Applicant: Shintom Co., Ltd.
Transmitter Type: BFYT3017
EXHIBIT 20
PAGE 1 OF 52

Advertisement

Table of Contents
loading

Related Manuals for Audiovox TR93

Summary of Contents for Audiovox TR93

  • Page 1 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 EXHIBIT 20 PAGE 1 OF 52...
  • Page 2 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Important There are some basic rules that apply to most hardware installation procedures and need to be observed to prevent damage or injury. Always make sure that any power is disconnected to the vehicle before handling any electrical components like wiring, fuseboxes, connectors, etc.
  • Page 3 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 2. Mount the Transceiver unit To install the cellular telephone with the transceiver unit located in the trunk-space of the automobile follow the steps outlined below. a. Place the mounting bracket so that the four bracket holes line up with the trans- ceiver holes.
  • Page 4 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 4. Mount the Cradle and Handset a. Using a pedestal mount. The cradle unit can be mounted as displayed. Be sure to use only supplied M4 × 10mm screws. Using improper screws will damage the cradle unit.
  • Page 5 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 5. Antenna The following is the standard antenna installation for TR93. Antenna type : Glass mount type - Colinear Mount location : Rear window of a vehicle Antenna cable : RG-58/U 8 feet (2.44m) or longer Install the antenna on your vehicle as shown below.
  • Page 6 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 OPERATING INSTRUCTIONS 555 Wireless Blvd., HAUPPAUGE, NY 11788 MOBILE CELLULAR TELEPHONE TR93 PRINTED IN XXXX x-xx EXHIBIT 20 288Exxxx PAGE 6 OF 52...
  • Page 7 Programmable One Touch Emergency Dialing, Anti-Fraud Se- curity Features, Automatic Call Retry, a Constant Signal Strength Indicator. And of course, your new Audiovox TR93 comes with something only an Audiovox phone can provide The proven reliability that has made Audiovox one of the world's leading suppliers of cellular communications equipment.

  • Page 8: Table Of Contents

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 TABLE OF CONTENTS INTRODUCTION ..........3 Safety Information for Wireless Handheld Phones ....3 Features .................. 7 Key/Display Names and Functions ........8 INSTALLATION ..........10 Cautions ................10 Parts List ................11 BASIC OPERATION ........
  • Page 9 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Recalling Numbers from Memory ........24 Memory Dialing ............... 24 Dialing after Telephone Number Search ......25 Dialing after Name Search ..........25 Speed Dialing ..............25 Link Dialing ................. 26 Storing Number in Link Dialing Memory ......26 Recalling Number from Link Dialing Memory ....

  • Page 10: Introduction

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 INTRODUCTION SAFETY INFORMATION FOR MOBILE PHONES IMPORTANT READ THIS INFORMATION BEFORE USING YOUR MOBILE CELLULAR TELEPHONE The cellular telephone is one of the most exciting and inno- vative electronic products ever developed. With it you can stay in contact with your office, your home, emergency ser- vices, and others.
  • Page 11 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 higher power level than necessary, and expose that person to RF energy in excess of that established by the updated ANSI Stan- dard. For best call quality, keep the antenna free from obstructions and point it straight up.
  • Page 12 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Turn your phone OFF in health care facilities when any regu- lations posted in the areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy. AIRCRAFT Turn your phone OFF before boarding any aircraft.
  • Page 13 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Vehicles using liquefied petroleum gas (such as propane or butane) must comply with the National Fire Protection Stan- dard (NFPA-58). For a copy of this standard, contact the National Fire Protection Association, One Batterymarch Park, Quincy, MA 02269, Attn.: Publications Sales Division.

  • Page 14: Features

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 FEATURES • SID management (programmable option) • Multiple city registration • Easy to read LCD display with alphanumeric and status indi- cators • Back-lit keypad and LCD display • Microphone mute control • Priority/emergency calling with automatic retry •...

  • Page 15: Key/Display Names And Functions

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 KEY/DISPLAY NAMES AND FUNCTIONS System A Indicator1 62-digit Display System B Indicator2 7ROAM Indicator Received Signal 8 Function Mode Strength Indicator Indicator IN USE Indicator4 Mute Indicator5 914-digit Display 0Message Indicator B End Key Send Key A G One Touch Dial, Mute, and Alpha Key...
  • Page 16 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 1 A lights when the system A (non-wireline) is selected. 2 B lights when the system B (wireline) is selected. Note: AB lights when standard mode is selected. 3 Received Signal Strength Indicator Yi constantly displays the signal strength represented by the number of bars.

  • Page 17: Installation

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 TRANSCEIVER CONNECTIONS Antenna Terminal Power Cable Socket Microphone Unit Jack Curly Cord Socket INSTALLATION CAUTIONS: • Always make sure that any power is disconnected to the vehicle before handling any electrical components like wiring, fuseboxes, connectors, etc.

