Ordering number : EP58B
Digital TV, Analog TV,
Flat Panel Display, and VCR ICs
'04-2
TOKYO OFFICE
Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
Telephone: 81-(0)3-3837-6339, 6340, 6342, Facsimile: 81-(0)3-3837-6377
•
SANYO Electric Co.,Ltd. Semiconductor Company Homepage
URL; http://www.semic.sanyo.co.jp/index_e.htm
This catalog provides information as of February, 2004. Specifications and information herein are subject to change without notice.
Printed in Japan / February 2004 2k PC Plan
Advertisement
Table of Contents
Related Manuals for Sanyo EP58B
Summary of Contents for Sanyo EP58B
- Page 1 Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN Telephone: 81-(0)3-3837-6339, 6340, 6342, Facsimile: 81-(0)3-3837-6377 • SANYO Electric Co.,Ltd. Semiconductor Company Homepage URL; http://www.semic.sanyo.co.jp/index_e.htm This catalog provides information as of February, 2004. Specifications and information herein are subject to change without notice.
-
Page 2: Table Of Contents
These flash memory products are manufactured and sold by SANYO Electric Co., Ltd. under license from Silicon Storage Technologies, Inc. (SST). Any and all SANYO products described or contained herein do not have specifications that can handle applications that require extremely high levels of reliability, such as life-support systems, aircraft's control systems, or other applications whose failure can be reasonably expected to result in serious physical and/or material damage. -
Page 3: Digital Tv Decoder System Chipset
Muting circuit block Muting transistor series series SANYO 480i / 480p down decoder chipsets support both digital satellite SANYO 480i / 480p down decoder chipsets support both digital satellite broadcast and digital terrestrial broadcast reception and broadcast and digital terrestrial broadcast reception and are optimal for compact and popularly-priced TV sets. -
Page 4: Digital Tv Ts + Audio + Video Decoder Ic With Built-In Osd Function
DAC I/F DIT(PCM&encoded stream) (Main output: video recording output) SANYO TV . VCR Overview The LC74186E is 32-bit microcontroller for digital TV that uses the IBM PowerPC as its CPU core and integrates on a single chip a wide range of peripheral functions, including UART, I control, and external bus control functions. -
Page 5: Flat Panel Display Video Signal-Processing Ics
Home AV Equipment Related Devices Home AV Equipment Related Devices SANYO has created video signal processing ICs that adopt high image quality scan SANYO has created video signal processing ICs that adopt high image quality scan converter technology and are optimal for flat panel displays. -
Page 6: Scan Converter Ic For Flat Panel Displays
Y Cb Cr Y Cb Cr External Select voltage signals Black stretch Data Select SANYO TV . VCR The LA7605M is a flat panel display color TV signal-processing I worldwide. DCLKI Output Timing XTAL AIDA AICS* Input Timing CLKIEN Select... -
Page 7: 8-Bit Flash Microcontroll
Package: QIP64E (14 14), SQFP64 (10 10) This flash memory product is manufactured and sold by SANYO Electric Co., Ltd. under license from Silicon Storage Technologies, Inc. (SST). SANYO TV . VCR... -
Page 8: Color Tv I 2 C Bus System Chip Set
Horizontal deflection output transistor series Video output transistor series Ultralow on-resistance MOSFETs SANYO supports end product design and manufacture appropriate for all markets SANYO supports end product design and manufacture appropriate for all markets with a full product line of color TV I... -
Page 9: Built-In Ctv Microcontroller Signal-Processing System Ics
Support for Worldwide Markets with All-in-One ICs A newly-developed signal-processing IC, a microcontroller, and even a CCD. There is no one other than SANYO who has included so much functionality in a single package. Additionally, series deployment with pin-to-pin compatibility* means that users can handle TV signal standards in different markets around the world by changing only certain specific components. -
Page 10: Signal-Processing Ic With Integrated Microcontroller
9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 KEY-IN AFT V DD SANYO TV . VCR The LA76919M and LA76922M series are I TV set design, improved manufacturability, and lower total costs. -
Page 11: C Bus Control Lineup La76810 Series
REST ERIGHT IF AGC CONTRAST RF AGC CLAMP V CC AUDIO OUTPUT FILTER V CC 5V RF AGC IF IN SANYO TV . VCR SECAM SEOAM-KIL DECODER V CC 5V CCD/ CLAMP APC2 1H DELAY DC ADS. 1/256 CLAMP COLOR... - Page 12 ERIGHT RF AGC CLAMP V CC 0.01 F AUDIO OUTPUT FM OUT RF AGC 100 F FILTER IF IN SANYO TV . VCR CWOUT X-RAY C_ IN FBP IN V CC 5V 0.47 F 1H-DL/ V CC 9V X-RAY H-OUT...
