Page 1 Thank you for purchasing this SHARP product. To obtain the best performance from this product, please read this manual carefully. It will guide you in operating your SHARP product. CD-ES700 Mini Component System consisting of CD-ES700 (main unit) and CP-ES700 (speaker system).
Page 2: Special Notes
NOTE It is the intent of Sharp that this product be used in full compliance with the copyright laws of the United States and that prior permission be ob- tained from copyright owners whenever necessary.
Page 3: Important Safety Instructions
Instruction Manual for replacement or resetting of protective device. If replacement of the plug is required, be sure the service technician has used a replacement plug specified by the manufacturer that has the same overload protection as the original plug. CD-ES700 CD-ES77...
Page 4 CD-ES700 IMPORTANT SAFETY INSTRUCTIONS CD-ES77 Outdoor Antenna Grounding - If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.
Page 5: Table Of Contents
NERGY TAR® Program Information As an NERGY TAR® Partner, SHARP has determined that this product meets the NERGY TAR® guidelines for energy efficiency. NERGY TAR® is a U.S. registered mark. WHY PURCHASE NERGY TAR® LABELED PRODUCTS? Many Electrical /Electronic Products use energy both when they are on and when they are off.
Page 6: Precautions
Using this product with a higher voltage other than that which is specified is dangerous and may result in a fire or other type of acci- dent causing damage. SHARP will not be held responsible for any damage resulting from use of this unit with a voltage other than that which is specified.
Page 7: Controls And Indicators
26. Game/Video Button ....... 31 24 25 26 CD-ES700 CD-ES77...
Page 8: Rear Panel
CD-ES700 Controls and indicators (continued) CD-ES77 13 14 15 ! Display 1. Disc Number Indicators ......18 2.
Page 9 20. Equalizer Mode Select Button ..... . 14 21. Volume Up and Down Buttons ..... . 14 CD-ES700 CD-ES77...
Page 10: System Connections
System connections CD-ES700 CD-ES77 Make sure to unplug the AC power cord before any connections. Right speaker Speaker connection (see page 11) Antenna connection (see page 11) FM antenna AM loop antenna Left speaker AC outlet (AC 120 V, 60 Hz)
Page 11: Antenna Connection
! Placing the speaker system The left and right speakers have individual shapes. For best perfor- mance, place the speakers according to the diagram below. Left speaker Screws (not supplied) Note: The speaker grilles are not removable. CD-ES700 CD-ES77 Black Incorrect Right speaker...
Page 12: System Connections
CD-ES700 System connections (continued) CD-ES77 ! AC power connection After checking all the connections have been made correctly, plug the AC power cord of this unit into the AC outlet. If you plug in the unit first, the unit will enter the demonstration mode.
Page 13: Remote Control
Point the remote control directly at the remote sensor on the unit. The remote control can be used within the range shown below: Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy music. 8" - 20' (0.2 m - 6 m) CD-ES700 CD-ES77 Remote sensor...
Page 14: General Control
General control CD-ES700 CD-ES77 ! To turn the power on Press the ON/STAND-BY button to turn the power on. After use: Press the ON/STAND-BY button to enter the power stand-by mode. ! Illumination light control When the power is turned on, light illuminates around the display. To turn on/off the light, hold down the CLEAR/DIMMER button on the remote control more than 2 seconds.
Page 15: Setting The Clock
The clock can also be set with the remote control. button to adjust the hour and then button once to advance the time by 1 button to adjust the minutes and button once to advance the time by 1 button to display the time. CD-ES700 CD-ES77...
Page 16: Cd Playback
Listening to a CD (CDs) CD-ES700 CD-ES77 This system can play audio CD, CD-R and CD-RW discs, but cannot record. Some audio CD-R and CD-RW discs may not be playable due to the state of the disc or the device that was used for recording.
Page 17 END" will appear on the display and CD operation will be paused. When the beginning of the first track is reached during fast re- verse, the unit will enter the playback mode. ( : Last track number) CD-ES700 CD-ES77 Operation Press in the stop mode.
Page 18: Advanced Cd Playback
CD-ES700 Advanced CD playback CD-ES77 ! To specify a disc to play You can play a disc by specifying the disc number. Press one of the 5 buttons to select the desired disc. Selected disc number Within 5 seconds, press the DIRECT PLAY button on the main unit.
Page 19: Repeat Play
" In random play, the CD player will select and play tracks automat- ically. (You cannot select the order of the tracks.) Caution: After performing repeat or random play, be sure to press the ton. Otherwise, the disc(s) will play continuously. CD-ES700 CD-ES77 but-...
