Sennheiser Evolution 004519 Specification Sheet

Microphones |
General Description
The e 604 is a cardioid microphone especially suitable for use with drums
and brass instruments.
Features
Rugged reinforced glass-fibre body
Low sensitivity to impact and handling noise
Very high sound pressure handling capability
Hum compensating coil
Easy to position due to compact design
Integral stand mount
Delivery includes: 1 e 604
1 drum clip
1 pouch
1 Instructions for use
1 Warranty Certificate
evolution
Technical Data
Transducer principle ..............................................................dynamic
Pick-up pattern .......................................................................cardioid
Frequency response ................................................. 40 – 18,000 Hz
Sensitivity (free field, no load, 1 kHz) ...........................1.8 mV/Pa
Nominal impedance ................................................................. 350
Min. terminating impedance ..................................................... 1 k
Dimensions ...................................Ø 33 x 59 mm (Ø 1.30˝ x 2.32˝)
Weight .........................................................................60 g (2.12 oz)
Profile
Cardioid instrument microphone, hum compensating coil,
frequency response 40 Hz – 18 kHz, sensitivity (free field, no
load) 1.8 mV/Pa at 1 kHz, nominal impedance 350
terminating impedance 1 k , dimensions Ø 33 x 59 mm
(Ø 1.30˝ x 2.32˝), weight 60 g (2.12 oz).
Cat. No. 004519
, min.
e 604
