Sanyo PLC-XU111 Owner's Manual

Sanyo multimedia projector owner's manual plc-xu111, plc-xu111k
Hide thumbs Also See for PLC-XU111:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
Multimedia Projector
PLC-XU111
MODEL
PLC-XU111K
Owner's Manual
Network Supported
❏ Wireless LAN
IEEE802.11b/g
❏ Wired LAN
100-Base-TX/10-Base-T
Memory Viewer
❏ USB Memory Viewer (optionally available)
Compatible with a dedicated USB memory
✽Refer to the owner's manuals below for details about
network and memory viewer function.
■ Network Set-up and Operation
■ Owner's Manual USB Memory
This manual is provided with optionally supplied
USB memory.

Advertisement

Table of Contents
loading

Related Manuals for Sanyo PLC-XU111

Summary of Contents for Sanyo PLC-XU111

  • Page 1 Multimedia Projector PLC-XU111 MODEL PLC-XU111K Owner’s Manual Network Supported ❏ Wireless LAN IEEE802.11b/g ❏ Wired LAN 100-Base-TX/10-Base-T Memory Viewer ❏ USB Memory Viewer (optionally available) Compatible with a dedicated USB memory ✽Refer to the owner’s manuals below for details about network and memory viewer function.

  • Page 3: Features And Design

    Features and Design This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. ◆...

  • Page 4: Table Of Contents

    Air Circulation Moving the Projector Installing the Projector in Proper Directions Compliance ..... . .9 Part Names and Functions ..10...

  • Page 5: To The Owner

    NOTE: This symbol and recycle system are applied only to EU countries and not applied to the countries in the other area of the world. Your SANYO product is designed and manufactured materials and components which can be recycled and reused.

  • Page 6: Safety Instructions

    Do not use attachments not recommended by the manufacturer as they may cause hazards. Do not place this projector on an unstable cart, stand, or table. The projector may fall, causing serious injury to a child or adult, and serious damage to the projector. Use only with a cart or stand recommended by the manufacturer, or sold with the projector.

  • Page 7: Air Circulation

    This may cause damage to the projector. For information about transporting the projector by courier or any other transport service, consult your dealer. –Do not put the projector in a case before the projector is cooled enough. Air Intake Vents...

  • Page 8: Installing The Projector In Proper Directions

    Safety Instructions Installing the Projector in Proper Directions Use the projector properly in specified positions. Improper positioning may reduce the lamp life and result in severe accident or fire hazard. This projector can project the picture upward, downward, or backward, perpendicular to the plane of the screen as shown in the figure below.

  • Page 9: Compliance

    Telephone No. : (818)998-7322 The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it. AC Power Cord for the United States and Canada: AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and certified by the Canadian Standard Association (CSA).

  • Page 10: Part Names And Functions

    !5 Air Filter !6 Adjustable Feet !7 Battery Cover ✽ Kensington Security Slot This slot is for a Kensington lock used to deter theft of the projector. * Kensington is a registered trademark of ACCO Brands Corporation. ✔ Note: • !2 USB Terminal and !3 LAN Connection Terminal are for the Network function.

  • Page 11: Rear Terminal

    USB port of the computer to the USB terminal with a USB cable (not supplied) (pp.13, 19). e SERVICE PORT This jack is used to service the projector. r COMPUTER IN 2/COMPONENT IN Connect the computer or component video (or RGB Scart) output signal to this terminal (pp.19, 21).

  • Page 12: Top Control

    –Blinks red when the internal temperature of the projector exceeds the operating range (pp.62, 71). o POWER indicator –Lights red when the projector is in stand-by mode. –Lights green during operations. –Blinks green in the Power management mode (p.52).

  • Page 13: Remote Control

    Scroll back and forth the pages on the screen when giving a presentation. To use these buttons, connect the projector and your computer with a USB cable (pp.11, 19) !4 LAMP CONTROL button Select a lamp mode (pp.28, 53).

  • Page 14: Laser Pointer Function

    Signal Emission Indicator Laser Light Window Pointer Function You can move the Spotlight or Pointer of the projector with the remote control to emphasize a part of the projected image. Press and hold the MENU and NO SHOW buttons for more than 10 seconds to activate the Pointer function.

  • Page 15: Wireless Mouse Operation

    Change the remote control code for the projector first before changing that for the remote control. See “Remote control” in the Setting Menu on page 53.

  • Page 16: Front

    Projection angle can be adjusted up to approx. 9.0 degrees with the adjustable feet. Lift the front of the projector and pull the feet lock latches on both side of the projector upward. Release the feet lock latches to lock the adjustable feet and rotate the adjustable feet to a proper height, and tilt.

