Thule XADAPT8 Installation Instructions

Download this manual

PARTS INCLUDED

part

61mm T-bolt

35mm T-bolt

Follow these instructions in conjunction with the 597 Super G or 598 Criterium Bike Carrier instructions for

mounting onto the Thule Xsporter Truck Rack or

• Install barrel nut into cam handle (included with bike carrier).

• Follow the chart below for proper bolt length required for your application.

Front bar

Rear bar

• Insert appropriate length t-bolts into front and

rear bar as shown.

description

Aero bar

application.

597 Super G

61mm x 2

61mm x 1

part number

853-2089-07

853-2089-08

598 Criterium

61mm x 2

35mm x 1

Aero Bar

qty.

Page 1: Parts Included
35mm T-bolt 853-2089-08 Follow these instructions in conjunction with the 597 Super G or 598 Criterium Bike Carrier instructions for mounting onto the Thule Xsporter Truck Rack or Aero bar application. • Install barrel nut into cam handle (included with bike carrier).
Page 2 • Place carrier on load bars and align bolts with holes in mounting plates. • Fasten carrier to bars with t-bolt and handles. • Use the handle with lock hole on bike loading side of front mounting plate. • Rotate handle to tighten. •...
