Summary of Contents for Acoustic Research ARIRC200
Page 1
It is important to read this instruction book prior to using your new product for the first time. Nous vous recommandons de lire ce manuel d’instructions avant d’utiliser votre nouveau produit pour la première fois. user manual guide de l'utilisateur ARIRC200 ARIRC205...
... 9 For ARIRC205 only: Connect the AR Wi-Fi Enabler to your network... 9 Optional (for ARIRC200 only): For use with a "Wired" connection ... 10 Plug in and turn on the radio ... 10 Set up the radio ... 11 Demonstration mode ...
Consult the dealer or an experienced radio / TV technician for help. In accordance with FCC requirements, changes or modifications not expressly approved by manufacturer could void the user’s authority to operate this product. Acoustic Research ARIRC200 Acoustic Research ARIRC205 CAUTION RISK OF ELECTRIC SHOCK...
Safety information Technical specification Product: Wi-Fi Internet Radio Brand: Acoustic Research Model: ARIRC200, ARIRC205 Electrical power source External AC adapter for radio Output: 9.0V DC 1.56A Input: 100-240V ~ 50/60Hz 0.7A External AC adapter for enabler (ARIRC205 only) Output: 5V DC 1A...
Safety information IMPORTANT SAFETY INSTRUCTIONS PLEASE READ AND SAVE FOR FUTURE REFERENCE Some of the following information may not apply to your particular product; however, as with any electronic product, precautions should be observed during handling and use. • Read these instructions. •...
Program's proprietary notices. (b) You may transfer the Program and license to another party only as a part of the Acoustic Research® brand Internet Radio Device (the “Device”), and only if the other party agrees to accept the terms and conditions of this EULA. If you transfer...
Page 7
End user license agreement LIMITATION OF LIABILITY OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU. (b) YOU ASSUME RESPONSIBILITY FOR THE SELECTION OF THE APPROPRIATE PROGRAM TO ACHIEVE YOUR INTENDED RESULTS, AND FOR THE INSTALLATION, USE, AND RESULTS OBTAINED.
Broadband (cable/DSL) modem, usually supplied by your Internet service provider • An 802.11 b or g (Wi-Fi) wireless home network or Ethernet router/switch/hub with available LAN port (for ARIRC200 only) For Wi-Fi connections, you may also need: • Your wireless network’s SSID •...
Before you begin 2. Setup your AR Infinite Radio accounts To simplify setup on the radio please complete these steps: A. Find the Setup Information Card that contains your radio’s MAC address number (MAC: 00-21-2A- XX-XX-XX) and activation PIN # (PIN: XXXX). (This number is also found in the Device Info screen under the Settings menu in your radio.) B.
Before you begin 5. Optional (for ARIRC200 only): For use with a "Wired" connection Use the supplied Ethernet cable if you do not have a wireless (Wi-Fi) access point. LA N Broadband modem or Ethernet router/hub/switch 6. Plug in and turn on the radio...
Before you begin 7. Set up the radio Refer to Using the menus on page 16 for more information on making choices and inputting information in menus. A. NOTE: When you turn on the radio for the first time, it will be in "DEMO" mode. To exit this mode, press and release preset 1, then SLEEP/SNOOZE, then preset 6 on top of the radio.
Page 12
Before you begin • Detect Networks: to automatically scan for available networks and display a list of networks to choose from. Go to step F to complete the connection. • Enter SSID: to manually enter your networks information. Select this option if your Networks SSID is hidden.
Before you begin Demonstration mode The radio has a pre-installed demonstration. To exit the demonstration, press and release in sequence the buttons on top of the radio: preset 1, then SLEEP/SNOOZE, then preset 6. Getting the latest firmware and information The radio will automatically alert you for upgrade if a new firmware is available.
Before you begin To turn on the Wi-Fi Enabler: The Enabler will turn on automatically when power is connected. To check the AR Wi-Fi Enabler's status by reading the LEDs (Lights): • Normally the POWER, WAN and WIRELESS LEDs will be on when the enabler is operating as a router.
Previous/scan back/reverse/ menu back Menu down Rear LAN port (for ARIRC200 only) Headphone/ audio line-out RealAudio is a trademark or a registered trademark of RealNetworks, Inc. WEATHER You can connect USB devices to the USB port: The radio can play open MP3, WMA and RealAudio audio files stored on the connected USB device.