  • Page 17: Installation

    Installation Positioning the Projector For projector positioning, see the figures below. The projector should be set perpendicularly to the plane of the screen. ✔ Notes: •The brightness in the room has a great influence on picture quality. It is recommended to limit ambient lighting in order to obtain the best image.

  • Page 18: Connecting The Ac Power Cord

    NOTE ON THE POWER CORD AC power cord must meet the requirements of the country where you use the projector. Confirm the AC plug type with the chart below and proper AC power cord must be used.

  • Page 19: Connecting To A Computer

    Cables used for connection • VGA Cable (Mini D-sub 15 pin)* • DVI-I/VGA Cable • USB Cable • Audio Cables (*One cable is supplied; other cables are not supplied with the projector.) Audio Output USB port USB cable VGA cable...

  • Page 20: Connecting To Video Equipment

    Cables used for connection • Video and Audio Cable (RCA x 3) • S-VIDEO Cable • Audio Cable (Cables are not supplied with the projector.) ✔Notes: •When connecting the AUDIO OUT to external audio equipment, the projector’s built-in speaker is disconnected.

  • Page 21: Connecting To Component Video Equipment

    Connecting to Component Video Equipment Cables used for connection • Audio Cables • Scart-VGA Cable • Component Cable • Component-VGA Cable (Cables are not supplied with the projector.) RGB Scart Component Video Output 21-pin Output (Y, Pb/Cb, Pr/Cr) Component cable...

  • Page 22: Basic Operation

    (see page 53) appear on the screen. If the projector is locked with a PIN code, PIN code input dialog box will appear. Enter the PIN code as instructed below.

  • Page 23: Turning Off The Projector

    LEAST FIVE MINUTES BEFORE TURNING IT OFF. ✔ Notes: •When the On start function is set to “On,” the projector will be turned on automatically by connecting the AC power cord to an AC outlet (p.53). •DO NOT OPERATE THE PROJECTOR CONTINUOUSLY WITHOUT REST.

  • Page 24: How To Operate The On-Screen Menu

    Basic Operation How to Operate the On-Screen Menu The projector can be adjusted or set via the On-Screen Menu. For each adjustment and setting procedure, refer to the respective sections in this manual. Press the MENU button on the top control or the remote control to display the On-Screen Menu.

  • Page 25: Menu Bar

    Used to adjust picture image [Contrast/Brightness/Color/Tint/ Color temp./White balance (R/G/B)/Sharpness/Gamma/ Noise reduction/Progressive] (pp.44–45). Basic Operation Setting Menu Used to set the projector’s operating configurations (pp.47- 57). Sound Menu Wired Menu Used to adjust See owner’s manual the volume or “Network Setup mute the sound and Operation.”...

  • Page 26: Zoom And Focus Adjustment

    Rotate the Focus Ring to adjust the focus of the image. Auto Setup Function Auto setup function is provided to automatically correct Keystone distortion according to the projector’s tilt and adjust the computer display parameters (Fine sync, Total dots, and Picture position) by just pressing the AUTO SETUP button on the top control or the AUTO SET button on the remote control.

  • Page 27: Sound Adjustment

    Sound Adjustment Direct Operation Volume Press the VOLUME+/– buttons on the top control or on the remote control to adjust the volume. The volume dialog box appears on the screen for a few seconds. Mute Press the MUTE button on the remote control to temporarily turn off the sound.

  • Page 28: Remote Control Operation

    Basic Operation Remote Control Operation Using the remote control for some frequently used operations is advisable. Just pressing one of the buttons enables you to make the desired operation quickly without calling up the On-Screen Menu. COMPUTER/VIDEO/NETWORK button Press the COMPUTER, VIDEO, or NETWORK button on the remote control to select the input source.
  • Page 29 NO SHOW button Press the NO SHOW button on the remote control to black out the image. To restore to normal, press the NO SHOW button again or press any other button. When a projected image is captured and set as “User” in the Logo selection (see page 49), the screen changes each time you press the NO SHOW button as follows.

  • Page 30: Input Source Selection

    Computer Input Input Source Selection (RGB: Computer 1 (Analog)/Computer 2 ) Direct Operation Choose either Computer 1 (Analog) or Computer 2 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below.

  • Page 31: Input Source Selection (Rgb (Pc Digital), Rgb (Av Hdcp))

    Visual Interface) from being copied. The specification of HDCP is decided and controlled by Digital Content Protection, LLC. Should the specification be changed, this projector may not display the digital content protected by HDCP. •Wired, Wireless, Memory viewer are for the Network function.

