  • Page 1 Test Report No.: GETEC-E3-07-007 FCC Class B Certification APPENDIX H : USER’S MANUAL EUT Type: 42” LCD Monitor FCC ID: BEJM4210CE...
  • Page 2 User's guide M4210C...

  • Page 3: Safety Precautions

    Safety Precautions Please read these safety precautions carefully before using the product. If you ignore the warning message, you may be seriously injured or there is a possibility of Warning accident or death. Caution If you ignore the caution message, you may be slightly injured or the product may be damaged Precautions in installing the Product Warning Keep away from heat sources like electrical heaters.

  • Page 4: Precautions In Moving The Product

    Safety Precautions Electrical Power Related Precautions Warning Make sure to connect the power cable to the grounded current. - You may be electrocuted or injured. Use the rated voltage only. - The product can be damaged, or you may be electrocuted. During a thunder or lightning storm, unplug the power cable or signal cable.
  • Page 5 Safety Precautions Caution Do not shock the product when moving it. - You may be electrocuted or the product can be damaged Do not dispose the product-packing box. Use it when you move. Make the panel face forward and hold it with both hands to move. - If you drop the product, the damaged product can cause electric shock or fire.

  • Page 6: Using The Remote Control

    • Auto Button There is not a function Automatic adjustment function which is supported (Operational for the analog signal only) • ARC button To select the image size of the screen. • Video Operation Button Applicable for LG products only...

  • Page 7: Inserting Batteries Into Remote Control

    Using the Remote Control • AV Button • Input Select Button Each time you press the Input button it will change to If you press the button once, Component1 the following Input Signal Component2 Window will appear. Select HDMI/DVI the signal type you want using the button.

  • Page 8: Connecting The Speakers

    Connecting the Speakers * Applicable only for models that support the speakers Use the screws to secure the speakers on the rear side of the product as shown in the below figure. When the speaker is installed.

  • Page 9: Name And Function Of The Parts

    Name and Function of the Parts * The product image in the user’s guide could be different from the actual image. Rear View REMOTE RS-232C HDMI/DVI IN RGB IN AUDIO COMPONENT IN AV IN CONTROL IN (CONTROL& (RGB/DVI) VIDEO L-AUDIO-R VIDEO L-AUDIO-R SERVICE)

  • Page 10: Connecting To External Devices

    Connecting to External Devices When Connecting to your PC First of all, see if the computer, product and the peripherals are turned off. Then, connect the signal input cable. When connecting with the D-Sub signal input cable. When connecting with the HDMI to DVI signal input cable (not included). RGB IN Rear side of the product.
  • Page 11 Connecting to External Devices Turn on power by pressing the power button on the product. SOURCE AUTO/SELECT ON/OFF ON/OFF Power button Turn on the PC. Select an input signal. Press the INPUT button on the remote control to select the input signal. INPUT Or, press the SOURCE button at the front side of the product.

  • Page 12: Watching Rgb Outputs

    Connecting to External Devices Watching RGB Outputs Use this function when displaying ANALOG RGB inputs of a PC to the other product. To use different products connected to each other • Connect one end of the signal input cable(15-pin D-Sub Signal Cable) to the RGB OUT connector of product 1 and connect the other end to the RGB IN connector of other products.

  • Page 13: When Watching Vcr / Dvd

    Connecting to External Devices When watching VCR / DVD Connect the video cable as shown in the below figure and then connect the power cord (See page A9). When connecting with a S-Video cable. When connecting with a BNC cable. Connect to the S-Video input terminal to •...
  • Page 14 Connecting to External Devices When watching HDTV/DVD(480p/576p/720p/1080i/480i/576i) Connect the video/audio cable as shown in the below figure and then, connect the power cord (See page A9). Connect the input terminal with a proper color match. • Product Product COMPONENT IN VIDEO COMPONENT IN L-AUDIO-R...
  • Page 15 Connecting to External Devices When watching HDMI/DVI/RGB from the VCR/DVD/Set-top Box (480p/576p/720p/1080i) Connect the video/audio cable as shown in the below figure and then connect the power cord (See page A9). Product Product Product HDMI/DVI IN RGB IN AUDIO HDMI/DVI IN RGB IN AUDIO HDMI/DVI IN...

