Page 1: User Manual
Power Zoom Camera ENGLISH.indd 1 User Manual imagine the possibilities Thanks you for purchasing this Samsung product. To receive a more complete service, please visit our website www.samsungsecurity.com SCC-C4253P SCC-C4353P SCC-C4255P SCC-C4355P 2009-9-10 13:53:4... - Page 2 overview CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING To reduce the risk of fire or electric shock, do not expose this appliance to rain or ...
- Page 3 Continued use in such a condition may cause fire or electric shock. If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifications or attempted repair.) When cleaning, do not spray water directly onto parts of the product.
- Page 4 overview FCC STATEmENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : 1) This device may not cause harmful interference, and 2) This device must accept any interference received including interference that may cause undesired operation.
-
Page 5: Important Safety Instructions
ImPORTANT SAFETy INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers) that produce heat. -
Page 6: Table Of Contents
overview CONTENTS INSTALLATION & _ overview ENGLISH.indd 6 OvERvIEW CONNECTION SETUP APPENDIx Important Safety Instructions Contents Features What’s Included At a Glance Preparing Installation Installation Main Menu Profile Camera Set Intelligent Video Privacy Zone Preset Other Set Communication System Info Language Shortcut Keys Specifications... -
Page 7: Features
processing and special algorithm of 600-line high resolution implemented. High Sensitivity: It implements images of high sensitivity using the up-to-date Super-HAD IT CCD(SCC-C4253P/C4353P)/ExView-HAD PS CCD(SCC-C4255P/ C4355P). VPS(Virtual Progressive Scan): This is an advanced technology that reproduces a sharp progressive image. This is appropriate to high quality recording and file transfer via the Internet. -
Page 8: What's Included
overview WHAT’S INCLUDED Please check if your camera and accessories are all included in the product package. Camera AT A GLANCE SIDE vIEW Wipe out a dirty surface of the lens softly with a lens tissue or cloth to which you have applied ethanol. -
Page 9: Rear Panel
� Rear Panel � SCC-C4353P � � � � � � SCC-C4253P � � � Input/Output Connector This connector has input and output ports for RS-485 control signals, DAY/NIGHT switching, and alarm output signals. ENGLISH.indd 9 � � �... - Page 10 overview 1. ALARM OUT Alarm out jack for motion detection. (Open Collector, On Gnd) 2. GND Grounding jack. 3. TRIGGER IN (SCC-C4255P/C4355P) Displays the current still image when it receives the Trigger signal. (Normal Open Type) 4.5.6 FOCUS, COM, ZOOM This port is used for ZOOM/FOCUS, MENU CONTROL, HOME RETURN, and ONEAF by using an external controller.
- Page 11 * 2 : For short voltage supply during MENU OFF, executes ONEAF and for more than 2 second * 3 : For more than 2 second long voltage supply, moves to the PRESET 0(HOME) position. 7. 5V OUT Power supply jack for RS-485 JIG. Use within typical DC +5V 100mA. 8.
-
Page 12: Preparing Installation
Power Adapter Cable (sold separately) The requirements for the power adapter, which connects to the camera’s POWER IN terminal, are as follows: - SCC-C4253P/C4255P : DC 12V 600mA - SCC-C4353P/C4355P: AC 24V 300mA Cable(sold separately) video Use a BNC cable, such as the one shown below, to connect the camera’s VIDEO OUT to the monitor. - Page 13 BNC cable(not included) 3. Plug in the power adapter(not inlcluded). Use a “minus” screwdriver to connect one part of the power adapter, which consists of two lines, to the POWER terminal of the camera as follows : ENGLISH.indd 13 Video In Terminal of Monitor Rear Surface Video Out Terminal 1.
- Page 14 - Signaling Speed: 9600 bps - Data Bit : 8 bits - Stop Bit : 1 bit - Parity Bit : none 1_ installation & connection ENGLISH.indd 14 TYPE 4_ZOM_WDR_P PROTOCOL SAMSUNG ADDRESS COMM.TYPE RS485,HALF BAUD RATE 9600 CAMERA VER. V1.00_090817 LENS...
-
Page 15: Main Menu
setup Using OSD icons _+: If these icons appear in the left and right corner of a menu item, you can use them move to the previous or next menu. (EXIT): Exits the menu setup screen. (RET): Saves your settings and returns to the previous screen. ... -
Page 16: Profile
setup COmmUNICATION Configures the settings pertaining to RS-485 communication. SySTEm INFO Shows the system information such as the camera version or communication settings. LANGUAGE Select a preferred one from the supported languages. PROFILE You can select one from the pre-determined configurations as appropriate to your specific camera installation environment. - Page 17 CAmERA SETUP mENU Parent menu Sub-menus BACKLIGHT IRIS WDR LEvEL Custom Setting Custom Setting WHITE BAL Custom Setting Custom Setting Custom Setting Custom Setting Custom Setting mOTION SHUTTER SENSE UP NIGHT DAy/NIGHT WHITE BAL NIGHT BRIGHTNESS DETAIL ENGLISH.indd 17 STANDARD LEvEL WEIGHT Custom Setting Custom Setting (F.FAST)
-
Page 18: Camera Set
setup CAmERA SET You can configure the general settings of the camera module. Select <mAIN mENU> - <CAmERA SET>. The Camera Setup menu appears. Change the settings as necessary, or select an item to check. CAmERA ID Provide the ID and location for a camera that displays on the screen. Select <CAmERA SET>... - Page 19 IRIS The IRIS menu is useful if you set to adjust the intensity of radiation incoming to the camera. ALC : Adjust the open and close of the iris. - LEVEL : Select an overall brightness level. - BLC : With <BACKLIGHT> set to <BLC>, you can specify the BLC area.