- Page 13 IC. The color TV vertical deflection system adjustment function can be controlled from the bus system when this IC is used in conjunction with a SANYO LA768X or LA769XX series TV bus control system signal- processing IC.
- Page 14 IC. The color TV vertical deflection system adjustment function can be controlled from the bus system when this IC is used in conjunction with a SANYO LA768X or LA769XX series TV bus control system signal-processing IC.
- Page 15 IC. The color TV vertical deflection system adjustment function can be controlled from the bus system when this IC is used in conjunction with a Sanyo LA768X or LA769XX series TV bus control system signal- processing IC.
- Page 16 IC. The color TV vertical deflection system adjustment function can be controlled from the bus system when this IC is used in conjunction with a SANYO LA768X or LA769XX series TV bus control system signal-processing IC.
-
Page 17: Vertical Output Ics
IC. The color TV vertical deflection system adjustment function can be controlled from the bus system when this IC is used in conjunction with a SANYO LA768X or LA769XX series TV bus control system signal-processing IC. - Page 18 The color TV vertical deflection system and EW adjustment functions can be controlled from the bus system when either of these ICs is used in conjunction with a Sanyo LA768X or LA769XX series TV bus control system signal-processing IC. The LA7847 provides a maximum output block voltage of 72 V, a maximum deflection current of 2.2 A p-p, and an EW drive current of 0.4 A, and thus is...
- Page 19 The LC863 Series products are high functionality high-speed 8-bit CMOS single-chip microcontrollers that provide OSD functionality. Since SANYO provides a full series of flash ROM versions instead of the earlier erasable EPROM and one-time programmable PROM versions, this series can easily respond to needs for rapid specification changes during mass production ramp up and for specification changes by target application.
-
Page 20: Tv Control Microcontrollers (Lc863 Series)
VRAM Watchdog timer SANYO TV . VCR Series (NTSC) The LC8633/LC8635/LC863BXX Series are TV control 8-bit microcontrollers that integrate an extensive set of peripheral functions around a CPU core that operates with a minimum cycle time of 0.424 s. The peripheral functions include 16 to 64 KB of program... -
Page 21: Vhs Format Vcr System Chip Set
At the same time as providing high quality and high reliability with adjustment-free ICs, SANYO is striving for even further reductions in mounting area by incorporating even SANYO is striving for even further reductions in mounting area by incorporating even more peripheral components in the IC itself and by increasing integration densities. - Page 22 Built-in mixer and oscillator regulator Supply voltage: V CC = 5 V Package: SSOP24 (275 mil) Block Diagram SANYO TV . VCR Tuner IC LV4512V Overview The LV4512V integrates local oscillator circuits for the VHF and UHF bands, mixers, an IF amplifier, and a PLL circuit for tuning on a single chip.
-
Page 23: Vif/Sif Signal-Processing Circuit
TRAP 300k 0.01 F 300k VCO COIL 39pF 39pF VIDEO OUT 10 H SANYO TV . VCR IF INPUT V CC (5V) V CC (9V) 0.01 F RF AGC OUT 0.1 F AFT OUT PAL SW V CC : 39.5MHz OPEN : 38.9MHz... - Page 24 TRAP (25) (26) (27) (1,2) 0.47 F 150k SW10 330P 1000P VIDEO SYSTEM SW SYSTEM SW OUTPUT VIF FREQ SANYO TV . VCR SW15 SAWF SW13 (13) (12) MODE CTRL (10) (11) AFT OUTPUT 1000P V CC SW11 270k 4.43/4MHz...
