- Page 1 Domestic 70 Stitch Sewing Machine Operating Instructions Model No. SB700 SMT081313...
-
Page 2: Table Of Contents
Contents Safety instructions 03-04 Component identi cation 05-06 Accessories Fitting the snap-in sewing table Connecting machine to the power source Two-step presser foot lever Attaching the presser foot holder Winding the bobbin Inserting bobbin Changing the needle Threading the upper thread Automatic needle threader Thread tension Bringing up the lower thread... -
Page 3: Safety Instructions
Safety instructions When using an electrical appliance, dropped or damaged or dropped into basic safety precautions should water. always be followed, including the following: 4. Never operate this appliance with Read all instructions before using this any air openings blocked. Keep sewing machine. -
Page 4: Safety Instructions
Safety instructions 11. Never drop or insert any object into any opening. 12. Do not use outdoors. 13. Do not operate where aerosol spray products are being used or where oxygen is being administered. 14. To disconnect, turn all controls to the o (”O”) position, then remove plug from outlet. -
Page 5: Component Identi Cation
Component identi cation (Part 1) Thread tension dial Bobbin stopper Presser foot pressure Stitch length dial Thread take-up lever Stitch width dial Thread cutting Stitch display Presser foot Reverse sewing lever Needle plate Automatic threader (optional) Sewing table and accessory box... - Page 6 Component identi cation (Part 2) Upper thread guide Power switch Presser foot lever Main plug socket Handle Bobbin thread guide Bobbin winder Spool pin Handwheel Pattern selector dial...
-
Page 7: Accessories
Accessories Standard Accessories (1) Optional Quilting Package (2) 4 step buttonhole foot Zipper foot with double edge L shape screwdriver Button sewing foot Seam ripper/brush Blind hem foot Lubricate oil Hemmer foot #14 needle x 3pcs (ORGAN brand) Quilting foot Bobbins x 3pcs in total Stain stitch foot Twin needle... -
Page 8: Fitting The Snap-In Sewing Table
Fitting the snap-in sewing table Hold the snap-in sewing table horizontal, and push it in the direction of the arrow. (Fig.1) The inside of the snap-in sewing table can be utilized as an accessory box. To open, lift up at the point of the arrow. -
Page 9: Connecting Machine To The Power Source
Connecting machine to power source CAUTION: Always make sure that the machine is unplugged from power source and the main switch is on (O ) “0” when the machine is not in use and before inserting or removing parts. - This machine is equipped with polarized plug which must be used with an appropriate electrical outlet. -
Page 10: Two-Step Presser Foot Lever
Two-step presser foot lever When sewing several layers or thick fabrics, the presser foot can be raised a second stage for easy positioning of the work. (A) The presser foot pressure of the machine has been pre-set and requires no particular readjustment according to the type of fabric (light or heavy weight). -
Page 11: Attaching The Presser Foot Holder
Attaching the presser foot holder ATTENTION: Turn power switch to “0” before carrying out any of the operations below. Raise the needle to its highest position and raise the presser foot lever. Attach the presser foot holder (b) to the presser foot bar (a). (1) Attaching the presser foot: Lower the presser foot holder (b) until the cut-out (c) is directly above the pin (d). -
Page 12: Winding The Bobbin
Winding the bobbin Place an empty bobbin winder spindle. Take the thread from the spool through the bobbin winder tension disc. (1) Wind the thread a few times by hand around the empty bobbin in a clockwise direction. Push the bobbin to the right towards the bobbin winding position. -
Page 13: Inserting Bobbin
Inserting bobbin ATTENTION: Turn power switch to (O ) “0” before inserting or removing the bobbin. When inserting or removing the bobbin, the needle must be fully raised. - Open the hinged cover. (1) - Hold the bobbin case with one hand. Insert the bobbin so that the thread runs in a clockwise direction (arrow). -
Page 14: Changing The Needle
Changing the needle CAUTION: Turn power switch to (O ) “0” before inserting or removing the needle. Replace the needle at the rst sign of thread breakage or skipped stitches. Select the correct type and size of needle for the fabric to be sewn. -
Page 15: Threading The Upper Thread
Threading the upper thread CAUTION: Before threading, turn power switch to (O ) “0”. Raise the needle bar to its highest position. Follow exactly the numbered threading sequence illustrated below. If you skip a step or fail to properly engage the thread in any of the thread guides, the machine will not sew properly. -
Page 16: Automatic Needle Threader
Automatic needle threader *The automatic needle threader is an optional accessory not supplied with your machine (to purchase call: 877-678-6232). ATTENTION: Turn power switch to (O ) “0” before carrying out any of the following: - Raise the needle to its highest position. - Press lever (A) right down. -
Page 17: Thread Tension
