- Page 1 Industry Acoustic System IAS-MO 2000 Set Instructions for use +/- 15dB OVERLOAD LEVEL GAIN...
-
Page 3: Table Of Contents
Setting up the device ... 7 Rack mounting ... 7 Connecting the mains unit ... 8 Connecting the amplifier ... 8 Connecting the optical microphone ... 9 Switching the central unit on/off ... 11 Adjusting the sensitivity ... 11 Overload indication ... 11 Disassembling the weather and wind protection ... -
Page 4: Safety Instructions
Use of the MO 2000 H optical microphone When installed in the MZWW 2000 weather and wind protection, the MO 2000 H optical microphone meets the IP 54 standard for dust and mois- ture resistance. In combination with the MZWW 2000, the optical microphone... - Page 5 (e.g. amplifiers). Keep the device away from direct sunlight and similar sources of heat. Only use attachments/accessories specified by Sennheiser. Use the device in dry rooms only. Do not expose the device to dripping or splashing and ensure that no objects filled with liquids, such as vases or coffee cups, are placed on the device.
-
Page 6: Ias-Mo 2000 Set
MO 2000 CU central unit. Power is supplied via an external wide voltage range power supply unit. The MO 2000 H is an omni-directional microphone designed for picking up air- borne sound. The components of the MO 2000 H microphone head (outside... -
Page 7: Delivery Includes
LEVEL Windshield basket Delivery includes IAS-MO 2000 Set 1 MO 2000 H optical microphone with 3 m fiber optic cable 1 MO 2000 CU central unit 1 mains unit with different country adapters 1 GA 2 rack adapter 1 carrying case... -
Page 8: Product Overview Ias-Mo 2000 Set
DC socket for connection of power supply unit (DC IN) Audio output (AF OUT BAL), XLR-3M, balanced Audio output (AF OUT UNBAL), BNC socket, unbalanced Type plate SC optical input for microphone SC optical output for microphone Optical microphone SC duplex connector... -
Page 9: Putting The System Into Operation
Putting the system into operation Risk of staining of furniture surfaces! CAUTION! Some furniture surfaces have been treated with varnish, polish or synthetics which might cause stains when they come into contact with other synthetics. Despite a thorough testing of the synthetics used by us, we cannot rule out the possibility of staining. -
Page 10: Connecting The Mains Unit
AF OUT BAL/UNBAL DC IN 12V/150mA LEV 6dBu MAX AF OUT BAL/UNBAL DC IN LEV 6dBu MAX 12V/150mA To mount two central units into a rack: Place the two central units side by side upside-down onto a flat surface. Align the jointing plate units. -
Page 11: Connecting The Optical Microphone
Connecting the optical microphone CAUTION! CAUTION! CAUTION! Before connecting the optical microphone, remove the protections caps from the microphone connections protection caps in a safe place for reuse during transport or storage. They protect the microphone connections against dirt. Connect the duplex connector of the professionally ready-made cable to... - Page 12 Connecting the optical microphone to the weather and windshield Remove the windshield basket and open the flap in the pipe as shown. Remove the protection caps from the connectors of the fiber optic cable Push down the plastic housing on an even base until the housing detaches from the connectors with an audible click.
-
Page 13: Switching The Central Unit On/Off
If the power supply is interrupted for several seconds (e.g. due to a power failure), the device switches on automatically even if it was switched off before. Adjusting the sensitivity With the microphone connected and both the gain switch control Use the gain switch (tenfold increase) or 40 dB (hundredfold increase). -
Page 14: Disassembling The Weather And Wind Protection
Disassembling the weather and wind protection Accessories Cat.-No. Accessory 009823 GA 2 rack adapter 525700 MO 2000 H optical microphone 525701 MO 2000 CU central unit 525702 Pipe 522170 SCRJ-GOF socket (inside the MZWW 2000) 522168 Cover with gasket 522169... -
Page 15: Care And Maintenance
Care and maintenance Danger to life! WARNING! Repairs to explosion-proof components are not allowed. If you repair explosion-proof components yourself, this presents an explosion hazard. Refer all repairs to the manufacturer. Liquids can damage the electronics of the MO 2000 CU central CAUTION! unit! Liquids entering the housing of the device can cause a short-... -
Page 16: Specifications
0 dB) approx. 330 Ω unbalanced/660 Ω balanced 1.55 V 0°C to +40°C –20°C to +70°C MO 2000 H microphone head with 3 m fiber optic cable omni-directional ± 20 Hz to 40 kHz (... -
Page 17: Connector Assignment
AF cable Design Connector assignment DC connector for mains unit Frequency response curve multimode 200/230 μm approx. 3–4 dB per 100 m socket/socket type SC 5–6 dB per coupling pair balanced microphone cable with shielding XLR-3F connector, balanced 50k Hz... -
Page 18: Manufacturer Declarations
Manufacturer Declarations Warranty Sennheiser GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our web site at www.sennheiser.com or contact your Sennheiser partner. CE Declaration of Conformity 0044 This equipment is in compliance with the essential requirements and other relevant provisions of Directives 94/9/EC, 2004/108/EC, and 2006/95/EC. - Page 20 Sennheiser electronic GmbH & Co. KG Am Labor 1 30900 Wedemark, Germany Phone +49 (5130) 600 0 Printed in Germany Fax +49 (5130) 600 300 Publ. 08/08 www.sennheiser.com 524194/A01...
