- Page 1 METAL WORKBENCH 47878 ASSEMBLY & OPERATING INSTRUCTIONS ®...
- Page 2 THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please complete the owner’s record below: Model___________ Serial No._____________ Purchase Date_____________ Save This Manual You will need the manual for the safety warnings and precautions, assembly instructions, operating and maintenance procedures, parts list and diagram.
- Page 3 Use of any other parts will void the warranty. Only use accessories intended for use with this product. Approved accessories are available from Harbor Freight Tools. 10. Do not operate product if under the influence of alcohol or drugs. Read warning labels on prescriptions to determine if your judgment or reflexes are impaired while taking drugs.
- Page 4 Step 8) Set the lip of the Drawer-Backing on top of the Drawer-Base. Attach the Drawer Backing (R) to the Drawer Base (K) with three (3) Bolts, then slide on Washers (N) and secure with Nuts (P). #47878 Page 4...
- Page 5 The Legs will be attached at each corner of the Wooden Top (I). Measure to make certain that each Leg (G) is placed within the same distance from each corner. Attach the Legs (G) to the Wooden Top (I) with three (3) Wood Screws (S) for each Leg-see Figure 5. #47878 Page 5...
-
Page 6: Unpack And Check Contents
Unpacking UNPACK AND CHECK CONTENTS When unpacking your Metal Workbench, check to make sure the following parts are included. If any parts are missing or broken, please call HARBOR FREIGHT TOOLS at 1-800-444-3353. Parts List-Roller Stand Part # Description Quantity...