  • Page 16: Watching Av Outputs

    Connecting to External Devices Watching AV Outputs • When you set the input signal of the main screen as 'AV (CVBS)', you can transmit the signal that you're watching to the AV output terminal. Video/TV BNC Cable Audio Cable (not included) (not included) AV IN VIDEO...

  • Page 17: To Arrange Cables Using Cable Management

    To arrange cables using cable management Arrange the cables in the center as shown in the following picture. REMOTE RS-232C HDMI/DVI IN RGB IN AUDIO COMPONENT IN AV IN CONTROL IN (CONTROL& (RGB/DVI) VIDEO L-AUDIO-R VIDEO L-AUDIO-R SERVICE) RGB OUT S-VIDEO Fit the cable management to the Holder Groove downwards.

  • Page 18: Attaching The Product To A Wall

    Attaching the product to a wall * Applicable only for models that support the stand • Set it up close to the wall so the product doesn't fall over when it is pushed backwards. The instructions shown below is a safer way to set up the product, which is to fix it on the wall so the product doesn't fall over when it is pulled in the forward direction.

  • Page 19: Selecting And Adjusting The Screen

    Selecting and Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit SOURCE AUTO/SELECT ON/OFF ON/OFF • Press this button to turn on the power. Press this button again to Power Button turn it off. • This Indicator lights up green when the display operates normally(on Power Indicator mode).
  • Page 20 Selecting and Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit [For PC Analog signal] AUTO/SELECT Button Auto in progress For opimal display change resolution to 1360 X 768 [When XGA Mode is active and 1360 X768 is selected] SOURCE Button SOURCE AUTO/SELECT...

  • Page 21: Osd Menu

    Selecting and Adjusting the Screen OSD Menu Icon Function Description Adjusts screen brightness, contrast and color that you prefer. PICTURE Adjusts the audio function. SOUND Adjusts the timer function. TIMER Adjusts the screen status according to the circumstances. SPECIAL Adjusts the screen video. SCREEN Note OSD(On Screen Display)

  • Page 22: How To Adjust The Osd (On Screen Display) Screen

    Selecting and Adjusting the Screen How to adjust the OSD (On Screen Display) screen Save Pops up Move where Move where Exit from the Select a Select a Adjust the status adjustment the menu you want to you want to menu screen.

  • Page 23: Adjusting Screen Color

    Selecting and Adjusting the Screen Adjusting Screen Color Advanced Reset The PSM function automatically adjusts the screen image quality depending on the AV usage environment. • Dynamic : Select this option to display with a sharp image. • Standard : The most general and natural screen display status. •...
  • Page 24 Selecting and Adjusting the Screen Adjusting Screen Color XD is LG Electronics unique picture improving technology to display a real HD source through an advanced digital signal processing algorithm. It's not available to use this function in RGB-PC or HDMI/DVI PC modes.

  • Page 25: Adjusting The Audio Function

    Selecting and Adjusting the Screen Adjusting the audio function Balance Speaker The best sound tone quality will be Surround MAX selected automatically depending on the Flat video type that you're currently watching. Balance Music Movie Speaker Sports User • Surround MAX : Set the Surround MAX on. This function plays back the mono or stereo sound input with the dynamic surround effects.

  • Page 26: Adjusting The Timer Function

    Selecting and Adjusting the Screen Adjusting the timer function Clock Off time On time Auto sleep Clock If the time is on the clock is incorrect, reset the clock manually. 1) Press the MENU button and then use button to select the TIME menu. 2) Press the button and then use button to select the Clock menu.