- Page 20 setup With this, you can adjust the AGC level of a camera. With AGC active, if the signal strength falls below the standard level, AGC will amplify the video signal to automatically improve the sensitivity. If <SENS-UP> is set to <OFF> or <FIx> mode, the <mOTION>...
- Page 21 SHUTTER You can select a fixed fast electronic shutter speed in 7 options ranging from 1/120 to 1/10k, which is mostly used to take a picture of a fast moving object. As long as SENSE UP is set to AUTO, FIXED / FLICKERLESS to ON / BACKLIGHT to WDR, the SHUTTER menu is not available.
- Page 22 setup DAy/NIGHT You can specify a recording mode according to the scene. Select <CAmERA SET> - <DAy/NIGHT>. Select a screen transition mode according to the illumination, and set options as appropriate. DAY : Fixed to DAY mode, regardless of the scene.
-
Page 23: White Bal
If <BACKLIGHT> is set to <BLC>, the MASK AREA function is not available. EXT : The interface to an external alarm enables an automatic switch between DAY and NIGHT mode. If you use an infrared light source while in AUTO mode, this may cause a failure in AUTO SWITCH or AUTO FOCUS. - Page 24 setup Select <CAmERA SET> - <WHITE BAL>. Select a mode where you set the <WHITE BAL>. DAY : You can set the RED, and BLUE value in DAY mode. The screen will be displayed in colors according to your settings. You can set the R-GAIN, and B-GAIN value only in <AWC>...
-
Page 25: Focus Mode
FOCUS mODE You can select a focus mode according to the angle that you adjusted for camera recording. - AF : This will monitor the screen continuously to focus automatically. If you adjust the focus manually, that will operate the same as in <mF>. - Page 26 The LL-PHASE can be adjusted as appropriate. It’s a must to use AC 24V power supply when you select line lock for SCC-C4353P and SCC-C4355P. Line lock is not available for SCC-C4253P and SCC-C4255P. AGC COLOR SUP You can adjust the color reproduction range according to AGC.
-
Page 27: Intelligent Video
If you set the digital zoom to a larger ratio than the actual enlargement for compensation, the <DIS> function will be disabled. <DIS> may not work properly in the following images: Flat, i.e., no regular-patterned image / Low contrast scene / High frequency image taken under a fluorescent lamp / Regular-patterned image. -
Page 28: Alarm Out
setup mASK AREA Select the number of the area to be masked that will be excluded from motion detection. Select the mask number and set the mask size and its coverage. DISPLAy When selected <ON>, it displays the motion detected and detection of configured advanced function. -
Page 29: Privacy Zone
PRIvACy ZONE You can set up to 12 privacy zones that will be hided for privacy of the subject when recording. Zone Setup Select <mAIN mENU>-<PRIvACy ZONE>. Select the number of the zone and press [ENTER]. The Zone setup screen appears. Select the <ZOOm>... -
Page 30: Preset
setup PRESET This function provides preset camera settings such as zoom and focus so to enable quicker and easier accessing and monitoring, which supports up to 512 presets. Select <mAIN mENU>-<PRESET>. Select the preset number. Select <POSITION>. Set <PRESET ID> to <ON> and enter the name. -
Page 31: Other Set
OTHER SET You can reset the system by running FACTORY DEFAULTS, or set the font color etc. Select <mAIN mENU>-<OTHER SET>. Select each item and set appropriately. ExTERNAL TRG Set the EXTERNAL TRG menu to ON and press the SETUP switch to display the appropriate screen. -
Page 32: Communication
BAUD RATE ADDRESS TYPE PROTOCOL ADDRESS COMM. TYPE BAUD RATE SERIAL NO. CAMERA VER. Near COMMUNICATION SAMSUNG 9600 SYSTEM INFO 4 _ ZOM _ WDR _ N SAMSUNG RS485, HALF 9600 000000000000000 v1.00 _ 00000 2009-9-10 13:53:5... -
Page 33: Language
LANGUAGE You can set the language of the user interface. Select <mAIN mENU>-<LANGUAGE>. Select your language using the up/down keys. ENGLISH.indd 33 LANGUAGE ENGLISH FRANÇAIS DEUTSCH ESPAÑOL ITALIANO English _ 2009-9-10 13:53:5... -
Page 34: Shortcut Keys
appendix SHORTCUT KEyS You may control this camera by using Controller (SSC-5000). IRIS – ALC – BACKLIGHT – WDR CAmERA SET IRIS – ALC – BACKLIGHT – OFF Function _ appendix ENGLISH.indd 34 Function DAY/NIGHT - DAY DAY/NIGHT - NIGHT DAY/NIGHT - AUTO DAY/NIGHT - EXT IRIS - ALC... -
Page 35: Specifications
Horizontal : 15, 625 Hz (INT) / 15, 625 Hz (L/L) Vertical : 50 Hz (INT) / 50 Hz (L/L) INT/LINE LOCK (LINE LOCK is not available for SCC-C4253P/C4255P) Horizontal : 600 TV LINES (color) Vertical : 350 TV LINES... - Page 36 High Speed: OFF~1/10K sec Low Speed: OFF~X512 2x ~ 16x ATW1/ATW2/AWC/MANUAL Mode (3200°K, 5600°K, R/B Gain adjustment) -10°C~+50°C ~90% SCC-C4253P/C4255P : 59mm x 59.2mm x 124.2mm SCC-C4353P/C4355P : 59mm x 59.2mm x 154.5mm SCC-C4253P/C4255P: 421g, SCC-C4353P/C4355P: 564g silver 2009-9-11 15:32:4...
