User's Guide
M4210N
M
ake sure to read the Important Precautions before using the product.
Keep the User's Guide(CD) in an accessible place for furture reference.
S
ee the label attached on the product and give the information to your dealer when you ask
for service.
Important
WARRANTY VOID
Warranty void if removed.
IF REMOVED
3850TAZ209Y

Advertisement

Table of Contents
loading

Related Manuals for LG M4210N-B10

Summary of Contents for LG M4210N-B10

  • Page 1 User’s Guide M4210N ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the product and give the information to your dealer when you ask for service.

  • Page 2: Safety Precautions

    Safety Precautions WARNING -This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Please read these safety precautions carefully before using the product. If you ignore the warning message, you may be seriously injured or there is a possibility of Warning accident or death.

  • Page 3: Precautions In Moving The Product

    Safety Precautions Electrical Power Related Precautions Warning Make sure to connect the power cable to the grounded current. - You may be electrocuted or injured. Use the rated voltage only. - The product can be damaged, or you may be electrocuted. In the presence of thunder and lightning, never touch the power cord and signal cable because it can be very dangerous.

  • Page 4: Precautions In Using The Product

    Safety Precautions Caution Do not shock the product when moving it. - You may be electrocuted or the product can be damaged. Do not dispose the product-packing box. Use it when you move. Make the panel face forward and hold it with both hands to move. - If you drop the product, the damaged product can cause electric shock or fire.

  • Page 5: Using The Remote Control

    • ARC button To select the image size of the screen. • Video Operation Button Applicable for LG products only • Power On/Off Button SLEEP • CTR.PWR Button Turn on the power of the PC built in the monitor and then turn off.

  • Page 6: Inserting Batteries Into Remote Control

    Using the Remote Control Inserting batteries into remote control. 1. Take out the battery cap. 2. Insert the batteries with correct polarity (+/-). 3. Close the battery cap. • Dispose of used batteries in the recycle bin to prevent environmental pollution. SLEEP •...
  • Page 7 Using the Remote Control Name of the Remote Control Buttons (B type) There is not a function which is supported There is not a function which is supported • CTR.PWR Button Turn on the power of the PC built in the monitor and then turn off.
  • Page 8 Using the Remote Control CTR. Inserting batteries into remote control. • Input Select Button If you press the button once, the following Input Signal Window will appear. Select the signal type you want using the 1. Take out the battery cap. 2.

  • Page 9: Connecting The Speakers

    Connecting the Speakers * Applicable only for models that support the speakers Mount the product onto the speaker by using a screw as following picture, and then connect the speaker cable.

  • Page 10: Name And Function Of The Parts

    Name and Function of the Parts * The product image in the user’s guide could be different from the actual image. Rear View RS-232C DVI IN REMOTE (CONTROL& CONTROL IN SERVICE) Power Connector : Connect the power cord Wired Remote Control Port RS-232C Serial Ports RGB, DVI Ports PC Sound Jack...

  • Page 11: Connecting To External Devices

    Connecting to External Devices When Connecting to your Built in PC This product contains DVI-Signal settings. Rear side of the product. Connect the power cord. When using with the D-Sub signal. First of all, see if the computer, product and the peripherals are turned off. Then, connect the signal input cable.

  • Page 12: When Connecting To Your Pc

    Connecting to External Devices When Connecting to your PC First of all, see if the computer, product and the peripherals are turned off. Then, connect the signal input cable. When connecting with the D-Sub signal input cable. When connecting with the DVI signal input cable. Rear side of the product.
  • Page 13 Connecting to External Devices Turn on power by pressing the power button on the product. Turn on the PC. Select an input signal. Press the INPUT button on the remote control to select the input signal. INPUT Or, press the SOURCE button at the back side of the product. SOURCE When connecting with a D-Sub signal input cable.

  • Page 14: Watching Rgb Outputs

    Connecting to External Devices Watching RGB Outputs Use this function when displaying ANALOG RGB inputs of a PC to the other product. To use different products connected to each other • Connect one end of the signal input cable(15-pin D-Sub Signal Cable) to the RGB OUT connector of product 1 and connect the other end to the RGB IN connector of other products.

