Sony ICF-F10 Operating Instructions

FM/AM Radio

Operating Instructions

使用說明書 (背面)
ICF-F10
© 2007 Sony Corporation
Telescopic antenna
A
3-798-717-31(1)
Printed in China
Insert the E side of the battery first.
English
Features
• High power radio
• Long battery life with two R20 (size D) batteries.
• Easy to carry with the supplied carrying strap.
Installing the
Batteries
(see fig. A)
1
Open the lid of the battery case.
2
Insert the batteries with correct polarity.
3
Close the lid.

Battery life

Using Sony batteries R20 (size D):
FM: Approx. 200 hours
AM: Approx, 220 hours
Replacing batteries
When the sound becomes weak or distorted, replace
all the batteries with new ones.
Note
When the unit is not to be used for a long period of
time, remove the batteries to avoid damage caused by
battery leakage and corrosion.

Operating the Radio

1
Set FM/AM/OFF to "FM" or "AM."
Power is turned on.
2
Tune in a station using TUNING.
3
Adjust the volume using VOLUME.
To turn off the radio
Set FM/AM/OFF to "OFF."
To listen with an earphone
(not supplied)
When an earphone is connected to the v jack, the
sound through the speaker cannot be heard.
Improving the
Reception
FM: Extend the telescopic
antenna and adjust
the length and the
angle for the best
reception.
AM: Since the reception is
affected by the
direction of the radio,
rotate the radio
horizontally for
optimum reception.
Attaching the
Supplied Carrying
Strap
When you carry the unit, use the supplied carrying
strap.
Pass the strap under the bar on each side of the radio.
Pass the strap through the buckle.
Precautions
• Do not open the unit. Refer servicing to qualified
personnel only.
• Operate the unit only on 3 V DC with two R20 (size
D) batteries.
• Avoid exposure to temperature extremes, direct
sunlight, moisture, sand, dust, or mechanical shock.
Never leave in a car parked in the sun.
• Should any solid object or liquid fall into the unit,
remove the batteries, and have the unit checked by
qualified personnel before operating it any further.
• Since a strong magnet is used for the speaker, keep
personal credit cards using magnetic coding or
spring-wound watches away from the unit to prevent
possible damage from the magnet.
• When the casing becomes soiled, clean it with a soft
cloth dampened with mild detergent solution. Never
use abrasive cleansers or chemical solvents, as they
may mar the casing.
• In vehicles or in buildings, radio reception may be
difficult or noisy. Try listening near a window.
If you have any questions or problem concerning your
unit, please consult the nearest Sony dealer.

Specifications

Frequency range
FM: 87.5 – 108 MHz
AM: 530 – 1 605 kHz
Speaker
Approx. 9.2 cm dia.
Power output
300 mW (max.)
Output
v (earphone) jack (ø 3.5 mm mini jack)
Power requirements
3 V DC, two R20 (size D) batteries
Dimensions
Approx. 206 × 131 × 66 mm (w/h/d) incl.
projecting parts and controls
Mass
Approx. 673 g incl. batteries
Supplied accessories
Carrying strap (1)
Operating Instructions (1)
Design and specifications are subject to change
without notice.
