE GLASS PANEL. DO Remove ash before it reaches the top of the ash pan. NOT OPERATE THE STOVE WITH THE GLASS Check the level at least once a day, and before each PANEL MISSING, DAMAGED, OR BROKEN.
-
Page 13: Maintenance
Then, stove is in operation. Overtightening can crack the touch up the stove with Vermont Castings high glass immediately or cause it to crack if it is unable temperature stove paint. Apply the paint sparingly, to expand when hot. - Page 14 ST268 If you cannot inspect or clean the chimney yourself, contact your local Vermont Castings Majestic Products Fig. 12 Remove shim washers to tighten latch engagement. Company Authorized Dealer or hire a professional chimney sweep.
- Page 15 Vermont Castings Seville Insert Annual Maintenance Draft Management Perform a thorough cleaning, inspection and repair Your stove is only one part of a system that includes each Spring, at the end of the heating season. the chimney, the operator, the fuel and the home. The •...
- Page 16 Vermont Castings Seville Insert Inside/Outside Location Single Venting Because the chimney’s function is to keep the smoke Your stove requires a dedicated flue. Do not connect warm, it is best to locate it inside the house. This the stove to a flue used by any other appliance.
- Page 17 With this ignition, you Consult your Vermont Castings Majestic Products may hear a muffled popping sound and see a bit of dealer regarding an adapter to attach to the stove to smoke forced out of the air inlets.
-
Page 18: Parts List
- p a r t s . c o m 1586 Vermont Castings, Majestic Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. - Page 19 'right' mean as you face the stove. 31. Door Handle Shaft 30000364 32. Roll Pin, 3/16” x 1” 1201833 2. Use only Vermont Castings Glass Panel part 33. Glass Gasket, horizontal 30000896 number 30000774 for replacement. 34. Glass Gasket, vertical (2) 30000895 3.
- Page 20 8. Vermont Castings, Majestic Products shall have no legal remaining term of the original limited warranty or six (6) f i r e - p a r t s .