General controls Turning on or off Press ON/STANDBY to turn the radio on or off (standby mode). Volume control Rotate the VOL. knob to adjust the volume. Source selection Press SOURCE repeatedly to select among the following audio content sources: •...
Page 17
General controls To input characters: • Some menus require character input (e.g. password, postal code). Postal code is useful for clock time setting, weather forecast and searching local Internet radio stations in your area. • When inputting characters, press select the alpha-numeric characters listed at the bottom of the screen.
Clock and alarm Accessing the digital clock The Wi-Fi Internet Radio also includes a digital clock which will be automatically updated when connected with the Internet. Wi-Fi connection strength Current temperature Alarm clock status • Press CLOCK to show the clock without interrupting audio playback.
Clock and alarm 8. Press to highlight one of the sources of wake sound: ALARM SOUND: Buzzer AM Preset FM Preset Internet Preset • Buzzer • AM Presets • FM Presets • Internet Presets Read relevant sections (e.g. Internet Radio) in this user manual to understand how to preset stations.
Internet Radio With Internet radio, you can listen to music, news, sports, weather or talk radio in other countries or from your home town. It offers the most music selections from around the world and most stations are free. Accessing Internet Radio •...
Internet Radio To assign the current station as the wake sound of the alarm clock: 1. Press . 2. Press to highlight Send to Alarm and then press SELECT. Recording Internet Radio Warning! Use of the recording feature is for personal use only.
MP3tunes MP3tunes is a Music Service Provider (MSP) and the home of MP3tunes Locker, a secure, online music space to allow unlimited listening. MP3tunes users can upload their own music collections to the MP3tunes Locker and listen through this radio when the computer is turned off.
FM/AM Tuner FM/AM antenna • For FM reception, uncoil the FM antenna at the back of the radio, ensuring it is fully extended (you may even want to tape it to the wall behind the radio if possible. The higher the better.) •...
Internal Memory The radio's internal memory stores up to 10 hours of recordings from Internet Radio and FM/ AM Tuner. Accessing Internal Memory • Press SOURCE repeatedly to select Internal Memory. • Press to highlight Internal Memory in the Source menu and then press SELECT. Listening to recordings 1.
USB Input The radio can play back music files (mp3, wma and RealAudio (RA8 and G2) formats) stored on an external USB device connected to it. The USB connection port is located at the back of the radio. Accessing USB Input mode •...
Weather Weather broadcast Your radio includes a complimentary 4 year weather, on-demand subscription from WeatherBug® A digital weather broadcast is available including: • Text-to-speech reading of weather forecast for the postal code associated with the radio (can be turned on or off in the Settings menu). Audio playback will pause during reading.
Settings Changing radio's settings To change the radio settings: 1. Press to display the Source menu. 2. Press to highlight Settings and then press SELECT. 3. Press to highlight a setting and press SELECT to enter the sub-menu. • Repeat this step to browse for more settings and sub-menus.
More information Troubleshooting tips The radio cannot be turned on. • Plug the AC power adapter securely into the radio and a wall outlet. • Check the power outlet by plugging in another device. • Press and hold ON/STANDBY for 10 seconds to reboot the unit.
More information Poor FM/AM Tuner reception. • Check the antenna connection. • Move antenna. • Turn off nearby electrical appliances, such as hair dryer, vacuum cleaner and microwave. Cannot record radio. • Record feature is only available for Internet Radio, AM and FM Tuner. •...
Page 30
More information 5. In the Network Setup screen, press highlight Enter SSID and then press SELECT. 6. The Network Security screen will be displayed. Confirm the SSID of the Wi-Fi Enabler or re-enter if necessary. When finished, press to show DONE and then press SELECT to continue.
More information Web-based utility of Wi-Fi Enabler • This section is provided for advanced users that would like to verify their Enabler's configurations via the Enabler’s web-based utility. • The utility can be accessed via your web browser through the use of a computer connected to LAN port of the Wi-Fi Enabler.