- Page 25 5.6k SAW(P) AF OUT 0.015 F 10k -B 0.022 F 0.01 F VIDEO 100 F 0.01 F 0.47 F 15 H SANYO TV . VCR RF AGC 100k 1000pF 0.01 F 100k V CC 2.2k VIDEO VIF/SIF Signal-Processing Circuit LA75676V/676VA Overview The LA7576V and LA7576VA are NTSC intercarrier VIF/SIF ICs that adopt a partially adjustment-free circuit structure.
-
Page 26: Pal Hi-Fi Audio Signal Record And Playback Processing
100 F 0.01 F SANYO TV . VCR The LA72648M is a PAL format system IC that adds a CANAL switch to the Hi-Fi audio signal-processing functions of earlier devices and aims at even lower power operation in power saving modes. -
Page 27: Hi-Fi Signal Processing Hifi Processing With Built-In Audio Multiplex Decoder For Us Market Products
0.1 F 10 F 22 F ALWAYS 5V Normal OUT EXT1 IN (L) Monitor EXT2 IN (L) IN(L) EXT3 IN (L) SANYO TV . VCR MUTE MODE OUT AF SW CLOCK DATA LOGIC D GND MONITOR 10 F 0.01 F... -
Page 28: Video And Audio Signal-Processing Ic
330k 4.7 F 2SC3331 10 F 2.2k LINE OUT TO MICOM 0.01 F (PB-Low) 1000 P 2SC3331 SANYO TV . VCR PB C OUT ALWAYS V CC REC C MONI 680k 0.01 F 4Fsc 0.01 F 4F sc ALWAYS CLOCK... -
Page 29: Vcr Secam Chrominance Signal-Processing Ic
HD-SW A-V CC DET C-GND 1200P 2SC3331 1.2k 5.6k 0.01 F 1200P 2SA1318 2SC3331 SANYO TV . VCR CANAL DECODER VPS OUT (1Vpp) TITLE IN STANDBY MODE DECODER SW1 FIXED ON IN1 SW2 FIXED ON IN3 SW3 FIXED ON IN2... -
Page 30: On-Screen Display Controller Ic
(CHABLK) (MUTE) SANYO TV . VCR The LC74789, LC74789M, and LC74789JM are on-screen display CMOS ICs that display text and patterns on the TV screen under control of a microcontroller. The LC74789, LC74789M, and LC74789JM display 12 18 dot characters in a display area of 12 lines by 24 columns. -
Page 31: Vps/Pdc Slicer Ic
Xtal IN Xtal OUT (CHABLK) (MUTE) SANYO TV . VCR The LC74793 and LC74793JM are PDC/VPS/UDT interface CMOS ICs. The operating mode can be set and the data acquired in the various modes can be read out by a microcontroller. Blinking... -
Page 32: Vhf Band Rf Module
Block Diagram MIXER ANT SW BIAS DRIVER WHITE CLIP CLAMP SANYO TV . VCR CARRIER OFF SW CHANNEL VHF Band RF Module LA77000V Overview The LA77000V is a VHF band RF module that supports channels 3 and 4 in the US. -
Page 33: Pwm Capstan + Sensorless Drum + Loading Motor Drivers
Upper side non saturatc circuit D_CNT D_FC D_PG D_PG L_OUT1 D_PGO1 D_PGO2 L_IN L_VREI SANYO TV . VCR Package Dimensions Package Dimensions [Loading Motor Drive Block] H bridge forward/reverse function Motor voltage switching function Short-circuit braking function Three-value input control 1.38 DIP24S(300mil) -
Page 34: Package Dimensions
15.2 0.15 12.5 0.15 (0.6) (0.75) 0.35 MFP36SD(375mil) MFP36SDJ(375mil) MFP36SD(375mil) MFP36SDJ(375mil) 15.2 15.2 0.25 (0.8) 0.25 (0.8) SANYO TV . VCR (Reference Drawing) (unit:mm) QIP100EJ(14 20) QIP100EJ(14 20) 23.2 20.0 0.15 0.15 0.65 0.25 (0.58) MFP24(375mil) MFP24(375mil) 15.2 (0.68) 1.27 0.15...
