O
rdering Information
Table 6: Ordering Information
Item
S350A Temperature Stage
Module
S351A Humidity Stage Module
S352A Pressure Stage Module
S
pecifications
Product
Input Voltage
Power Consumption
Output Relay Electrical
Ratings
Differential Adjustment
Range
Offset Range
Ambient Temperature
Ambient Humidity
Material
Mounting
Agency Listing
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult Johnson Controls/Penn Application Engineering at (414) 274-5535. Johnson Controls, Inc. shall not be liable for
damages resulting from misapplication or misuse of its products.
Controls Group
507 E. Michigan Street
P.O. Box 423
Milwaukee, WI 53201
8
S350A Temperature, S351A Humidity, and S352A Pressure Stage Modules Product/Technical Bulletin
Product Code
Description
Number
S350AA-1C
Temperature Stage Module with Fahrenheit Scale
S350AB-1C
Temperature Stage Module with Celsius Scale
S351AA-1C
Humidity Stage Module with percent RH Scale
S352AA-2C
Pressure Stage Module with psi Scale
S350AA:
Temperature Stage Module with Fahrenheit Scale
S350AB:
Temperature Stage Module with Celsius Scale
S351AA:
Humidity Stage Module with Percent RH Scale
S352AA-2:
Pressure Stage Module with psi Scale
S350AA:
Provided by the A350
S351AB:
Provided by the W351
S352AA-2:
Provided by the P352AB
1.0 VA maximun
SPDT Enclosed Relays
10 Ampere Non-inductive, 125 VA Pilot Duty, 24/240 VAC
1/2 hp 120/240 VAC
S350AA:
1 to 30F°
S350AB:
0.5 to 17C°
S351AA:
2 to 10% RH
S352AA-2:
2 to 50 psi
S350AA:
1 to 30F°
S350AB:
0.6 to 16.7C°
S351AA:
2 to 30% RH
S352AA-2:
2 to 50 psi
Operating:
-30 to 150°F (-34 to 66°C)
Shipping:
-40 to 185°F (-40 to 85°C)
0 to 95% RH (Non-condensing)
Case, Cover: NEMA 1 High Impact Thermoplastic
Wall or DIN Rail
UL Listed, CCN XAPX, File E27734
UL Listed for Canada, CCN XAPX7, File E27734
Printed in U.S.A.
www.johnsoncontrols.com
