Sennheiser SDC 8000 CV Specification

SDC 8000 CV
Conference and Information Systems |
General Description
The digital SDC 8000 CV chairman's unit is an ideal choice for both mobile and fixed
conference systems. Its compact and elegant design harmoniously blends in with
any conference room. The unit features a high-quality built-in loudspeaker, provid-
ing excellent sound at a pleasant volume. By pressing the Mic key, the chairman can
make a comment any time. At multi-lingual conferences, the translated languages
can be listened to via headphones. The SDC 8000 CV chairman's unit features chip
card identification and allows to start and stop votings. The results are conveniently
displayed on the unit's LCD display.
Features
Built-in high-quality loudspeaker (automatically muted when the
microphone is switched on)
Microphone on/off key
Gooseneck microphone with red LED ring
Priority key for switching off all live microphones
Two RJ 45 sockets for connecting up to 15 units in one cable line
Two 3.5 mm headphone jacks for headphones or induction couplers
for the hearing impaired
Headphone volume control
Channel selection keys with numerical display of selected channel
(floor language + up to 28 translations)
Five voting keys with LED
Selection of voting mode, voting start/stop, display of results
Back-lit graphic LCD display (122 x 32 dots)
Built-in chip card reader for chairman identification
Delivery includes: 1 SDC 8000 CV Chairman's Unit
Accessories
RJ 45 conference bus cables, type 24 AWG,
available lengths: 2 m, 3 m, 5 m, 10 m, 20 m, 50 m
HD 410-D, HD 1029 headphones
SDC 8000
Technical Data
Frequency response ................................. 100 – 14,000 Hz
Pick-up pattern .........................................................cardioid
Headphone connector.................. 3.5 mm mono (> 32 Ω)
Power supply.............................................................. 48 V DC
Power consumption............................................max. 4.2 W
Operating temperature .........................................0 – 50 °C
Standards..................................................................... IEC 849
Colour..........................................................Pantone Black 7C
Housing .............................................................................. ABS
Dimensions ............................................ 150 x 80 x 185 mm
Gooseneck length .................................................... 380 mm
Weight ............................................................................. 650 g
Cat. No. 009417