  • Page 18: Parts List

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 PARTS LIST Your TR93 Kit consists of following parts. Please also refer to the Optional Parts List. 1. Transceiver unit 2. Handset (TH93) (TR93) 4. Curly cord * (CC91) 3. Cradle 5. Power cable 6.
  • Page 19 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 11. Screw kit (SKM46) ( SKM410 ) (SKM435) 12. Hands-free microphone EXHIBIT 20 PAGE 19 OF 52...

  • Page 20: Basic Operation

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 BASIC OPERATION Removing your Replacing your Handset Handset TURNING YOUR PHONE ON AND OFF Your phone will be switched on or off with the vehicle's DC power as you turn the ignition key. If your phone remains off after switching on ignition (or vice versa), press and hold p.

  • Page 21: Call-In Progress Protection

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Example: To call 123-4567 1. Enter 123456 YiAB 2. Press s. 1234567 Talk with the other party. 3. To terminate the call, press e. To Correct Entered Digits: • Press c to erase the last digit entered. •...

  • Page 22: Automatic Answering

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 To Activate the Silent Incoming Calls: Press f, 8. Silent Alert on” will be displayed. “ To clear the display, press c. To Deactivate the Silent Incoming Calls: Press f, 8 again. Silent Alert oF”...

  • Page 23: Automatic Redial (Programmable Option)

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 2. Press s for redialing. Automatic Redial (Programmable Option) If Automatic Redial is selected, your phone will automati- cally continue redialing in 20 seconds if the attempt to reach the cell site is not successful. The I indicator will stay on, but the earpiece speaker will be muted.

  • Page 24: Enhanced Operation

    Your phone will receive calls normally even if it is locked. Locking the Phone 1. Press f, 5. 2. Enter the 3-digit Unlock code. Notes: • Please contact your selling Audiovox dealer to check the initial Unlock code. Locked • If your phone is locked, “...

  • Page 25: Keypad Disable Function In Handsfree Mode (Programmable Option)

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 KEYPAD DISABLE FUNCTION IN HANDSFREE MODE (PROGRAMMABLE OPTION) This function prevents accidental or unintentional use of the keypad in handsfree mode. When this function is activated by Programmable option, no key operations in handsfree mode are possible. The display shows “...

  • Page 26: Storing In The Memory

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 STORING IN THE MEMORY You can store telephone numbers and names in 89 memory locations. Maximum 32 digits and 7 characters each can be stored in locations 1 to 20. Maximum 16 digits and 7 char- acters each can be stored in locations 21 to 89.

  • Page 27: Manual Storage

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 The following example shows how to enter the name JOHN. You can learn the characters behind the digit keys and how to move the characters with the cursor keys. Note this ex- ample illustrates how to enter a name but not actually store the name.
  • Page 28 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 The following examples show how to store the telephone number together with name, as well as how to store tele- phone number alone. Example 1: To store telephone No. 123-4567 with name JOHN in memory location No. 10 1.

  • Page 29: Automatic Storage

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Automatic Storage You can automatically store telephone numbers and names in vacant memory locations. (You may choose to omit names.) 1. Press c, then enter the telephone number. 2. Enter the name. 1) Press f, .

  • Page 30: Editing The Telephone Numbers And Names

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Example: To store telephone No. 456-7890 with name JOHN in the vacant memory location No. 13 , then enter 4567890. 1. Press 2. Enter the name. 1) Press f m. “ALPHA?” will blink. 2) Enter the name with the name entry keys.

  • Page 31: Editing The Names

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Editing the Names To edit the name of location No. XX (1-89), follow the next steps. , and enter x/xx. 1. Press 2. Press f, 3. Edit the name with the name entry keys. 4.

  • Page 32: Dialing After Telephone Number Search

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Example: To place a call using memory location No. 10 1. Press YiAB 2. Enter 10. JOHN 3. Press s. 1234567 Dialing after Telephone Number Search You can scan, recall and dial numbers stored in memory lo- cations 1 through 89.

  • Page 33: Link Dialing

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 LINK DIALING When you receive service such as Voice Mail from your cel- lular service provider, you can dial a number and make Link Dialing with key only. Five Link Dialing Memories (M1 to M5) are provided with your phone.

  • Page 34: One Touch Dialing

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 ONE TOUCH DIALING You can place a call with key after storing a telephone number in the one touch memory assigned to key. Storing in the One Touch Memory 1. Press c, then enter a telephone number. 2.

  • Page 35: Scratch Pad Memory

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 SCRATCH PAD MEMORY As a sort of numerical note pad, you can enter up to 7 en- tries in special memory locations (memory locations 90 to 96) of up to 32 digits each. Also, you can place a call from the scratch pad memory.