  • Page 15: To Arrange Cables Using Cable Management

    To arrange cables using cable management * Applicable only for models that support the stand. Arrange the cables in the center as shown in the following picture. Fit the cable management to the Holder Groove downwards. Bundle the cables using the supplied twister holder. * When you want remove it.

  • Page 16: Attaching The Product To A Wall

    Attaching the product to a wall * Applicable only for models that support the stand. • Set it up close to the wall so the product doesn't fall over when it is pushed backwards. The instructions shown below is a safer way to set up the product, which is to fix it on the wall so the product doesn't fall over when it is pulled in the forward direction.

  • Page 17: Selecting And Adjusting The Screen

    Selecting and Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit SOURCE • Press this button to turn on the power. Press this button again to Power Button turn it off. • This Indicator lights up blue when the display operates normally(on Power Indicator mode).
  • Page 18 Selecting and Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit AUTO/SET Button If the resolution is 1360X768 (RGB Mode) If the resolution is not 1360X768 (RGB Mode) • Select the input signal SOURCE Button DVI (Digital signal) Digital signal and Analogue signal can't be outputted at the same time so when transferring the source connect the connector and then turn on the power.

  • Page 19: Function Description

    Selecting and Adjusting the Screen OSD Menu Icon Adjusts screen brightness, contrast and color that you prefer. PICTURE Adjusts the audio function. SOUND Adjusts the screen status according to the circumstances. SPECIAL Adjusts the screen video. SCREEN Note OSD(On Screen Display) The OSD function enables you to adjust the screen status conveniently since it provides graphical presentation.

  • Page 20: How To Adjust The Osd (On Screen Display) Screen

    Selecting and Adjusting the Screen How to adjust the OSD (On Screen Display) screen (A type) Pops up Move where Select a the menu you want to menu icon screen adjust (B type) To access a control, use the When the icon you want becomes highlighted, press the SET Button. Use the Buttons to adjust the item to the desired level.

  • Page 21: Adjusting Screen Color

    Selecting and Adjusting the Screen Adjusting Screen Color • 6500K/9300K Selecting a factory setting color set. 6500K: Slightly reddish white. 9300K: Slightly bluish white. • User : Select this option to use the user-defined settings. Contrast To adjust the contrast of the screen. Brightness To adjust the brightness of the screen.

  • Page 22: Adjusting The Audio Function

    Selecting and Adjusting the Screen Adjusting the audio function SOUND Balance • Flat : The most commanding and natural audio. • Music : Select this option to enjoy the original sound when listening to the music. • Movie : Select this option to enjoy sublime sound. •...

  • Page 23: Selecting The Options

    Selecting and Adjusting the Screen Selecting the options Input Reset Child lock Use the buttons to select On or Off. The Set can be set up so that it can only be used with the remote control. This feature can prevent unauthorized viewing. In order to lock the OSD screen adjustment, set the Child lock tab to the 'On' position.
  • Page 24 Selecting and Adjusting the Screen Selecting the options To use this function • - You can connect the product with several other products and use the Tile mode function. Tile mode Reset • Tile mode Tile mode and choose Tile alignment and set the ID of the current product to set location. Adjust the horizontal size of the screen taking into account the size of the bezel.
  • Page 25 Selecting and Adjusting the Screen Selecting the options • Tile mode - Tile mode : row x column ( r = 1, 2, 3, 4 c = 1, 2, 3, 4) - 4 x 4 available. - Configuration of an integration screen is also available as well as configuration of one by one Display. - Tile mode (product 1 ~ 4) : r(2) x c(2) ID 1 ID 3...
  • Page 26 Selecting and Adjusting the Screen Selecting the options - Tile mode (product 1 ~ 2) : r(2) x c(1) ID 1 Reset Use this function to reset the product to the factory default. However, language selection and PC Control selection will not be initialized. Set ID Set ID Logo light...

  • Page 27: Adjusting Screen Clock/Phase And Position

    Selecting and Adjusting the Screen Adjusting Screen CLOCK/PHASE and Position To select the image size of the screen. (1:1 menu are not supported over 1360 X 768 resolution) Auto-configure Auto-configure This button is for the automatic adjustment of the screen position, clock and phase. This function is suitable for analoge singnal input only.

