ALDI Workzone Titanium+ 85509 Instruction Manual

700w airless spray station
Hide thumbs

Advertisement

Table of Contents

700W AIRLESS SPRAY STATION
Original Instructions
WARNING!
Read this Instruction Manual
carefully before using the spray
station and keep it in a safe place
for future reference.
This instrucitons can also be obtained from service address below.
01904 727506
01247 5150
MODEL: PLD3090, 85509, 8/2018
Instruction
Manual
3
YEAR WARRANTY
700W AIRLESS SPRAY STATION
Version Number: 001
PLD3090 57488 09/2017
1

Advertisement

Table of Contents
loading

Related Manuals for ALDI Workzone Titanium+ 85509

Summary of Contents for ALDI Workzone Titanium+ 85509

  • Page 1 Instruction 700W AIRLESS SPRAY STATION Manual 700W AIRLESS SPRAY STATION Original Instructions WARNING! Read this Instruction Manual carefully before using the spray station and keep it in a safe place for future reference. This instrucitons can also be obtained from service address below. 01904 727506 01247 5150 YEAR WARRANTY...

  • Page 2: Table Of Contents

    700W AIRLESS SPRAY STATION Contents Welcome 1. APPLICATION ………………………………..............……….. 4 2. PARTS DESCRIPTION …………………………………………………………………....... 5 Congratulations for choosing to buy a Workzone® Titanium product. 3. PACKAGE CONTENT LIST ………………………………………………….......…………. 6 4. SYMBOLS ………………………………………………………………......…………………… 7 All products brought to you by Workzone® Titanium are manufactured to the highest 5.

  • Page 3: Application

    700W AIRLESS SPRAY STATION 700W AIRLESS SPRAY STATION Application Parts Description AIRLESS SPRAY STATION 700W 2. PARTS DESCRIPTION PLD3090 Fig.A 1. APPLICATION This Airless Spray Station is designed for coating and painting applications. It can draw material/paint directly from a material/paint can. It delivers 3000psi and can cover a large area in a short period of time.

  • Page 4: Package Content List

    700W AIRLESS SPRAY STATION Package Content List Symbols 700W AIRLESS SPRAY STATION 3. PACKAGE CONTENTS LIST 4. SYMBOLS 1 x Airless spray station 1 x Cleaning Brush The following symbols are used in this manual and/or on the airless spray 1 x Spray gun 1 x Cleaning Needle station.

  • Page 5: General Power Tool Safety Warnings

    700W AIRLESS SPRAY STATION General Power Tool Safety Warnings General Power Tool Safety Warnings 700W AIRLESS SPRAY STATION 5. GENERAL POWER TOOL SAFETY WARNINGS f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

  • Page 6: Safety Instructions For Airless Spray Station

    700W AIRLESS SPRAY STATION General Power Tool Safety Warnings Safety Instructions For Airless Spray Station 700W AIRLESS SPRAY STATION 6. SAFETY INSTRUCTIONS FOR AIRLESS SPRAY c) Disconnect the plug from the power source and/or the battery pack before making any adjustments, changing accessories, or storing STATION power tools.

  • Page 7: Material And Paint Selection

    700W AIRLESS SPRAY STATION Material And Paint Selection 700W AIRLESS SPRAY STATION Safety Instructions For Airless Spray Station h) Plastics can cause static sparks. Never hang plastic sheets to enclose 7. MATERIAL AND PAINT SELECTION the spray area. Do not use plas c drop cloths when spraying flammable materials.

  • Page 8: Assembly

    700W AIRLESS SPRAY STATION Assembly Operation 700W AIRLESS SPRAY STATION 8. ASSEMBLY 9. OPERATION 8.1 Attaching paint sprayer to metal stand 9.1 Trigger Lock (Fig.4) (Fig.1) a) Put the paint sprayer onto the metal WARNING! Always lock the spray gun when you stop spraying to stand.
  • Page 9 700W AIRLESS SPRAY STATION Operation Operation 700W AIRLESS SPRAY STATION 9.3 Priming the pump (Fig. 6-9) a) Turn the Prime/Spray knob to the PRIME position. a) Submerge the suction tube in the paint inside the paint container. b) Aim the spray gun into a waste container. Pull and hold the trigger. c) Whilst pulling the trigger, turn on the airless spray station and turn the b) Place the return tube into a waste container.
  • Page 10 700W AIRLESS SPRAY STATION Operation Operation 700W AIRLESS SPRAY STATION 9.8 Spray technique(Fig.12-14) 9.6 Spraying (Fig. 11) a) Keep your arm moving at a constant speed and keep the spray gun at a constant distance from the surface being sprayed. The best distance is WARNING! Ensure the spray hose is free of kinks and clear of objects 25cm to 30cm.

  • Page 11: Cleaning

    700W AIRLESS SPRAY STATION Cleaning Cleaning 700W AIRLESS SPRAY STATION 10. CLEANING e) Point the spray gun at a piece of wood or cardboard, unlock and pull the trigger to blow out the obstructions. When the spray tip is clean, material/ paint will come out in a straight, high pressure stream.
  • Page 12 700W AIRLESS SPRAY STATION Cleaning Cleaning 700W AIRLESS SPRAY STATION g) Replace the cleaned spray tip, saddle seat and washer back to the spray e) Check the two rubber seal rings, clean and lubricate with a light machine guard assembly. oil.

  • Page 13: Maintenance

    700W AIRLESS SPRAY STATION Maintenance Storage 700W AIRLESS SPRAY STATION 11. MAINTENANCE 12. STORAGE a) The airless spray station has been designed to operate over a long 12.1 Short term storage - up to 3 hours during operation period of time with minimum maintenance. Continuous satisfactory a) The airless spray station can be stored with material/paint up to 3 hours operation depends on proper care and regular cleaning.

  • Page 14: Disposal

    700W AIRLESS SPRAY STATION Disposal Troubleshooting 700W AIRLESS SPRAY STATION 14. RESIDUAL RISKS Additional residual risks may arise when using the tool which may not be included in the enclosed safety warnings. These risks can arise from misuse, prolonged use etc. Even with the application of the relevant safety regulations and the implementation of safety devices, certain residual risks cannot be avoided.
  • Page 15 700W AIRLESS SPRAY STATION Technical Specifications Residual Risks 700W AIRLESS SPRAY STATION 16. TECHNICAL SPECIFICATIONS Does not draw in paint The airless spray station is not Prime the airless spray station when the Prime/Spray primed p r roperly knob is set to PRIME Model No.
  • Page 16 Warranty card Warranty conditions conditions Warranty conditions WARRANTY CARD Dear Customer, Airless spray station The ALDI warranty offers you extensive benefits. Warranty period: 3 years from date of purchase. Excluding Consumables. Your details: Name Costs: Free repair/exchange. No transport costs.
  • Page 17 （ ） （ ）...
  • Page 18 ALDI guarantees that our exclusive brand products are developed to our strin- please return it to your nearest ALDI store within 60 days from the date of purchase for a full refund or replacement, or take advantage of our after sales support by calling the supplier‘s Customer Service Helpline.
