Page 1
Leggere attentamente questo manuale d’istruzioni prima di utilizzare il monitor LCD. Vi ringraziamo per aver scelto un monitor LCD Sanyo che vi consentirà di trascorrere momenti piacevoli e divertenti. Lea este manual de instrucciones antes de usar su nuevo monitor. Deseamos que disfrute de él muchas horas.
Page 2
Neutral Live Important recycling information. Your SANYO product is designed and manufac- tured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be dis- posed of separately.
General This End-User License will be governed by laws of England and the User may only bring claims in the English Courts and SANYO shall be entitled to bring a claim in the courts of any jurisdiction. The above terms and conditions supersede any prior agreement, you may not;...
Step : 1 Connections (Essential) ■ REMOVE TERMINAL COVER AS INDICATED BELOW. Security fixing point ■ CONNECT THE DISPLAY UNIT TO AERIAL, VGA. BNC.AND SCART CONNECTOR AS BELOW. ■ TERMINAL COVER MUST BE REPLACED WITH CABLE EXITS AS INDICATED IN THE SKETCH ABOVE. Security fixing point Wall mount...
Terminals 1. The LCD display will have a Standby light to show there is power. 2. Control buttons (bottom edge of cabinet) Menu/F button: rotate between contrast, Brightness, colour and sharpness Input/ OK button: s witch between TV, AV1, RGB, AV2, AV3, HDMI and PC mode.
TV/AV switch To switch from TV, AV1, RGB, AV2, AV3, PC or HDMI mode press repeatedly. Press and hold in a few seconds, an AV selection bar appaers. Select the mode you require using the Screen mode selector To select the screen mode, Auto, Natural, Full Zoom 16:9, Title 16:9,Zoom 14:9,title 14:9 or Normal.
Setting menu Setting Child lock OFF / ON OSD Language English Timer Text Language Greek/ East/ West/ Cyrillic : Select : Adjust ■ Child lock You can prevent unwanted operation on the LCD monitor via the buttons on the bottom edge of the monitor. 1.
Preset Menu ■ Program sort. Use this channel moving feature to move the channels between two programme positions. This feature is particularly useful after auto- matic tuning. Program sort Move You have to choose a programme that you wish to move from one position to another.
PC menu settings Connect your PC to the connector on the left side terminal of the set. Once connected select PC mode via the v button on your remote control. The set will become a monitor for the PC. By pressing the MENU button on the remote control a menu window will appear on screen, this allows the settings to be adjusted.
Direct access to page. All the numeric buttons can be used to select a page number directly. If you need page 301, then press 3 then 0 and then 1. Sub page access. Some text pages are made up of severall sub pages which rotate automatically.
Selecting of picture size ■ Screen options Today there are various transmission formats with different size ratios, eg. 4:3 , 14:9, 16:9 and video formats such as letterbox. ■ Auto It automatically switches to the optimum screen mode according to the WSS signal provided in the receiving signal source.
Input: Composite video Output: Composite video Audio M.Out: CINCH L/R HDMI Input : HDMI GROUP Standard Input Serial port RS232C: Input/ output CE32LM4WPR-E Contrast Ratio 1000:1 Screen(inches/ cm) 32” / 81 cm (viewing measured diagonally) Display Resolution 1366 X 768 (WXGA) Viewing angles H:176°, V:176°...
Page 13
HDMI / COMPONENT SIGNAL SUPPORT TIMING LIST HD MI si gna l supp ort timing HD MI si gna l supp ort timing Format Timing Format Timing Description Description 60Hz Forma ts 60Hz Forma ts 480p 480p 480p 480p 720p 720p 1080i 1080i...