Thread tension NOTE: The bobbin thread tension has been adjusted at the factory and readjustment is usually not required. Lower thread tension To test the bobbin thread tension, remove the bobbin case and bobbin from the machine and hold the bobbin case suspended by the thread. Shake it once or twice. -
Page 18: Bringing Up The Lower Thread
Bringing up the lower thread Hold the upper thread with the left hand. Turn the handwheel towards you with your right hand until the needle goes down and comes up again to its highest position. (1) - Lightly draw the needle thread forming a loop with the bobbin thread. The upper thread should have caught the lower thread in a loop. -
Page 19: Finishing Up
Finishing up Reverse sewing Reverse sewing is used for locking the end of seams and where reinforcement is needed. At the end of seam, press down the reverse sewing lever and touch the foot control lightly. Sew a few reverse stitches. Release the lever and the machine will sew forwards again. -
Page 20: Matching Needle / Fabric / Thread
Matching needle / fabric / thread NEEDLE FABRICS THREAD SIZE Lightweight fabrics-thin cottons, voile, Light-duty thread in cotton, nylon or serge, silk, muslin, Qiana, interlocks, polyester. 9-11 (65-75) cotton knits, tricots, jerseys, drapes, woven polyester, shirt & blouse fabrics. Medium weight fabrics-cotton, satin, 12 (80) kettleclote, sailcloth, double knits, lightweight woolens. -
Page 21: Matching Needle / Fabric / Thread
Matching needle / fabric / thread NEEDLES EXPLANATION TYPE OF FABRIC HAx 1 Standard sharp needles. Sizes range Natural woven fabrics-wool, cotton, thin to large. 9 (65) to 18 (110) silk, etc. Qiana. Not recommended 15x 1 for double knits. Natural and synthetic woven fabrics, polyester blends. -
Page 22: How To Choose Your Pattern
How to choose your pattern For straight stitch select pattern “A” with pattern selector dial (4). Adjust the stitch length dial (2). You may choose any needle position, by turning the stitch width dial (1). For zig-zag stitch, select pattern “B” with pattern selector dial (4). -
Page 23: Straight Stitching And Needle Position
Straight stitching and needle position Turn the pattern selector dial so that the stitch display shows the straight stitch position. Generally speaking, the thicker the fabric, thread and needle, the longer the stitch should be. Choose your needle poition, from left position to right needle position by changing the stitch width dial (1) from “0”... -
Page 24: Zig-Zag Sewing
Zig-zag sewing Turn the pattern selector dial to “B”. Function of stitch width dial The maximum ziz-zag stitch width for zig-zag stitching is “5”; however, the width increases as you move zig-zag dial from “0” - “5”. For twin needle sewing, never set the width wider than “2.5”. -
Page 25: Blind Hem / Lingerie Stitch
Blind hem / lingerie stitch *The blind hem foot is a standard accessory. Blind hem for stretch fabrics. Position “D” on selection dial. Blind hem/lingerie for rm fabrics. Position “E” or “F” on selection dial. Set the machine as illustrated. NOTE: It takes practice to sew blind hems. -
Page 26: Overlock Stitches
Overlock stitches *The overcasting foot is an optional accessory not supplied with your machine (to purchase call: 877-678-6232). Seams, neatening, visible hems. Turn the stitch length dial to “S1”. The stitch width can be adjusted to suit the fabric. Stretch overlock: For ne knits, jerseys, neck edges, ribbing. -
Page 27: Sewing On Buttons
Sewing on buttons Install the embroidering plate to the needle plate as illustrated (1). Change presser foot to button sewing foot. Position the work under the foot. Place the button in the desired position, lower the foot. Set the pattern selector knob on zig-zag stitch. -
Page 28: Utility Sewing
Utility sewing PREPARE: 1. Take o the all purpose foot and attach the buttonhole foot. 2. Measure diameter and thickness of button and add 0.3cm (1/8”) for back tacks; mark buttonhole size on fabric. 3. Place fabric under the foot, so that marking on the buttonhole foot aligns with starting marking on fabric. -
Page 29: Zippers And Piping
Zippers and piping Set the machine as illustrated. Dial selector on “A”. Set stitch length control between “1” - “4” (according to thickness of fabric). The zipper foot can be inserted right or left, depending on which side of the foot you are going to sew. -
Page 30: Sewing With The Hemmer Foot
Sewing with the hemmer foot *The hemmer foot is an optional accessory not supplied with your machine (to purchase call: 877-678-6232). For hems in ne or sheer fabrics. Set the machine as illustrated. Pattern selector on “A”. Neaten the edge of the fabric. At the beginning of the hem, turn under the edge twice by about 3mm (1/8”) and sew 4-5 stitches to secure. -
Page 31: Step Zig-Zag
3 step zig-zag Sewing on lace and elastic, darning, mending, reinforcing edges. Set the machine as illustrated. Pattern selector on “C”. Place patch in position. The stitch length can be shortened to produce very close stitches. (1) When mending tears, it is advisable to use a piece of backing fabric to reinforce. -
Page 32: Stitch Selection