Page 32
More information 8. Click Status from the left menu to view the current connection status. 9. Click Wireless from the left menu to view the wireless settings. The SSID shows here must match the SSID of the radio. • A quick way to check the SSID on the radio: press , select Settings, select Network Setup, and then select Connection Info.
Warranty information Limited warranty 12 Month Limited Warranty Applies to Acoustic Research Audio/Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be...
Page 35
Warranty information • Properly pack your unit. Include any remotes, memory cards, cables, etc. which were originally provided with the product. However DO NOT return any removable batteries, even if batteries were included with the original purchase. We recommend using the original carton and packing materials.
Page 36
Illustrations contained within this publication are for representation only and subject to change. The descriptions and characteristics given in this document are given as a general indication and not as a guarantee. In order to provide the highest quality product possible, we reserve the right to make any improvement or modification without prior notice.
Page 37
Installation des piles AAA dans la base de la radio ... 9 Pour le modèle ARIRC205 seulement : connexion de l’outil Wi-Fi AR à votre réseau... 9 En option (ARIRC200 seulement) : connexion de la radio à l’aide d’un câble Ethernet ... 10 Branchement et démarrage de la radio ... 10 Configuration de la radio ...
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Acoustic Research ARIRC200 Acoustic Research ARIRC205...
Information de sécurité Caractéristiques techniques Appareil : Radio Internet Wi-Fi Marque : Acoustic Research Modèle : ARIRC200, ARIRC205 Alimentation électrique Adaptateur CA externe pour la radio Sortie : 9,0 V CC 1,56 A Entrée : 100 à 240 V ~50/60 Hz 0,7 A Adaptateur CA externe pour l’outil Wi-Fi...
Information de sécurité IMPORTATNES INSTRUCTIONS DE SECURITE BIEN LIRE ET CONSERVER POUR RÉFÉRENCE ULTÉRIEURE Il est possible que certains des articles ci-dessous ne s’appliquent pas à votre appareil. Cependant, il faut prendre certaines précautions quand on manipule et utilise tout appareil électronique. •...
(b) Vous pouvez transférer le logiciel et la licence à une autre personne seulement dans le cadre du transfert de l’appareil de radio Internet de marque Acoustic Research seulement si cette personne accepte les modalités et conditions de ce CLUF. Si vous transférez le Logiciel, vous devez transférer en même temps toutes les copies à...
Page 42
Entente de licence de l'utilisateur FINANCIÈRE) SANS ÉGARD À LA CAUSE OU GENRE D’ACTION INCLUANT LES CONTRATS, LES TORTS OU LES NÉGLIGENCES PROVENANT DE VOTRE UTILISATION OU INCAPACITÉ D’UTILISER LE LOGICIEL MÊME SI AUDIOVOX A ÉTÉ PRÉVENUE DE LA POSSIBILITÉ DE TELS DOMMAGES. COMME CERTAINS ÉTATS OU CERTAINES JURIDICTIONS NE PERMETTENT PAS L’EXCLUSION OU LA LIMITATION DE LA RESPONSABILITÉ...
Avant de commencer Cher client d’Acoustic Research, merci d’avoir acheté la radio Internet Wi-Fi AR. Cet appareil vous permet d'écouter la radio Internet, MP3tunes, la radio AM/FM, les prévisions météorologiques et la musique enregistrée dans la mémoire interne ou sur un dispositif USB.
Avant de commencer 2. Configuration de vos comptes AR Infinite Radio Pour simplifier la configuration de la radio, veuillez suivre les étapes suivantes : A. Trouvez la carte d’information de configuration qui indique le numéro d’adresse MAC (MAC : 00-21-2A-XX-XX-XX) et le NIP (PIN : XXXX) de votre radio. (Ce numéro est aussi affiché sous l'option Device Info dans le menu Settings de votre radio.) B.
Avant de commencer 5. En option (ARIRC200 seulement) : Pour une connexion « avec fil » Utilisez le câble Ethernet fourni si vous n’avez pas de point d’accès sans fil (Wi-Fi). Modem haute-vitesse ou routeur/concentrateur/ commutateur Ethernet LA N 6. Branchement et démarrage de la radio Prise électrique...