  • Page 28: Troubleshooting

    Troubleshooting No image is displayed G Is the product power cord connected? G Is the power indicator light on? G Power is on, power indicator is green but the screen appears extremely dark. G Is the power indicator amber? G Does the 'Out of range' message appear? G Does the 'Power saving mode DVI' message appear?

  • Page 29: The Screen Image Looks Abnormal

    Troubleshooting The screen image looks abnormal. G Is the screen position wrong at the RGB mode? G Do thin lines appear on the background screen at the RGB mode? G Horizontal noise appears or the characters look blurred at the RGB mode.

  • Page 30: After-Image Appears On The Product

    Troubleshooting 'Child lock on' message appears. G The 'Child lock on' message appears when pressing the Menu button. After-image appears on the product. G After-image appears when the product is turned off. Screen color is abnormal. G Screen has poor color resolution (16 colors).

  • Page 31: Specifications

    The product specifications can change without prior notice for product improvement. LCD Panel 42 inches (106.73 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Anti-Glare coating Visible diagonal size: 106.73 cm 0.681 mm (Pixel Pitch) Rated Voltage Power Power Consumption On Mode Dimensions &Weight...
  • Page 32 The product specifications can change without prior notice for product improvement. Video Signal Max. Resolution Recommended Resolution RGB : WSXGA 1360 X 768 @60Hz Horizontal Frequency Vertical Frequency Synchronization Type Separate/Composite/Digital Input Connector Environmental Operational Condition Temperature: 5˚C ~ 35˚C , Humidity: 10% ~ 80% Conditions Storage Condition * Applicable only for models that support the speakers...

  • Page 33: Pc Mode - Preset Mode

    Specifications PC Mode – Preset Mode Horizontal Frequency Preset mode (kHz) 31.469 640 x 350 31.468 720 x 400 31.469 640 x 480 VESA 37.500 640 x 480 37.879 VESA 800 x 600 46.875 VESA 800 x 600 49.725 832 x 624 VESA 48.363 1024 x 768...
  • Page 34 VESA wall mounting Connected to another object (stand type and wall-mounted type.) This product accepts a VESA- compliant mounting interface pad.- (This has to be purchased separately if required.) For further information, refer to the VESA Wall Mounting Instruction Guide. Kensington Security Slot- (This has to be purchased separately if required.) Connected to a locking cable that can be purchased...

  • Page 35: Signal Connector Pin Assignment

    Specifications Signal Connector Pin Assignment DVI-D Connector Signal(DVI-D) T. M. D. S. Data2- T. M. D. S. Data2+ T. M. D. S. Data2/4 Shield T. M. D. S. Data4- T. M. D. S. Data4+ DDC Clock DDC Data Analog Vertical Sync. T.

  • Page 36: Connecting The Usb Cable

    Connecting the USB(Universal Serial Bus) Cable "USB (Universal Serial Bus)" is an innovation in connecting your different desktop peripherals conveniently to your computer. By using the USB, you will be able to connect your mouse, keyboard, and other peripherals to your display instead of having to connect them to your computer.

  • Page 37: Controlling The Multiple Product

    Controlling the Multiple Product RS-232C Use this method to connect several products to a single PC. You can control several products at a time by connecting them to a single PC. Connecting the cable Connect the RS-232C cable as shown in the picture. * The RS-232C protocol is used for communication between the PC and product.