Stitch selection Triple straight stitch: (1/3) For hardwearing seams. Pattern selector on “A”. Turn the stitch length dial to “S1”. The machine sews two stitches forward and one stitch backwards. This gives triple reinforcement. Triple zig-zag: (2/4) For hardwearing seams, hems and decorative seams. Pattern selector on “B”. -
Page 33: Smocking Stitch
Smocking stitch Seams, hems, T-shirts, underwear, etc. Set the machine as illustrated. This stitch can be used for all types of jersey as well as for woven fabrics. (1) Sew at 1cm (1/4”) from the fabric edge and trim the surplus fabric. (2) Pattern selector on “C”. -
Page 34: Sewing With The Cording Foot
Sewing with the cording foot *The cording foot is an optional accessory not supplied with your machine (to purchase call: 877-678-6232). Decorative e ects, cushions, tablecloths, etc. Set the machine as illustrated. Various stitches are suitable for sewing on cord, e.g. Zig-zag, Triple zig-zag, decorative stitches. -
Page 35: Free Motion Darning
Free motion darning *The darning foot is an optional accessory not supplied with your machine (to purchase call: 877-678-6232). Set the machine as illustrated. Install the embroidering plate. (1) Remove the presser foot clamp. (2) Attach the darning foot to the presser foot bar. -
Page 36: Practical Stitches
Practical stitches Set the machine as illustrated. Turn the switch width dial and stitch length dial to suit the fabric. Shell hem (A) For decorative edges. Suitable for edges on sheer, ne and stretch fabrics. The larger stitch should go just over the edge of the fabric to create the shell e ect. -
Page 37: Darning
Darning - Turn stitch length dial to the desired length. - Turn stitch selector to straight stitch, center needle position. - Position the fabric to be darned under the presser foot together with the under laying fabric to be used. - Lower the presser foot and alternately sew forward or reverse using the lever. -
Page 38: Attaching Lace
Attaching lace - Turn stitch length dial to the desired stitch length. - Turn stitch selector to straight stitch, center needle position. - Fold in the edge of the fabric approximately 6mm (1/4”). - Place the lace under the folded edge of the fabric allowing it to under lap the fabric slightly as required by the pattern of the lace. -
Page 39: Applique
Applique - Turn stitch length dial to the desired length. - Turn pattern selector dial to zig-zag. - Select a narrow zig-zag width. - Cut out the applique design and baste it to the fabric. - Sew slowly around the edge of the design. - Trim excess material outside the stitching. -
Page 40: Twin Needle
Twin needle - Turn stitch length dial to the desired stitch length. - Turn stitch selector to straight stitch, center needle position, width setting “0”. - Make sure that the two threads used to thread the twin needle are of the same weight. You can use one or two colors. -
Page 41: Quilting
Quilting *The quilting foot is an optional accessory not supplied with this machine (to purchase call: 877-678-6232). Set pattern selector as illustrated. Insert the quilting guide in presser foot holder and set the space as you desired. Move the fabric over and sew successive rows with the guide riding along on the previous row of stitching. -
Page 42: Gathering X-Foot
Gathering x-foot *The gathering foot is an optional accessory not supplied with this machine (to purchase call: 877-678-6232). Set the pattern selector as illustrated. 1. Attach the gathering foot. 2. Sew a single row or multiple rows of straight stitches. 3. -
Page 43: Patch Work
Patch work These stitches are used to join two pieces of fabric while leaving a space between their edges. Fold over the edges of the two pieces of fabric for the hem and baste the edges to a thin piece of paper leaving a small space between them. -
Page 44: Maintenance
Maintenance CAUTION: Always make sure that the machine is unplugged from power source and the main switch is on (O ) “0”. When the machine is not in use and before inserting or removing parts. Remove the stitch plate: Turn the handwheel until the needle is fully raised. Open the hinged front cover and unscrew the needle plate screw with the screwdriver. -
Page 45: Troubleshooting Guide
Troubleshooting guide PROBLEM CAUSE CORRECTION 1. The machine is not threaded correctly. 1. Rethread machine. 2. The thread tension is too tight. 2. Reduce the thread tension (lower Upper 3. The thread is too thick for the needle. number). 4. The needle is not inserted correctly. 3. -
Page 46: Troubleshooting Guide
Troubleshooting guide PROBLEM CAUSE CORRECTION 1. The machine is not threaded correctly. 1. Check the threading. 2. The bobbin case is not correctly 2. Thread the bobbin case as Loose threaded. illustrated. 3. Needle/fabric/thread combination is 3. The needle size must suit the stitches wrong. - Page 47 The SB700 Domestic 70 Stitch Sewing Machine is warranted for 1 year from provable date of purchase against defects in material and workmanship. During this period such defects will be repared, or the product will be replaced without a charge.