Avant de commencer 7. Configuration de la radio Consultez la rubrique Utilisation des menus à la page 16 pour plus de renseignements sur la sélection et l’entrée d’informations dans les menus. A. REMARQUE : La première fois que vous démarrez la radio, elle est en mode «DÉMO». Pour quitter ce mode, appuyez et relâchez préréglage 1, puis SLEEP/SNOOZE et enfin préréglage 6 situés sur le dessus de la radio.
Page 47
Avant de commencer • À l’écran Config. réseau, appuyez sur pour sélectionner San fils puis appuyez sur SELECT. L’écran Config Réseau s’affiche et offre deux options de configuration. Appuyez pour sélectionner une option puis appuyez sur SELECT. • Détecter réseaux : pour détecter automatiquement les réseaux disponibles et afficher une liste des réseaux pouvant être sélectionnés.
Avant de commencer Après la connexion à Internet • Si vous n’avez pas activé vos comptes Infinite Radio, ou si la radio ne parvient pas à télécharger vos renseignements du serveur Infinite Radio, la radio pourrait vous demander votre code postal. •...
Avant de commencer Pour installer l’outil Wi-Fi : L’outil Wi-Fi peut être installé à la verticale ou à l’horizontale. Retirez les supports si vous l’installez à l’horizontale. Tournez l’antenne pour améliorer la réception du signal. MODE WIRELESS POWER WiFi ENABLER PRESS Pour démarrer l’outil Wi-Fi : L’outil Wi-Fi démarre automatiquement lorsque...
Déplacement vers le bas dans le menu Arrière Port LAN (ARIRC200 seulement ) Casque d’écoute/ sortie de ligne audio RealAudio est une marque de commerce ou une marque déposée de RealNetworks, Inc. WEATHER Vous pouvez brancher des dispositifs USB dans le port USB : La radio peut lire les fichiers audio mp3, WMA et RealAudio enregistrés sur les dispositifs USB connectés.
Commandes générales Démarrage et fermeture Appuyez sur ON/STANDBY pour démarrer ou fermer la radio (mode d'attente). Réglage du volume Tournez le bouton VOL. pour régler le volume. Sélection de la source Appuyez à plusieurs reprises sur SOURCE pour sélectionner l’une des sources audio suivantes : •...
Page 52
Commandes générales Pour entrer des caractères : • Certains menus peuvent nécessiter l’entrée de caractères (p. ex., un mot de passe ou un code postal). Le code postal est utile pour le réglage de l'horloge, les prévisions météorologiques et la recherche de stations de radio Internet locales dans votre région.
Horloge et alarme Accès à l’horloge numérique La radio Internet Wi-Fi possède aussi une horloge numérique qui est mise à jour lors de la connexion à Internet. Force du signal Wi-Fi Température actuelle État de l’alarme • Appuyez sur CLOCK pour afficher l’horloge sans interrompre la lecture audio.
Horloge et alarme 8. Appuyez sur pour mettre en surbrillance l’une des sources pour le son du réveil : • Bruiteur • Préréglages AM • Préréglages FM • Préréglages Internet Consultez les rubriques correspondantes (p. ex., Radio Internet) de ce guide de l’utilisateur pour savoir comment prérégler des stations.
Radio Internet La radio Internet vous permet d’écouter de la musique, des nouvelles, des sports, la météo ou la radio parlée dans d’autres pays ou dans votre région. Elle offre la plus grande diversité de musique provenant de tous les coins du monde et la plupart des stations sont gratuites.
Radio Internet Pour enregistrer la station courante dans My Favorites : Appuyez sur pendant l’écoute. Aussi : 1. Appuyez sur 2. Appuyez sur pour mettre en surbrillance Ajout station fav. puis appuyez sur SELECT. Pour écouter une station dans My Favorites : Sélectionnez une station dans My Favorites dans le menu principal de la radio Internet puis appuyez sur SELECT pour démarrer l’écoute.
MP3tunes MP3tunes est un fournisseur de services musicaux (MSP) et l'hôte de MP3tunes Locker, un espace en ligne sécuritaire de musique offrant une écoute continue. Les utilisateurs de MP3tunes peuvent téléverser leur propre collection de musique sur MP3tunes Locker et l'écouter avec cette radio lorsque leur ordinateur est fermé.