Page 20 CD-ES700 Advanced CD Playback (continued) CD-ES77 ! Programmed play You can choose up to 32 selections for playback in the order you like. While in the stop mode, press the MEMORY/SET (MEMORY) button to enter the programming save mode. Press one of the 5 buttons to select the desired disc.
Page 21: Listening To The Radio
" " " will appear when an FM broadcast is in stereo. " If the FM reception is weak, press the TUNER (BAND) button to extinguish the "ST" indicator. The reception changes to monau- ral, and the sound becomes clearer. FM stereo mode indicator FM stereo receiving indicator CD-ES700 CD-ES77...
Page 22: Listening To The Radio
CD-ES700 Listening to the radio (continued) CD-ES77 ! Memorizing a station You can store 40 AM and FM stations in memory and recall them at the push of a button. (Preset tuning) Perform steps 1 - 3 in "Tuning" on page 21.
Page 23: Tape Playback
2) button (main unit and remote control): The unit turns on and the "TAPE" function is activated. " button (main unit and remote control): The unit turns on and playback of the last function starts (CD/TAPE/TUNER/ GAME). CD-ES700 CD-ES77 TAPE 1 TAPE 2 Tape play indicator...
Page 24: Recording On A Cassette Tape
" When recording important selections, make a preliminary test to Operation ensure that the desired material is properly recorded. control " SHARP is not liable for damage or loss of your recording arising Press in the stop from malfunction of this unit. mode.
Page 25 CD and the cassette will stop automatically. " CD playback will start approximately 7 seconds after the tape starts. To stop recording: Press the button. The CD and tape will stop. CD-ES700 CD-ES77...
Page 26: Recording On A Cassette Tape
CD-ES700 Recording on a cassette tape (continued) CD-ES77 Recording from several CDs continuously: 1 Perform steps 1 - 5 in "Recording from a CD (CDs)" on page 25. 2 Within 5 seconds, press the To perform programmed recording: 1 Program discs and tracks. (See page 20.) 2 Press the button.
Page 27: Timer And Sleep Operation
Within 10 seconds, press the "ONCE" or "DAILY", and press the MEMORY/SET button. Once timer Stop Set the unit to the correct time if "ONCE" or "DAILY" does not appear. sette compartment. button to select Continued to the next page CD-ES700 CD-ES77...
Page 28 CD-ES700 Timer and sleep operation (continued) CD-ES77 Within 10 seconds, press the lect "ONCE SET" or "DAILY SET", and press the MEMORY/ SET button. Press the "REC", and press the MEMORY/SET button. White The illustrations show the daily timer setting.
Page 29 "ONCE ON" or "DAILY ON", and press the MEMORY/SET button. 4 Press the ON/STAND-BY button to enter the power stand-by mode. Note: The timer can also be set with the remote control. CD-ES700 CD-ES77 button to select button to select button to select...
Page 30: Timer And Sleep Operation
CD-ES700 Timer and sleep operation (continued) CD-ES77 ! Sleep operation The radio, compact disc and cassette tape can all be turned off automatically. Play back the desired sound source. Press the CLOCK/TIMER button. Within 10 seconds, press the button to select "SLEEP", and press the MEMO-...
Page 31: Enhancing Your System
(CD/TAPE/TUNER/GAME). ! To record on a tape from Game, VCR etc. Insert a cassette in the TAPE 2 cassette compartment. Press the GAME/VIDEO button. Press the button. Press the button. Play the game system, VCR, etc. Yellow CD-ES700 CD-ES77...
Page 32: Troubleshooting Chart
Troubleshooting chart Many potential problems can be resolved by the owner without call- ing a service technician. If something is wrong with this product, check the following before calling your authorized SHARP dealer or service center. ! General Symptom Possible cause "...
Page 33 While pressing down the button and the X-BASS/DEMO but- ton, press the PRESET button until "CLEAR AL" appears. Caution: This operation will erase all data stored in memory including clock, timer settings, tuner preset, and CD program. CD-ES700 CD-ES77...
Page 34: Maintenance
CD-ES700 CD-ES77 ! Condensation Sudden temperature changes, storage or operation in an extremely humid environment may cause condensation inside the cabinet (CD pickup, tape heads, etc.) or on the transmitter on the remote control. Condensation can cause the unit to malfunction. If this happens, leave the power on with no disc (or cassette) in the unit until normal playback is possible (about 1 hour).
Page 35: Specifications
Specifications As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification fig- ures indicated are nominal values of production units. There may be some deviations from these values in individual units.
Page 36: Consumer Limited Warranty
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused by repairs or attempted repairs performed by anyone other than an authorized servicer.