  • Page 27: Selecting The Options

    Selecting and Adjusting the Screen Selecting the options Language Child lock ISM Method Set ID Tile Mode Power Indicator Logo light Demo Language To choose the language in which the control names are displayed. Child lock Use the buttons to select On or Off. The Set can be set up so that it can only be used with the remote control.
  • Page 28 Selecting and Adjusting the Screen Selecting the options To use this function • - Must be displayed with various other products. - Must be in a function that can be connected to RS-232C or RGB Out Tile mode It is used to enlarge the screen and Language Tile Mode also used with several products to...
  • Page 29 Selecting and Adjusting the Screen Selecting the options - Tile mode (product 1 ~ 9) : r(3) x c(3) ID 3 ID 1 ID 2 ID 4 ID 5 ID 6 column ID 9 ID 7 ID 8 - Tile mode (product 1 ~ 2) : r(2) x c(1) ID 1 ID 2 column...
  • Page 30 Selecting and Adjusting the Screen Selecting the options Language Tile Mode Child lock Tile ID ISM Method H-Size Set ID V-Size Tile Mode H-Position Power Indicator V-Position Logo light Reset To set Demo Select the location of the Tile by setting an ID. •...

  • Page 31: Adjusting Screen Clock/Phase And Position

    Selecting and Adjusting the Screen Adjusting Screen CLOCK/PHASE and Position Auto config. Manual config. XGA Mode Reset This button is for the automatic adjustment of the screen position, clock and phase. Auto-config. This function is suitable for analogue signal input only. (RGB PC input only) If the picture isn't clear after auto adjustment and especially that characters are still...
  • Page 32 Selecting and Adjusting the Screen Adjusting Screen CLOCK/PHASE and Position To select the image size of the screen. Spectacle When your AV receives the wide screen signal, it will lead you to adjust the picture horizontally, in a nonlinear proportion, to fill the entire screen.

  • Page 33: Troubleshooting

    Troubleshooting No image is displayed G Is the product power cord connected? • See if the power cord is properly connected to the outlet. G Is the power indicator light on? • See if the power switch is turned on. G Power is on, power indicator is green •...

  • Page 34: The Screen Image Looks Abnormal

    Troubleshooting The screen image looks abnormal. G Is the screen position wrong? • D-Sub analog signal – Press the “AUTO” button in the remote control to automatically select the optimal screen status that fits into the current mode. If adjustment is not satisfactory, use the Position OSD menu.

  • Page 35: The Audio Function Does Not Work

    Troubleshooting The audio function does not work. G No sound? • See if the audio cable is connected properly. • Adjust the volume. • See if the sound is set properly. • Select the appropriate equalize sound. G Sound is too dull. •...

  • Page 36: Specifications

    Specifications The product specifications can change without prior notice for product improvement. LCD Panel 42 inches (106.73 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Anti-Glare coating Visible diagonal size: 106.73 cm 0.681 mm (Pixel Pitch) Rated Voltage AC 100-240V~ 50/60Hz 2.5A Power Power Consumption On Mode...
  • Page 37 Specifications The product specifications can change without prior notice for product improvement. Video Signal Max. Resolution RGB : 1600 X 1200 @60Hz HDMI/DVI : 1280 X 1024 @60Hz – It may not be supported depending on the OS or video card type. Recommended Resolution RGB : WSXGA 1360 X 768 @60Hz HDMI/DVI : WSXGA 1360 X 768 @60Hz –...

  • Page 38: Dtv Mode

    Specifications PC Mode – Preset Mode Vertical Vertical Horizontal Horizontal Frequency Frequency Frequency Preset mode Frequency Preset mode (Hz) (Hz) (kHz) (kHz) 31.469 640 x 350 VESA 1024 x 768 60.123 31.468 720 x 400 VESA 1024 x 768 68.68 31.469 640 x 480 VESA...
  • Page 39 Specifications VESA wall mounting Connected to another object (stand type and wall-mounted type.) This product accepts a VESA- compliant mounting interface pad.- (This has to be purchased separately if required.) For further information, refer to the VESA Wall Mounting Instruction Guide. Kensington Security Slot- (This has to be purchased separately if required.) Connected to a locking cable that can be purchased...

  • Page 40: Regulatory Information

    Regulatory information Regulatory information...

