FCC INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide residential protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not Installed and used in accordance with the instructions, may cause harmful interference to radio communications.
LOCATION OF CONTROLS: Main Unit: 1. Camera 2. Micro SD Card Slot 3. Built-in Battery 4. Blades 5. Decorative LED Lights 6. DC IN Jack...
Page 4
Remote Control: 1. Left Joystick 2. Right Joystick 3. Video/Photo Shutter Button 4. Roll Button 5. Crab Trimmer 6. Left/Right Trimmer 7. Power ON-OFF Switch 8. Speed Adjust Button 9. Forward/Backward Trimmer 10. Antenna 11. Power On Indicator 12. Headless Button 13.
Page 5
PREPARATIONS: Recharging the built-in battery in the unit. The unit has a built-in DC 3.7V Li-ion rechargeable battery, recharge it before first time use or when it is consumed as follow: Connected the small plug from the supplied USB Charging Cable to the battery on the unit.
Install or replace the batteries of Remote Control: The Remote Control is using six (6) AA size batteries (Not included), install or replace when it is consumed as below: Unsecure the screw from the battery door. Press the tab on the battery door then lift it up as the Fig. 1 below. Install six (6) AA size batteries into the battery compartment as the polarity marking inside.( For longest playing time, Alkaline batteries are recommended.) Close the battery door as the Fig.
Page 7
Micro SD Card Installation: The unit is support to take photos/videos then record in a Micro SD Card (not supplied). Insert a Micro SD Card into the Micro SD Card Slot with contact fingers face to blades side as the figures follow: Notes: Insert the class 4 (or up) Micro SD Card (Up to 32GB) into the Micro SD Card Slot with contact fingers face to blades side.
Page 8
OPERATIONS: 1. Insert the Micro SD Card to the unit as previous procedures. 2. Recharge the built-in battery as previous procedures. 3. Connect the connection plug from the built-in battery to the DC IN Jack on the unit as the figure below. The Decorative Lights on the unit will illuminate and blink. 4.
Press the upper or lower side of the Crab Trimmer repeatedly to fine tune the Joystick’s control of Crab. Press the upper or lower side of the Left/Right Trimmer repeatedly to fine tune the Joystick’s control of Left/Right . Press the upper or lower side of the Forward/Backward Trimmer repeatedly to fine tune the Joystick’s control of Forward/Backward.
Page 10
The unit had not paired to the Pair the unit to the Remote Control as Remote Control. “OPERATION” section point 4-6 on page 7. Push the Left Joystick to downward. Wait The blade still running The unit had not shut off, until the blades stop turning.