  • Page 32: Computer System Selection

    Computer Input Computer System Selection This projector automatically tunes to various types of computers based on VGA, SVGA, XGA, SXGA, WXGA, or UXGA with its Multi-scan system and Auto PC Adjustment. If a computer is selected as a signal source, this projector automatically detects the signal format and tunes to project a proper image without any additional settings.

  • Page 33: Auto Pc Adjustment

    To store adjustment parameters The adjusted parameters from the Auto PC Adjustment can be stored in the projector. Once the parameters are stored, the setting can be done just by selecting a Mode (1–5) in the PC System Menu (see page 32). See also “Store” on page 35.

  • Page 34: Manual Pc Adjustment

    Computer Input Manual PC Adjustment Some computers employ special signal formats which may not be tuned by Multi-scan system of this projector. Manual PC Adjustment enables you to precisely adjust several parameters to match those signal formats. The projector has five independent memory areas to store those parameters manually adjusted. It allows you to recall the setting for a specific computer.
  • Page 35 Display area H Use the Point buttons to adjust the horizontal area displayed by this projector. Display area V Use the Point buttons to adjust the vertical area displayed by this projector. Reset To reset the adjusted data, select Reset and press the SELECT button.

  • Page 36: Image Mode Selection

    Image 3, and Image 4 by pressing the IMAGE button on the remote control. Dynamic For viewing pictures in a bright room. Standard Normal picture mode preset on the projector. Real Picture mode with improved halftone for graphics. Blackboard (Green) For the image projected on a blackboard.

  • Page 37: Image Adjustment

    Image Adjustment Press the MENU button to display the On-Screen Menu. Use the Point buttons to move the red frame pointer to the Image Adjust Menu icon. Use the Point buttons to move the red frame pointer to the desired item and then press the SELECT button to display the adjustment dialog box.

  • Page 38: Screen Size Adjustment

    Quit Exit the Image Adjust Menu. Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Press the MENU button to display the On-Screen Menu. Use the Point frame pointer to the Screen Menu icon.
  • Page 39 Custom Adjust the screen scale and position manually with this function. Press the SELECT button at Custom and the “Custom” is displayed on the screen for a few seconds and then the Aspect dialog box appears. Scale H/V... Adjust the Horizontal/Vertical screen scale. H&V...

  • Page 40: Video Input

    SELECT button. When selecting Auto, the projector automatically Auto detects incoming video signal, and adjusts itself to optimize its performance. The projector selects connection in the following order: 1. S-video 2. Video When video input signal is connected to the Video VIDEO jack, select Video.

  • Page 41: Input Source Selection (Component, Rgb Scart 21-Pin)

    Input Source Selection (Component, RGB Scart 21-pin) Direct Operation Choose Computer 2 by pressing the INPUT button on the top control or press the COMPUTER button on the remote control. Before using these buttons, correct input source should be selected through Menu operation as described below. Menu Operation Press the MENU button to display the On-Screen Menu.

  • Page 42: Video System Selection

    When Video System is PAL-M or PAL-N, select the system manually. PAL/SECAM/NTSC/NTSC4.43/PAL-M/PAL-N If the projector cannot reproduce proper video image, select a specific broadcast signal format from among PAL, SECAM, NTSC, NTSC 4.43, PAL-M, and PAL-N. Component...

  • Page 43: Image Mode Selection

    Image 3, and Image 4 by pressing the IMAGE button on the remote control. Dynamic For viewing pictures in a bright room. Standard Normal picture mode preset on the projector. Cinema Picture mode adjusted with fine tone. Blackboard (Green) For the image projected on a blackboard.

  • Page 44: Image Adjustment

    Video Input Image Adjustment Press the MENU button to display the On-Screen Menu. Use the Point frame pointer to the Image Adjust Menu icon. Use the Point buttons to move the red frame pointer to the desired item and then press the SELECT button to display the adjustment dialog box.
  • Page 45 L1... For an active picture. L2... For a still picture. Film ... For watching a film. With this function, the projector reproduces pictures faithful to the original film quality. Reset To reset the adjusted data, select Reset and press the SELECT button.

  • Page 46: Screen Size Adjustment

    Video Input Screen Size Adjustment This projector has the picture screen resize function, which enables you to customize the image size. Press the MENU button to display the On-Screen Menu. Use the Point frame pointer to the Screen Menu icon.

