Products powered by electricity should be serviced or repaired only by experienced professional technicians.Any attempt to service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death` 2017 Haier washing Machine All rights reserved. Unauthorized copying and distribution is a violation of law.
Issue Service Manual Service Manual Rev. MABE500-1789 Model No: Chapter 1: General Infromation ........2 1-1.Table of Contents ................2 1-2. General Guidelines ................3 1-3. Caution and Warning symbols ............3 1-4. Function indication symbols............... 3 Chapter 2: Product Features ..........4 2-1.
Issue Service Manual Service Manual Rev. MABE500-1789 Model No: 1-2. General Guidelines When servicing observe the original lead dress.If a short circuit is found, replace all parts which are overheated or damaged by the short circuit.After servicing,see to it that all the protective devices such as insulation barriers ,insulation papers shields are properly installed .Confirm that the screws,parts and wiring which were removed in order to service are put in the original positions, or whether there are the portions which are deteriorated around the service places serviced or not.
Issue Service Manual Service Manual Rev. Model No:MABE500-1789 Chapter 2: Product Features 2-1. Features ● Soak wash make cleaner wash ● Fashionable appearance, transparent top lid ● Efficaciously reduce noise ● Automatically power off function ● Self-adjustment to unbalance of laundry in spinning ●...
Issue Service Manual Rev. Model No:MABE500-1789 2-2. Specification Model MABE500-1789 Free standing √ × Built under EAN code Features for use Wash capacity Spin capacity 1/12L 2/16L 3/20L 4/24L 5/28L Level/Volume 6/32L 7/36L 8/40L 9/43L 10/46L Preset √ Residual dampness <115 Control model controller...
Issue Service Manual Service Manual Rev. MABE500-1789 Model No: Chapter 3: SAFETY PRECAUTIONS 3-1. Safety Please insert the power cord into special receptacle with rated voltage. Be sure to use single-phase three pins receptacle.The earthing terminal of the receptacle must be earthed reliably. If possible,please adopt electric leakage protector.
Page 7
Issue Service Manual Service Manual Rev. Model No: MABE500-1789 Do not wash laundries with volatile materials (such as thinner, petrol etc.) The children shall not approach the working washing machine. Keep the machine away from direct sunlight and heat source like the heater. Do not decompose, repair or alter the machine by yourself.
Issue Service Manual Service Manual Rev. Model No: MABE500-1789 3-3. Net Dimensions Unit: mm Chapter 4: Installation and accessory parts 4-1. Key points in installation Please install and adjust the machine according to the requirement of the mannual. It is very important to your security and correct operating the machine. 4-2.
Issue Service Manual Rev. MABE500-1789 Model No: 4-3. Adjustment of the installation position The largest allowable slope of the shank base of the machine is ≤2°. The slanting or rough ground will result in unstable running or stoppage of the machine. Please adjust it with following methods: ●Confirm it's horizontal: Hang the lead line to check if it is horizontal ●Adjust the adjustable foot:...
Issue Service Manual Service Manual Rev. MABE500-1789 Model No: 4-5. Placement of Drainage Hose To avoid syphoning, the drain hose should not be submerged in the water.
Issue Service Manual Rev. Model No: MABE500-1789 4-6. Usage of oper Lighting Flashing Water Level Deep Clean Normal Wash Time Warm Delicate Strong Rinse Times Cool Wool Soak Spin Time Child Remaining Minutes Air Dry Lock Cold Quick Delay Start/Pause Power Water Process...
Page 12
Issue Service Manual Rev. Model No:MABE500-1789 Process” button To select water level, wash time, rinse times , spin time and Delay. When the process is selected, push ”Adjust“ button and then adjust the parameters. Set the desired washing program,after seting,press the Start/Pause button,and washing machine begin to run Then hold the water level button and delay botton at the same time for more than 3 seconds,you will hear three beep sound,digital tub display“CL”,and the child lock will activate All of the bottons are locked,...
Issue Service Manual Rev. Model No:MABE500-1789 4-7. Key points in disassembly 4-7-1 Points of attention in maintance 1) General attention ● Be sure to pull off the power plug in disassembly or maintenance ● Use stipulated crimp terminals in connecting the wires between the conducting wires as far as possible, and fix with suitable tools;...
Issue Service Manual Service Manual Rev. Model No:MABE500-1789 4-7-2 Points of attention in assembly ● Fix the wiring in the control panel seat to its original position. Do not make it touch sharp corner and mobile position. The space surrounding the computer sequencer is rather narrow. Please dispose it carefully and do not make the transformer press the wires.
Issue Service Manual Rev. Model No:MABE500-1789 Chapter 5: PARTS AND FUNCTIONS Liquid detergent dispenser Powder detergent dispenser Outer tub cover Balance ring Top lid component Control panel seat Control panel film Inner tub Lint filter Filter cover Pulsator Cabinet Cabinet handle Adjustable foot(2 pieces)
Issue Service Manual Service Manual Rev. Model No:MABE500-1789 Chapter 6: MAINTENANCE SERVICE AND TROUBLE SHOOTING 6-1. Trouble alarm and solve method Push Is the drain hose set too low? The height of the end of the drain hose should be between 800mm-1200mm The display shows F2.
Issue Service Manual Rev. Model No:MABE500-1789 6-2. Trouble-shooting charts If you replace the computer sequencer without checking the other components carefully, the computer sequencer may be damaged again. Therefore,please first check if the other components working normally before replacing the computer sequencer in maintence. 6-2-1 No action (The indicator is off) Confirm that there's no power failure and the power plug is inserted reliably.
Issue Service Manual Service Manual Rev. Model No:MABE500-1789 6-2-2 No water filling Switch on the power. Push the "Start/Pause" button. Remove the foreign materials of the water There is sound Confirm the action sound inlet valve filter screen or raise the water of the water inlet valve? pressure to 0.03Mpa-1Mpa before use.
Issue Service Manual Rev. Model No:MABE500-1789 Set rinse or spin. 6-2-4 No draining Start the machine. Roll up normally Check the drain system like Check if the drain motor acts? the drain valve etc. Measure the Exist voltage of the two ends of Replace the drain motor.
Issue Service Manual Service Manual Rev. Model No:MABE500-1789 6-2-6 No spinning The washing and draining are normal. No On/Off point Replace the microswitch Check the On/off point of the or stop switch. microswitch and stop switch. Normally Check if the clutch pawl Replace the drain motor.
Issue Service Manual Rev. Model No:MABE500-1789 6-2-8 Too much noise in washing If the noise of the motor Replace the motor is too much? If the motot fastened tightly? Fasten the motor The pulsator is rubbing the Add pulsator gasket bottom of the inner tub.
Issue Service Manual Service Manual Rev. Model No:MABE500-1789 6-2-10 Brake time out Is the brake moment of the retarder Adjust the brake moment. lower than 6N.m? Is the reset spring of the retarder loose? Adjust the reset spring. Check if the pawl can leave the ratchet for 2mm Is the gap between the connecting arm block and the brake arm of retarder less up during spinning.
Issue Service Manual Rev. Model No:MABE500-1789 Chapter 7: WIRING DIAGRAM Fuse Fuse Black Black White Yellow White Yellow Blue/White Blue Door Switch Door Switch Life Line Yellow Life Line Yellow Green Green Life Line Life Line Life Line Orange Blue Life Line Red/White Orange...
Page 24
