Set up and Operating inStructiOnS
Visit our website at: http://www.harborfreight.com
read this material before using this product.
failure to do so can result in serious injury.
SaVe thiS manual.
©
Copyright
2009 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements,
actual product may differ slightly from the product described herein.
for technical questions or replacement parts, please call 1-800-444-3353.
air knife with
3 bladeS
®
. All rights reserved. No portion of this manual or any artwork
67473
Advertisement
Table of Contents
Related Manuals for Central Pneumatic 67473
Summary of Contents for Central Pneumatic 67473
-
Page 1: Set Up And Operating Instructions
3 bladeS 67473 Set up and Operating inStructiOnS Visit our website at: http://www.harborfreight.com read this material before using this product. failure to do so can result in serious injury. SaVe thiS manual. © ® Copyright 2009 by Harbor Freight Tools . -
Page 2: Important Safety Information
The tool is able to alert symbol, indicates a create sparks resulting in the ignition hazardous situation which, if of the dust or fumes. Page 2 for technical questions, please call 1-800-444-3353. SKU 67473... -
Page 3: Personal Safety
Use the use safety equipment. A correct tool for the application. The dust mask, non-skid safety correct tool will do the job better and shoes and a hard hat must SKU 67473 for technical questions, please call 1-800-444-3353. Page 3... -
Page 4: Air Source
There is a risk of bursting if the tool is inStructiOnS. damaged. use only accessories that are identified by the manufacturer for the specific tool model. Use of an accessory not intended for use with Page 4 for technical questions, please call 1-800-444-3353. SKU 67473... -
Page 5: Symbols And Specific Safety Instructions
California to cause birth defects (or other reproductive harm). (California Health & Safety code § 25249.5, et seq.) Only use with accessories rated to handle the forces exerted by this tool during operation. Other accessories SKU 67473 for technical questions, please call 1-800-444-3353. Page 5... - Page 6 Pregnant women or people who have impaired blood circulation to the hand, past hand injuries, nervous system disorders, diabetes, or Raynaud’s Disease should not use Page 6 for technical questions, please call 1-800-444-3353. SKU 67473...
-
Page 7: Functional Description
Pneumatic Remove this plug before set up. Tool Oil to the airline connection before operation. Add a few more SKU 67473 for technical questions, please call 1-800-444-3353. Page 7... -
Page 8: Instructions For Putting Into Use
Adjust the pressure gradually, Page 8 for technical questions, please call 1-800-444-3353. SKU 67473... -
Page 9: Components And Controls
Set up source. While holding the air knife firmly in one hand and the other Designate a work area that is clean and well-lit. The work area must not SKU 67473 for technical questions, please call 1-800-444-3353. Page 9... - Page 10 Without it, the tool could activate when the tool is bumped against something, set down on its lever, or someone goes to pick up the tool, Page 10 for technical questions, please call 1-800-444-3353. SKU 67473...
-
Page 11: User Maintenance Instructions
Check all screws to ensure they are explosion. tight and secure. SKU 67473 for technical questions, please call 1-800-444-3353. Page 11... -
Page 12: Troubleshooting
BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Page 12 for technical questions, please call 1-800-444-3353. SKU 67473... -
Page 13: Parts List & Assembly Diagram
Fork Drive Spring valve Screw Ball Bearing O-Ring Crankshaft O-Ring Retainer Ball Bearing Exhaust Deflector Front Plate Air Inlet Washer Oil Cover Screw Rotor O-Ring Rotor Blade Hex Wrench M5 SKU 67473 for technical questions, please call 1-800-444-3353. Page 13... -
Page 14: Limited 1-Year Warranty
If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 14 for technical questions, please call 1-800-444-3353. SKU 67473...