  • Page 47: Setting

    Setting Setting This projector has a Setting menu that allows you to set up the other various functions described below. Press the MENU button to display the On-Screen Menu. Use the Point frame pointer to the Setting Menu icon. Use the Point...
  • Page 48 Countdown Off ... Show the input image instead of the countdown when turning on the projector. Use this function when you want to project the image as early as possible even when the lamp is not bright enough.
  • Page 49 After capturing the projected image, go to the Logo select function and set it to “User”. Then the captured image will be displayed the next time you turn on the projector or when you press the NO SHOW button (see page 29).
  • Page 50 After entering the four-digit number, move the pointer to “Set.” Press the SELECT button so that you can start to operate the projector. If you entered an incorrect Logo PIN code, “Logo PIN code” and the number (✳✳✳✳) will turn red for a moment.
  • Page 51 – When pressing the COMPUTER button or VIDEO button on the remote control. On2 ... Input search works under the following situation. – When turning on the projector by pressing the ON/STAND-BY button on the top control or the remote control.
  • Page 52 Operation.” ✔ Note: •When selecting Normal, the cooling fans may be running depending on the temperature inside the projector even if the projector is turned off. Power management For reducing power consumption as well as maintaining the lamp life, the Power management function turns off the projection lamp when the projector is not operated for a certain period.
  • Page 53 ✔ Note: •Be sure to turn off the projector properly (see “Turning Off the Projector” on page 23). If the projector is turned off in the incorrect sequence, the On start function does not work properly. Lamp control This function allows you to change brightness of the screen.
  • Page 54 Setting Security (Key lock, PIN code lock, Alarm settings) This function allows you to use the Key lock, PIN code lock, and Alarm function to set the security for the projector operation. Key lock This function locks the top control and remote control buttons to prevent operation by unauthorized persons.
  • Page 55 DOWN THE NEW PIN CODE IN COLUMN OF THE PIN CODE NO. MEMO ON PAGE 78, AND KEEP IT SECURELY. IF YOU FORGET YOUR PIN CODE, THE PROJECTOR CAN NO LONGER BE STARTED. Alarm This function allows you to configure the Alarm operation.
  • Page 56 (p.23). L1... Normal operation L2... Slower and lower-sound than the normal operation (L1), but it takes more time to cool the projector down. Fan control Choose the running speed of cooling fans from the following options.
  • Page 57 Filter counter This function is used to set a frequency for the filter cleaning. When the projector reached a specified time between cleanings, a Filter warning icon appears on the screen, notifying the cleaning is necessary. After cleaning the filter, be sure to select RESET and set the timer.

  • Page 58: Antitheft Alarm Function

    •This function is not a guarantee against stealing. •The alarm does not ring while the AC power cord is connected to an outlet even if the projector detects vibrations. •The alarm will stop, as the AC power cord is connected to an outlet, except when the battery cover is open.

  • Page 59: Other Settings

    Other settings Change the PIN code Press the F button and enter the four-digit PIN code number within about 10 seconds. The ALARM indicator blinks red for a few seconds and a high-pitched confirmation sound is produced. While the indicator is blinking, enter a new PIN code, then you will hear a high-pitched confirmation sound and the ALARM indicator is turned off.
  • Page 60 Replace the rechargeable batteries Use only the specified battery for this projector. Using other types of battery may cause accident or fire hazard. Replacement Battery: SANYO Ni-MH BATTERY PACK Part No. 645 089 8587 How to replace the rechargeable batteries Unplug the AC power cord from a wall outlet.
  • Page 61 ● If you do not use the projector or the Antitheft alarm function for a long period of time, remove the battery from the projector and store it in a place where the temperature is always between –4˚F to 86˚F (–20˚C to 30˚C).

  • Page 62: Maintenance And Cleaning

    Maintenance and Cleaning Warning Indicator The WARNING indicator shows the state of the function which protects the projector. Check the state of the WARNING indicator and the POWER indicator to take proper maintenance. The projector is shut down and the WARNING indicator is blinking red.

  • Page 63: Cleaning The Filter

    If a “Filter warning” icon appears on the screen, clean the filter immediately. Clean the filter by following the steps below.

  • Page 64: Slide Shutter

    Avoid using an excessive amount of cleaner. Abrasive cleaners, solvents, or other harsh chemicals might scratch the surface of the cabinet. When the projector is not in use, put the projector in an appropriate carrying case to protect it from dust and scratches.

  • Page 65: Lamp Replacement

    Lamp Replacement When the projection lamp of the projector reaches its end of life, the Lamp replacement icon appears on the screen and LAMP REPLACE indicator lights yellow. Replace the lamp with a new one promptly. The timing when the LAMP REPLACE indicator should light is depending on the lamp mode.