  • Page 38: Command Reference List

    Controlling the Multiple Product RS-232C Command Reference List 01. Power 02. Input Select 03. Aspect Ratio 04. Screen Mute 05. Volume Mute 06. Volume Control 07. Contrast 08. Brightness 09. OSD Select 10. Remote On/Off 11. Balance 12. Select Color Temp 13.
  • Page 39 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command 1]: First command. (k) * [Command 2]: Second command. (a ~ u) * [Set ID]: You can adjust the set ID to choose desired product ID number in Special menu.
  • Page 40 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 01. Power On(Command : a) To control Power On/Off of the Set. Transmission [k][a][ ][Set ID][ ][Data][Cr] Data 0 : Power Off 1 : Power On Acknowledgement [a][ ][Set ID][ ][OK][Data][x] To show the status of Power On/Off.
  • Page 41 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 03. Aspect Ratio(Command : c) (Main picure format) To adjust the screen format. You can also adjust the screen format using the ARC (Aspect Ratio Control) button on remote control or in the Screen menu.
  • Page 42 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 05. Volume Mute(Command : e) To control On/Off of the Volume Mute. Transmission [k][e][ ][Set ID][ ][Data][Cr] Data 0 : Volume Mute On (Volume Off) 1 : Volume Mute Off (Volume On) Acknowledgement [e][ ][Set ID][ ][OK][Data][x] Data 0 : Volume Mute On (Volume Off)
  • Page 43 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 07. Contrast(Command : g) To adjust screen contrast. You can also adjust the contrast in the Picture menu. Transmission [k][g][ ][Set ID][ ][Data][Cr] Data Min : 00H ~ Max : 64H Refer to ‘Real data mapping’...
  • Page 44 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 09. OSD Select(Command : l) To control OSD on/off to the set. Transmission [k][l][ ][Set ID][ ][Data][Cr] Data 0 : OSD Off 1 : OSD On Acknowledgement [l][ ][Set ID][ ][OK][Data][x] Data 0 : OSD Off 1 : OSD On 10.
  • Page 45 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 12. Select Color Temp (Command : u) To adjust the screen color temperature. Transmission [k][u][ ][Set ID][ ][Data][Cr] Data 0 : User 1 : 9300K 2 : 6500K Acknowledgement [u][ ][Set ID][ ][OK][Data][x] Data 0 : User 1 : 9300K 2 : 6500K...
  • Page 46 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 14. Red Gain Adjust (Command: j w) To adjust Red color level. Transmission [j][w][ ][Set ID][ ][Data][Cr] Data Min : 00H ~ Max : 64H Acknowledgement [w][ ][Set ID][ ][OK][Data][x] * When it is executed with the 6500K or 9300K selected, it is automatically changed to the USER. 15.
  • Page 47 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 17. Tiling Mode (Command :d d) Change a Tiling Mode. Transmission [d][d][][Set ID][][Data][x] Data Description Tiling mode is off. 1 x 2 mode(column x row) 1 x 3 mode 1 x 4 mode 4 x 4 mode * The data can not be set to 0X or X0 except 00.
  • Page 48 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 19. Tile V Position(Command : d f) To set the Vertical position. Transmission [d][f][][Set ID][][Data][x] * The data range is from 00 to 64(in Hex). Acknowledgement [f][][Set ID][][OK/NG][Data][x] 20. Tile H Size(Command : d g) To set the Horizontal size.
  • Page 49 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 22. Tile ID Set (Command : d i) To assign the Tile ID for Tiling function. Transmission [d][i][][Set ID][][Data][x] * The data range is from 00 to 10 tile mode. (in Hex). Acknowledgement [i][][Set ID][][OK/NG][Data][x] 23.
  • Page 50 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 24. PC Power On/Off (Command : d s) To turn On and Off the built in PC. Transmission [d][s][][Set ID][][Data][x] Data 0 : PC Power Off 1 : PC Power On Acknowledgement [s][][Set ID][][OK/NG][Data][x] *This operates only when ‘PC Control’...
  • Page 51 RS-232C Connect your wired remote control to Remote Control port on the Product. Output waveform single pulse, modulated with 37.917KHz signal at 455KHz Configuration of frame • 1st frame Lead code custom code C0 C1 C2 C3 C4 C5 C6 C7 C0 C1 C2 C3 C4 C5 C6 C7 D0 D1 D2 D3 D4 D5 D6 D7 D0 D1 D2 D3 D4 D5 D6 D7 •...
  • Page 52 RS-232C Code(Hexa) Function VOL( ) VOL( ) POWER ON/OFF POWER ON POWER OFF MUTE INPUT MENU EXIT Number Key 0 Number Key 1 Number Key 2 Number Key 3 Number Key 4 Number Key 5 Number Key 6 Number Key 7 Number Key 8 Number Key 9 ARC (1:1)