  • Page 41: Fcc Compliance Statement

    Regulatory Information cont. respecte toutes les exigences du Règlement sur le FCC Compliance Statement matériel brouilleur du Canada. This equipment has been tested and found to comply NOTICE within the limits of a Class B digital device pursuant to Part The regulations are applied only to the products with the 15 of the FCC Rules.
  • Page 42 Regulatory Information cont. computer and/or display, after a certain period of inactivity, Why do we have environmentally labelled computers? In many countries, environmental labelling has become an shall reduce its power consumption to a lower level, in one established method for encouraging the adaptation of or more stages.
  • Page 43 Regulatory Information cont. relevant bio-accumulative TCO’95 requirement permits Monitor Disposal the inclusion of lead, as no replacement has yet been WARNING developed. If you need to dispose of a monitor, ask a qualified service representative for the proper procedure. Improper disposal could Cadmium is present in rechargeable batteries and in the result in personal injury from implosion.
  • Page 44 Regulatory Information cont. Approval requirements cover a wide range of issues: ecology, ergonomics, emission of electrical and TCO’99 requires that plastic components weighing more magnetical fields, energy consumption and electrical than 25 grams shall not contain flame retardants with safety. organically bound bromine or chlorine.
  • Page 45 The product must be prepared for recycling and the If you want to find out more information about our recycling manufacturer must have a certified environmental program, please contact your local LG vendor or a management system such as EMAS or ISO 14 001 corporate representative of LG.
  • Page 46 La LGE. ha annunciato nel 1994 la cosiddetta 'LG http://www.lge.com/experience/social_commitment/enviro Declaration for a Cleaner Environment' (Dichiarazione di ment.jsp LG a favore di un ambiente più pulito), un ideale che da allora funge da principio ispiratore della gestione aziendale. La dichiarazione rappresenta il fondamento che Français consente di intraprendere attività...
  • Page 47 LGE. presentó la 'Declaración para un entorno más limpio Declaração é a base que nos tem permitido realizar de LG' en 1994 y este ideal ha servido para guiar nuestros atividades favoráveis ao ambiente com consideração principios empresariales desde entonces. La Declaración atenta aos aspectos econômicos, ambientais e sociais.
  • Page 48 ¬ 1994 „Ó‰Û ÍÓÔÓ‡ˆËˇ LGE ÓÔÛ·ÎËÍÓ‚‡Î‡ het milieu 'ƒÂÍ·‡ˆË˛ LG ÔÓ Óı‡Ì ÓÍÛʇ˛˘ÂÈ Ò‰˚', LGE. publiceerde in 1994 de 'LG Declaration for a Cleaner ÍÓÚÓ‡ˇ Ò ÚÂı ÔÓ ÒÎÛÊËÚ ÓÒÌÓ‚Ì˚Ï ÔË̈ËÔÓÏ Environment' (de LG-verklaring met betrekking tot een ÛÔ‡‚ÎÂÌˡ. Õ‡ ÓÒÌÓ‚Â ˝ÚÓÈ ‰ÂÍ·‡ˆËË Ï˚ ÒÏÓ„ÎË...
  • Page 49 LG 공급업체나 LG 기업 대표부에 문의하시기 바랍니다. ‰ÂÈÒÚ‚Û˛Ú ÒËÒÚÂÏ˚ ÛÚËÎËÁ‡ˆËË ÓÚıÓ‰Ó‚ Ë ‚ÓÁ‚‡Ú‡ ËÒÔÓθÁÓ‚‡ÌÌÓÈ ÔÓ‰Û͈ËË. ÃÌÓ„Ë ÍÓÏÔÓÌÂÌÚ˚ LG 전자는 기업 개선 정책의 하나로 지구 환경 문제를 ·Û‰ÛÚ ‚ÚÓ˘ÌÓ ËÒÔÓθÁÓ‚‡Ì˚ Ë ÛÚËÎËÁËÓ‚‡Ì˚, ‚ ÚÓ 채택함으로써 보다 나은 환경을 만들어 나가기 위한...
