Summary of Contents for Zanussi ZWF 71440BW
- Page 1 User Manual GETTING STARTED? EASY. ZWF 71440BW EN User Manual Washing Machine...
-
Page 2: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. -
Page 3: Safety Instructions
The appliance must be connected to the water mains using the • new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre. Old hose sets must not be reused. • If the mains power supply cable is damaged, it must be •... -
Page 4: Product Description
• Use original spare parts only. WARNING! Risk of injury, electrical DISPOSAL shock, fire, burns or damage to the WARNING! Risk of injury or appliance. suffocation. • This appliance is for household use only. • Follow the safety instructions on the detergent •... - Page 5 FIXING PLATE KIT (4055171146) Available from your authorised dealer. If you install the appliance on a plinth, secure the appliance in the fixing plates. Read carefully the instructions supplied with the accessory.
-
Page 6: Easy Start
EASY START CONTROL PANEL DESCRIPTION Katoen/Coton 90° Katoen Jeans Coton 60° Opfrissen Synthetica 40° Rafraîchir 20’ Synthétiques 30° Antikreuk Fijne was/Délicats Repassage facile Centrifugeren Wol/Handwas Essorage Laine/Lavage à la main Pompen Donkere kleding Vidange Couleurs foncées Spoelen Mix/Mixtes 20° Rinçage Programme knob Automatic spin reduction and Rinse Hold... - Page 7 Maximum load Programme Programme description Maximum spin Temperature range (Type of load and soil level) speed 7 kg White cotton and fast-coloured cotton. Normal soil. Katoen/Coton 1400 rpm The energy consumption decreases and the time of the washing programme is extended. 60°C - 40°C Synthetica/Synthé- 3 kg...
- Page 8 Maximum load Programme Programme description Maximum spin Temperature range (Type of load and soil level) speed 30'@ 30° 3 kg A short cycle for synthetic and delicate items with 30°C 700 rpm light soil level or for items to freshen up. 1) Standard programmes for the Energy Label consumption values.
-
Page 9: Consumption Values
Programme ■ ■ ■ ■ Spoelen/Rinçage ■ Pompen/Vidange ■ ■ Centrifugeren/Essorage ■ ■ ■ ■ Antikreuk/Repassage facile ■ ■ Opfrissen/Rafraîchir 20' ■ ■ ■ Jeans ■ ■ 30'@ 30° 1) When you set this option, we recommend that you decrease the quantity of the laundry. It is possible to keep the full load but the washing results can be unsatisfactory. - Page 10 Approximate Energy con- Water con- Remaining programme Programmes Load (kg) sumption sumption (li- duration (mi- moisture (%) (kWh) tre) nutes) Fijne was/Délicats 0,55 40°C Wol-Laine/Hand- was-Lavage à la 0,45 main 30°C Standard cotton programmes Standard 60°C cot- 0,92 Standard 60°C cot- 0,68 Standard 40°C cot- 0,59...
-
Page 11: Before First Use
SNEL/RAPIDE Use this option for persons allergic to detergents and in areas where the water is soft. Press this button to decrease the programme duration. The related indicator comes on. Set this option for items with light soil or items to STARTUITSTEL/DÉPART DIFFÉRÉ... - Page 12 USING DETERGENT AND ADDITIVES 2. Adjust the flap in posi- tion B. 1. Measure out the de- 3. Put back the drawer in tergent and the fabric the recess. conditioner. 2. Put the detergent and the fabric condi- tioner into the com- partments.
- Page 13 STARTING A PROGRAMME WITH THE DELAY OPENING THE DOOR START OPTION While a programme or the delay start operates, the 1. Press the button Startuitstel/Départ différé appliance door is locked. repeatedly to set the required delay. CAUTION! If the temperature and The indicator of the set delay comes on.
-
Page 14: Hints And Tips
STAND BY • The brightness of the indicators reduces. • The indicator of the button Start/Pauze Départ/ Some minutes after the end of the washing Pause flashes slowly. programme, if you do not deactivate the appliance, the energy saving status activates. The energy Press one of the buttons to deactivate the energy saving status decreases the energy consumption saving status. -
Page 15: Care And Cleaning
CARE AND CLEANING MAINTENANCE WASH WARNING! Refer to Safety chapters. With the low temperature programmes it is possible that some detergent stays in the drum. Perform a maintenance wash regularly. To do this: EXTERNAL CLEANING • Remove all laundry from the drum. •... -
Page 16: Troubleshooting
5. When no more water flows, install the inlet Do this procedure also when you want hose and the drain hose again. to do the emergency drain. WARNING! Make sure that the 1. Disconnect the mains plug from the mains temperature is more than 0 °C before socket. - Page 17 Problem Possible solution The appliance does not fill • Make sure that the water tap is open. with water properly. • Make sure that the pressure of the water supply is not too low. For this information, contact your local water authority. •...
-
Page 18: Technical Data
find the information on the rating plate: model, PNC and Serial Number. (Mod., Prod. No., Ser. No.) TECHNICAL DATA Dimension Width/ Height/ Depth/ To- 600 mm/ 850 mm/ 559 mm/ 578 mm tal depth Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A... - Page 20 WWW.ZANUSSI.COM/SHOP...
