Honeywell V8205 Installation Instructions Manual

Direct ignition combination gas controls

Advertisement

Quick Links

These direct ignition gas controls are used in gas-fired
appliances with up to 200 cfh capacity on natural gas. They
include safety shutoff, a manual valve, one or two auto-
matic operators and a pilot adjustment. See Table 1 for
model differences and Table 2 for temperature ranges and
regulator types.
BODY PATTERN: Straight through with 1/2 in. inlet
and 1/2 in. outlet.
PIPE ADAPTERS: Angle and straight adapters available
for 3/8, 1/2 and 3/4 in. pipe. See Table 3.
TABLE 1—DIRECT IGNITION COMBINATION GAS CONTROL MODELS.
Model
Frequency
V8205
24V/60 Hz
VR8205
24V/60 Hz
TABLE 2—MODEL NUMBER
SUFFIX LETTER DESIGNATION.
Model No.
Ambient
Suffix
Temperature
Letter
Range
A
0° F to 175° F
[-18° C to 79° C]
C
H
K
-40° F to 175° F
[-40° C to 79° C]
M
P
TABLE 3—FLANGE PART NUMBERS.
Inlet/Outlet
Flange
Pipe Size
Type
3/8 in. NPT
Straight
Elbow
1/2 in. NPT
Straight
Elbow
3/4 in. NPT
Straight
Elbow
V8205, VR8205 Direct Ignition
Combination Gas Controls
Installation Instructions for the Trained Service Technician.
Voltage/
Automatic Operators
Regulator
Type
Standard
Step-opening
Slow-opening
Standard
Step-opening
Part No.
Less Hex
With Hex
Wrench
Wrench
393690-1
393690-11
393690-2
393690-12
393690-6
393690-16
393690-3
393690-13
393690-4
393690-14
393690-5
393690-15
G. S. • Rev. 12-93 • ©Honeywell Inc. 1993 • Form Number 69-0329—4
These gas controls are factory-set for natural (and manu-
factured) gas or LP gas. Do not attempt to use a control set
for natural (manufactured) gas on LP gas, or a control set
for LP on natural (manufactured) gas.
Controls with standard or slow opening regulators can be
converted from one gas to the other with a conversion kit
(ordered separately). Order part no. 393691 to convert from
natural (manufactured) to LP gas; order part no. 394588 to
convert from LP to natural (manufactured) gas. Controls
with step opening regulators cannot be converted.
Number of
One
Two
NOTE: Flange Kits include one flange with attached O-ring
and four mounting screws. TRADELINE
9/64 in. hex wrench, as noted.
APPROVALS:
American Gas Association design certificate: L2025006.
Canadian Gas Association design certificate: L2025006.
Australian Gas Association design certificate: 4214.
Approved for Delta C applications.
WHEN INSTALLING THIS PRODUCT...
1. Read these instructions carefully. Failure to follow
them could damage the product or cause a hazardous condi-
tion.
2. Check the ratings given in the instructions and on the
product to make sure the product is suitable for your appli-
cation.
3. Installer must be a trained, experienced service tech-
nician.
4. After installation is complete, check out product op-
eration as provided in these instructions.
1
Application
Gas Control
Knob Positions
OFF-ON
OFF-ON
Installation
Current Draw
0.30A
0.5A
®
kits include a
69-0329—4
