- Page 1 Installation and User's Manual Models C1448, C1848, C2148W...
-
Page 2: Table Of Contents
Introduction The design of this modular cuber is the result of years of experience and testing. Standard features include front accessible indicator lights and on-off switches that provide the user with fast access to critical information and easy operational control. When desired, optional controls can add features like ultrasonic bin ice level sensing, seven day programmable bin ice level setting, remote lock out... -
Page 3: Installation: Product Specifications
C1448, C1848, C2148W Air and Water Cooled User Manual Installation: Product Specifications Location Limitations: The product is designed to be installed indoors, in a controlled environment. Air cooled models discharge very warm air into the room out the back. Space must be allowed at the left side and back for air intake and discharge. -
Page 4: Product Information
Other Bins & Applications: Note the drop zone and ultrasonic sensor locations in the illustrations. Scotsman ice systems are designed and manufactured with the highest regard for safety and performance. They meet or exceed the standards of UL and NSF. -
Page 5: Product Description & Electrical Requirements
C1448, C1848, C2148W Air and Water Cooled User Manual Product Description & Electrical Requirements Dimensions Model w” x d” x h” 48 x 24 x 29 C1448SA-32 same C1448SW-32 same C1448SA-3 same C1448SW-3 same C1848SA-32 same C1848SW-32 same C1848SA-3 same C1848SW-3 same C2148SW-32... - Page 6 C1448, C1848, C2148W Air and Water Cooled User Manual Cabinet Layout, Air Cooled November 2006 Page 5...
- Page 7 C1448, C1848, C2148W Air and Water Cooled User Manual Cabinet Layout, Water Cooled November 2006 Page 6...
-
Page 8: Water
Water The quality of the water supplied to the ice machine will have an impact on the time between cleanings and ultimately on the life of the product. There are two ways water can contain impurities: in suspension or in solution. Suspended solids can be filtered out. -
Page 9: Panel Removal
C1448, C1848, C2148W Air and Water Cooled User Manual Panel Removal Locate and loosen the two screws at the front edge of the top panel. Pull the front panel out at the top until it clears the top panel. Lift the front panel up and off the machine. Remove two screws at front edge of top panel. -
Page 10: Uncrate And Set Up
Uncrate and Set Up Begin with unpacking the ice storage bin. Remove the carton, and using part of the carton as a cushion, tip the bin on its back to remove the skid and attach the legs or casters. Note: Turn the leg levelers in all the way and adjust after the ice machine is on top and in its selected location. -
Page 11: Plumbing Requirements
C1448, C1848, C2148W Air and Water Cooled User Manual Plumbing Requirements All models require connection to cold, potable water. A hand actuated valve within site of the machine is required. Air cooled models have a single 3/8” FPT inlet water connection, a 3/8” FPT to 3/8”... -
Page 12: Drains
Drains All models require drain tubing to be attached to them. Air cooled models have a single ¾” FPT drain fitting in the back of the cabinet. Water cooled models have the same fitting plus an additional ½” FPT drain fitting in the back of the cabinet. Install new tubing when replacing a prior ice machine, as the tubing will have been sized for the old model and might not be correct for this one. -
Page 13: Electrical
C1448, C1848, C2148W Air and Water Cooled User Manual Electrical The machine is not supplied with a power cord, one must either be field installed or the machine hard-wired. The dataplate on the back of the cabinet details the power requirements, including voltage, phase, minimum circuit ampacity and maximum fuse size. -
Page 14: Final Check List
Final Check List After connections, Wash out the bin. If desired, the interior of the bin could be sanitized. Locate the ice scoop (if supplied) and have it available for use when needed. Final Check List: Is the unit located indoors in a controlled environment? Is the unit located where it can receive adequate cooling air? -
Page 15: Initial Start Up
C1448, C1848, C2148W Air and Water Cooled User Manual Initial Start Up Remove front panel. Check machine for any packing or wires rubbing moving parts. Note location of control board in upper left corner of the machine’s front. Remove tape securing each curtain to its evaporator. -
Page 16: Adjustments
Adjustments Bridge Thickness - For Service Tech Only Push and hold Off till the machine stops. Remove evaporator cover. Remove curtain. Use a box wrench and rotate the bridge thickness adjustment screw in 1/8 turn increments CW to increase bridge thickness. Rotate CCW to decrease bridge thickness. -
Page 17: Water Flush Setting
C1448, C1848, C2148W Air and Water Cooled User Manual Water flush setting The water flush is factory set to the automatic position, suitable for most water conditions. The setting can be changed to one of 5 manual settings or left on automatic. Flush setting Minimum... -
Page 18: Use And Operation
Use and Operation Once started, the ice machine will automatically make ice until the bin or dispenser is full of ice. When ice level drops, the ice machine will resume making ice. Caution: Do not place anything on top of the ice machine, including the ice scoop. -
Page 19: Switches
C1448, C1848, C2148W Air and Water Cooled User Manual Switches The two switches – on and off - can be accessed from the front of the machine. Status De-Scale Power Water • To switch the machine OFF, push and release the Off button. The machine will shut off at the end of the next cycle. -
Page 20: Options And Other Information
Options and Other Information SmartBoard When this option is present there is an additional display panel in the area below the main control board. It is not visible when the front panel is on. The SmartBoard’s features include: • Seven day programmable ice level setting when used with the optional Vari-Smart ice level control •... -
Page 21: Cleaning, Sanitation And Maintenance
C1448, C1848, C2148W Air and Water Cooled User Manual Cleaning, Sanitation and Maintenance This ice system requires three types of maintenance: • Remove the build up of mineral scale from the ice machine’s water system and sensors. • Sanitize the ice machine’s water system and the ice storage bin or dispenser. •... - Page 22 13 Remove water distributors from ice machine. Inspect each distributor for restricted orifice holes. Be sure all holes are full open. Squeeze Tabs Together, Slide Out Until it Stops, Then Lift to Remove Remove Water Distributors Inspect Orifice Holes Inspect Water Distributor 14 Locate ice thickness sensor.
-
Page 23: Air Cooled Condenser Filter
C1448, C1848, C2148W Air and Water Cooled User Manual Air cooled condenser filter Pull air filters from their louvered mounts. Wash the dust and grease off the filter. Return them to their original positions. Do not operate the machine without the filter in place except during cleaning. -
Page 24: What To Do Before Calling For Service
What to do before calling for service Reasons the machine might shut itself off: • Lack of water. • Freeze cycle takes too long. • Harvest cycle takes too long. • High discharge temperature. • Controller self test failure. Check the following: 1. - Page 25 SCOTSMAN ICE SYSTEMS 775 Corporate Woods Parkway, Vernon Hills, IL 60061 800-533-6006 www.scotsman-ice.com 17-3083-02...