  • Page 36: Extended Features And Functions

    To Activate Call Restriction 1. Press f, *, 5. 2. Enter the 3-digit Call Restriction code. Note: Please contact your selling Audiovox dealer to check the initial Call Restriction code. “CR” will be displayed to indicate that call restriction is in effect.

  • Page 37: Keypad (Dtmf) Tones

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 CAUTION: Keep the record of new code in a safe place! Note: If you enter a wrong code in step 2, your phone returns to standby mode. KEYPAD (DTMF) TONES Dual Tone Multi-Frequency (DTMF), or “Keypad Tone” sig- nals can be transmitted during a call by entering digits on the keypad or recalling numbers from the memory.

  • Page 38: Outgoing Call Timer

    You can display your outgoing call time. 1. Press f, *, 3, 1. 2. Enter the 2-digit Call Timer code. Note: Please contact your selling Audiovox dealer to check the initial Call Timer code. “Outgo-T hhhh:mm” will be displayed. (hhhh: Hours, mm: Minutes) To exit this mode, press c.

  • Page 39: Outgoing Call Counter

    You can check the accumulated number of outgoing calls. 1. Press f, *, 2, 1. 2. Enter the 2-digit Call Counter code. Note: Please contact your selling Audiovox dealer to check the initial Call Counter code. “Outgo-C XXXX” will be displayed. (XXXX: Number of outgoing calls) To exit this mode, press c.

  • Page 40: Call Time Warning Tone

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Call Time Warning Tone You can turn the Call Time Warning Tone on and off. When it is set to on, a single warning tone will be heard every 1 minute and a double warning tone will be heard every 5 minutes during a call.

  • Page 41: Multiple City Registration

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Standard Mode: Your phone will scan the preferred system channels. If un- able to find an acceptable preferred channel, your phone switches to scan the non-preferred system channels. “A B” will light in the display. System A Only Mode: Your phone will scan the system A only.

  • Page 42: Current Sid, Channel And Rssi Level Display

    To Enter the PIN and Turn the PIN Feature ON or OFF: 1. Press f, #, *. 2. Enter the 3-digit Unlock code. Note: Please contact your selling Audiovox dealer to check the initial Unlock code. 3. Enter your PIN (up to 6 digits).

  • Page 43: Function Review

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 FUNCTION REVIEW To Review the Function Menus: 1. Press f, then ^ or v. “FNC Review” will be dis- played. 2. Press ^ or v to scroll up or down the function menus. 3.
  • Page 44 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Display Function FNC *4 One touch emergency call selection 1-Touch Emerg. FNC *5 Call restriction mode selection Call Restr. FNC *6 Current SID, RF Channel Display RSSI and RSSI level display FNC *20 Temporarily accumulated call Call Counter counter display...
  • Page 45 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 Display Function FNC #53 Call counter access code change Change C-Count FNC #54 Call timer access code change Change C-Timer FNC #* PIN entry mode Change PIN FNC ## Multiple city registration (phone Multi Reg.
  • Page 46 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 and use ^/v “VOICE MAIL” will blink. Press keys to display the number of received Voice Mail. • When Voice Mail Message is received during alert or con- versation, Voice Mail Number or number of received Voice Mail is displayed.
  • Page 47 Many companies are making look-alike accessories and in some cases, promoting that their product is equal to or bet- ter than the Audiovox product. Be careful. Some of these products may not be compatible for use with your Audiovox product and may damage the unit or cause it to malfunction.

  • Page 48: General Specifications

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 GENERAL SPECIFICATIONS Frequency Range: Transmit: 824.040 to 848.970 MHz Receive: 869.040 to 893.970 MHz Number of RF Channels: 832 Channels, Full Duplex Channel Spacing: 30 KHz Duplex Spacing: 45 MHz Frequency Stability: ±2.5 PPM Operating Temperature: Main Unit: –22°F to +140°F (–30°C to +60°C)

  • Page 49: Table Of Key Operation

    Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 TABLE OF KEY OPERATION KEY OPERATION Function Holding p turns your phone on and off. Stores to Scratch Pad Memory. Phone No.+f+1 f+3 (During conversation) Turns the DTMF tone on and off. f+5+3 Digit Code Locks your phone electronically.
  • Page 50 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 KEY OPERATION Function f+*+5 Activates the Call Restriction +3 Digit Code mode. f+*+6 Displays the current SID, current Channel and the RSSI Level. f+*+9+0 Adjusts the earpiece volume +^/v level. f+*+9+1 Adjusts the alert sound output +^/v volume level.
  • Page 51 Applicant: Shintom Co., Ltd. Transmitter Type: BFYT3017 KEY OPERATION Function Phone No.+f+ Stores the telephone number in +Memory Location No. the memory. Phone No.+f+ Stores the telephone number +Name.+f+ and the alphanumeric informa- +Memory Location No. tion in the memory. Phone No.+f+ Searches the vacant memory and stores the telephone num-...

  • Page 52: 12 Month Limited Warranty