Radio FM/AM Antenne FM/AM • Pour capter la bande FM, dépliez l'antenne FM située à l'arrière de la radio et assurez- vous qu'elle est entièrement dépliée (vous devriez même la coller au mur derrière la radio si possible. Plus elle est élevée, meilleure sera la réception.) •...
Mémoire interne La mémoire interne de la radio permet de sauvegarder jusqu’à dix heures d’enregistrements de la radio Internet et FM/AM. Accès à la mémoire interne • Appuyez à plusieurs reprises sur SOURCE pour sélectionner Mémoire Interne. • Dans le menu Source, appuyez sur pour mettre en surbrillance Mémoire Interne puis appuyez sur SELECT.
Entrée USB La radio peut lire les fichiers musicaux (en format mp3, WMA et RealAudio (RA8 et G2)) qui sont enregistrés sur un dispositif USB connecté. Le port de connexion USB est situé à l’arrière de la radio. Accès au mode d’entrée USB •...
Météo Bulletin météo Votre radio comprend un abonnement de faveur de quatre ans au service d'informations météorologiques sur demande WeatherBug Un bulletin météo est disponible et offre : • Une lecture texte-vers-parole des prévisions météo pour le code postal associé à la radio (cette fonction peut être activée et désactivée dans le menu Réglages).
Réglages Modification des réglages de la radio Pour modifier les réglages de la radio : 1. Appuyez sur pour afficher le menu Source. 2. Appuyez sur pour mettre en surbrillance Réglages puis appuyez sur SELECT. 3. Appuyez sur pour mettre en surbrillance un réglage puis appuyez sur SELECT pour ouvrir un sous-menu.
Plus de renseignements Conseils de dépannage Impossible de démarrer la radio. • Branchez fermement l’adaptateur d’alimentation CA dans la radio et la prise murale. • Vérifiez la prise murale en y branchant un autre appareil. • Appuyez et gardez enfoncé ON/STANDBY pendant dix secondes pour redémarrer l’appareil.
Plus de renseignements • La vitesse de transmission réelle d'une transmission numérique radio dépend du fournisseur de service (c.-à-d., la station de radio Internet). Impossible de revenir à la chanson précédente lors de l’écoute de la radio Internet. • Le saut à la chanson précédente n'est pas disponible avec la radio Internet.
Page 65
Plus de renseignements Pour vérifier si les informations de configuration sont les mêmes que celles de la radio : 1. Appuyez sur pour afficher le menu Source de la radio. Appuyez sur pour mettre en surbrillance Réglages puis appuyez sur SELECT.
Plus de renseignements Utilitaire web de l’outil Wi-Fi • Cette rubrique est destinée aux utilisateurs expérimentés qui voudraient vérifier la configuration de leur outil Wi-Fi à l’aide de l’utilitaire web de l’outil Wi-Fi. • Vous pouvez accéder à cet utilitaire à l'aide de votre navigateur web en utilisant un ordinateur connecté...
Page 67
Plus de renseignements 8. Cliquez sur Status dans le menu de gauche pour afficher l’état de la connexion courante. 9. Cliquez sur Wireless dans le menu de gauche pour afficher les réglages sans fil. Le SSID qui apparaît sur cette page doit être le même que le SSID de la radio.
Normes : IEEE 802.11g et 802.11b • Canaux : 11 canaux Wi-Fi (États-Unis et Canada) • Port Ethernet (ARIRC200 seulement) : compatible avec la norme 10/100 RJ-45 • Alimentation : Externe; 9,0 V CC 1,56 A • Piles de secours : 3 piles AAA •...
Information de garantie Information de garantie Garantie limitée de 12 mois S’applique aux appareils RCA audiovideo AUDIOVOX ELECTRONICS CORP. (la Compagnie) garantit au premier acheteur au détail de cet appareil que cet appareil ou toute partie de ce dernier, dans des conditions d’utilisation normales, ne possède aucune défectuosité...
Page 70
Information de garantie L’APPAREIL RETOURNÉ. L’appareil sera retourné avec les réglages par défaut et sans contenus préenregistrés qui auraient pu être déjà installés lors de l'achat original. Le consommateur sera responsable de télécharger à nouveau les données et les contenus. Le consommateur sera responsable du rétablissement des réglages personnalisés.
