Fisher & Paykel E331T Operating Instructions

Download this manual

Operating instructions

Details many of the operating instructions and information regarding temperature control, sabbath mode, and refrigerator

sounds.

635 mm wide

Models:

680 mm wide

790 mm wide

• When the refrigerator is first turned on, the powerful cooling system will automatically cool both refrigerator and

freezer compartments to their set temperatures. This will take between 2 – 3 hours.

• The two compartment temperatures are accurately and independently controlled and do not change with the

temperature or humidity of the surroundings; whether summer or winter.

• If you wish to alter the temperature of either the fresh food compartment or freezer compartment, this can be

easily done by using the control panel located at the back of the fresh food compartment.

https://producthelp.fisherpaykel.com/nz/Cool/Freezers/Chest/H360XWH/User_Guide_H360XWH/ActiveSmart_refrigerators/01_Operating_

E331T, E381T, E411T, E415H

E440T

E521T, RF521T

Updated: Fri, 01 Mar 2019 05:39:49 GMT

Table of Contents

Page 1: Operating Instructions
Operating instructions Details many of the operating instructions and information regarding temperature control, sabbath mode, and refrigerator sounds. 635 mm wide E331T, E381T, E411T, E415H Models: 680 mm wide E440T 790 mm wide E521T, RF521T Temperature control • When the refrigerator is first turned on, the powerful cooling system will automatically cool both refrigerator and freezer compartments to their set temperatures.
Page 2: Fresh Food Compartment
Control panel to adjust temperatures Fig.4 Control panel Fresh food compartment • The fresh food compartment light on the refrigerator diagram will be showing. The temperature indicator illustrated by a thermometer will show the temperature setting for this compartment as a series of lights. •...
Page 3: Sabbath Mode
Successively pressing the button will automatically scroll between the compartments, a return to the fresh food compartment will be accompanied by a longer beep. • When the door is re-opened the control panel will return automatically to the fresh food compartment setting. Sabbath mode •...
Page 4 • Running water sound. This is the liquid refrigerant in the system and can be heard as a boiling or gurgling noise. • An audible hissing sound after closing the freezer door. This is due to the pressure difference between the warm air that has entered the cabinet and suddenly cooled, and the outside air pressure.

E381t E415h E411t E440t E521t Rf521t