  • Page 66: Resetting The Lamp Counter

    Additionally, check carefully to ensure that there are no broken shards or pieces of glass around the projector or coming out from the cooling air circulation holes. Any broken shards found should be cleaned up carefully. No one should check the inside of the projector except those who are authorized trained technicians and who are familiar with projector service.

  • Page 67: Appendix

    Before calling your dealer or service center for assistance, check the items below once again. –Make sure you have properly connected the projector to peripheral equipment as described on pages 19–21. –Make sure all equipment is connected to AC outlet and the power is turned on.
  • Page 68 High voltages are used to operate this projector. Do not attempt to open the cabinet. If problems still persist after following all operating instructions, contact the dealer where you purchased the projector or the service center. Specify the model number and explain about the problem. We will advise you how to obtain service.

  • Page 69: Menu Tree

    Menu Tree Computer Input/Video Input Input Computer 1 (Analog) Computer 1 (Digital) Computer 2 Video Wired Wireless* Memory viewer* Sound Sound Volume Mute Quit Computer Input System SVGA 1 Mode 1 Mode 2 - - - - ✽Systems displayed in the System Menu vary depending on an input signal.
  • Page 70 On/Off On/Off Eco/Normal Ready Shut down Timer (1–30 Min.) Quit On/Off Auto/High/Normal/Eco Spotlight/Pointer Quit Code 1–Code 8 Key lock Projector Remote control Quit PIN code lock Off/On1/On2 PIN code change Quit Alarm Battery charge Off/Auto Alarm volume Small/Medium/Large Sensitivity Low/Medium/High...

  • Page 71: Indicators And Projector Condition

    The projector detects an abnormal condition and cannot be turned on. Unplug the AC power cord and plug it again to turn on the projector. If the projector is turned off again, unplug the AC power cord and contact the dealer or the service center for service and checkup.

  • Page 72: Compatible Computer Specifications

    Appendix Compatible Computer Specifications Basically this projector can accept the signal from all computers with the V-, H-Frequency mentioned below and less than 140 MHz of Dot Clock for analog signal and 110 MHz of Dot Clock for digital signal.
  • Page 73 When the input signal is digital from DVI terminal, refer to the chart below. ON-SCREEN RESOLUTION DISPLAY D-VGA 640 x 480 D-480p 640 x 480 D-575p 768 x 575 D-SVGA 800 x 600 D-XGA 1024 x 768 D-WXGA 1 1366 x 768 D-WXGA 2 1360 x 768 D-WXGA 3...

  • Page 74: Technical Specifications

    1.8” (W) x 1.0” (H) x 5.7” (D) (45 mm x 25 mm x 145 mm) 3.5 oz (99 g) (including batteries) Class II Laser (Max. Output: 1 m W/Wave length: 640–660 nm) SANYO Ni-MH BATTERY PACK 3.6V (Part No. 645 089 8587)

  • Page 75: Optional Parts

    Accessories Owner’s Manual (CD-ROM) Quick Reference Guide AC Power Cord Remote Control and Batteries VGA Cable PIN Code Label Alarm Label Network Application (CD-ROM) Soft Carrying Case USB Wireless LAN Adapter ● The specifications are subject to change without notice. ●...

  • Page 76: Pj Link Notice

    Appendix PJ Link Notice This projector is compliant with PJLink Standard Class 1 of JBMIA (Japan Business Machine and Information System Industries Association). This projector supports all commands defined by PJLink Class 1 and is verified conformance with PJLink Standard Class 1.

  • Page 77: Configurations Of Terminals

    Configurations of Terminals COMPUTER IN 2 /COMPONENT IN /MONITOR OUT (ANALOG) Terminal: Analog RGB (Mini D-sub 15 pin) DVI-I TERMINAL (DIGITAL/ANALOG) C1 C2 USB CONNECTOR (Series A) VCC(5V) – DATA + DATA Ground LAN TERMINAL TX + TX – RX + ----- 8 7 6 5 4 3 2 1 SERVICE PORT CONNECTOR...

  • Page 78: Pin Code Number Memo

    PIN Code Number Memo Write down the PIN code number in the column below and keep it with this manual securely. If you forgot or lost the number and unable to operate the projector, contact the service station. PIN Code Lock No.

  • Page 79: Dimensions

    Appendix Dimensions Unit: inch (mm) 13.15 (334) 3.17 (80.5) Screw Holes for Ceiling Mount Screw: M4 Depth: 0.472 (12.0) 8.9º MAX 5.20 (132) 5.08 (129) 4.43 (112.5)
  • Page 80 KM6AC SANYO Electric Co., Ltd.
