  • Page 1 DATA R9002120 OWNER'S MANUAL...
  • Page 3 BARCO PROJECTION SYSTEMS DATA R9002120 OWNER'S MANUAL Date : Art. No. : 260597 R5975977...
  • Page 4 Due to constant research, the information in this manual is subject to change without notice. Produced by BARCO NV, May 1997. All rights reserved. Trademarks are the rights of their respective owners. BARCO nv/Projection Systems Noordlaan 5 B-8520 Kuurne Belgium...

  • Page 5: Table Of Contents

    Connecting a computer, e.g. IBM PC (or compatible), Apple Macintosh to the RS232 input of the projector..3-6 Connecting a RCVDS 05 switcher to the projector..3-6 Connecting a VS05 switcher to the projector..3-6 Connecting an IR Remote Receiver to the projector ... 3-6 Peripheral equipment ...
  • Page 6 Projector Set-up ... 7-2 Identification ... 7-2 Total Run Time ... 7-3 Change password ... 7-3 Change Language ... 7-3 Change Projector Address ... 7-4 Change baudrate ... 7-4 Power up mode ... 7-4 BARCO_logo ... 7-5 Memory management ... 7-5 Copy a block ...
  • Page 7 MESSAGES, WARNINGS AND FAILURES ... 8-1 OPTIONS ... 9-1 IR Receiver 800 ... 9-1 Hardwired RCU..9-1 Projector Control software ... 9-1 RCVDS 05 Source Selector ... 9-1 VS05 Switcher ... 9-1 IRIS/2 Auto-Convergence System ... 9-1 MAGIK Interface ... 9-2 Adapter and communication cables ...

  • Page 8: Table Of Contents

    Table of Contents 5975977 BARCODATA 708 260597...

  • Page 9: Safety Instructions

    OWNER’S RECORD The part number and serial number are located at the back side of the projector. Record these numbers in the spaces provided below. Refer to them whenever you call upon your BARCO dealer regarding this product. PART NUMBER : SER.

  • Page 10: On Installation

    Replacement parts - When replacement parts are required, be sure the service technician has used original BARCO replacement parts or authorized replacement parts which have the same characteristics as the BARCO original part. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.

  • Page 11: Location And Function Of Controls

    VIDEO IN (Composite video, 1x BNC connector) : allows a video tape recorder, video camera, color receiver/monitor, etc. having video line output to be connected to the projector. S-VIDEO IN : Separated Y/C (luma-chroma) signal inputs and outputs for higher quality playback of Super VHS signals (4-pin S-VIDEO connector).

  • Page 12: Control Panel Terminology

    RCU control panel terminology This remote control includes a battery powered infrared (IR) transmitter that allows the user to control the projector remotely. This remote control is used for source selection, control, adaptation and set-up. It includes automatic storing of : - picture controls (Brightness, Sharpness,...)
  • Page 13 ADJ. : adjust key, to enter or exit the adjustment mode. Address key (recessed key), to enter the address of the projector (between 0 and 9). followed by pressing one digit button between 0 and 9. STBY : stand by button : - to initiate remote power up operation - to stop projection without main power off.
  • Page 14 Location and Function of Controls 5975977 BARCODATA 708 260597...

  • Page 15: Connections

    CONNECTIONS Power (mains) cord connection Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the front of the projector. Switching on/off The projector is switched ON and OFF using the power (mains) switch ON/OFF.

  • Page 16: Connecting A Composite Video Source

    Connections Source No Projector input Comp. Video S-Video*/Comp. Video RGBS or RGsB** RGB3S or RG3sB*** (R-Y)Y(B-Y)S or (R-Y)Ys(B-Y)**** (R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y)***** Connecting a Composite Video source. Composite video signals from a VCR, OFF air signal decoder, etc.. If a line doubler is built in :...

  • Page 17: Connecting A S-Video Or Video Source To Port 2

    Connecting a S-Video or Video source to port 2. Separate Y-luma/C-chroma signals for higher quality playback of Super VHS signals. If a line doubler is built in : the default position of this line doubler is ON (active), the video input signal will be displayed as a non interlaced image (= improved image stability).

  • Page 18: Connecting A Rgb Analog Source With Composite Sync

    The projector detects automatically where the sync signal is located. Always use an interface when a computer and local monitor have to be connected to the projector. Examples of interfaces which can be applied : Universal analog interface...

  • Page 19: Connecting A Component Source

    - Press ENTER to select the highlighted source. Connecting a Component source. (R-Y)Y(B-Y) analog input terminals with sync input or with sync on the luminance (Y) input. The projector detects automatically where the sync signal is located. Line doubling is possible for component video input sources on standard line frequency.

  • Page 20: Connecting A Computer, E.g. Ibm Pc (Or Compatible), Apple Macintosh To The Rs232 Input Of The Projector

    - Use the control disk to highlight 6. - Press ENTER to select the highlighted source. Connecting a computer, e.g. IBM PC (or compatible), Apple Macintosh to the RS232 input of the projector. The projector has a RS232 port that allows it to communicate with a computer.

  • Page 21: Controlling

    CONTROLLING Caution : Do not display a stationary image with full brightness and contrast for longer than 20 min., otherwise you risk damage to the CRT's. Battery installation in the RCU. A new battery is delivered inside the plastic bag with the power cord. Before using the RCU, install first the battery.

  • Page 22: How To Use The Rcu

    - Computer, e.g. IBM PC (or compatible), Apple MAC, etc. for addresses between 0 and 255. Note : A projector will respond to an RCU set to an address of '0' regardless of what address is set in the projector itself.

  • Page 23: How To Program An Address Into The Rcu

    (address between 0 and 9). For example : if the Address key displays projector address 003, the press "3" digit button on the RCU to set the RCU's address to match the projector's address. Do not press digit 003. This will address the remote to '0' and control all projectors in the room.

  • Page 24: Picture Controls

    - button (softer picture). The Pause key. When the Pause key is pressed, the image projection is stopped but the projector remains with full power for immediate restart. To restart the image : - Press the Pause key, - Select a source number.

  • Page 25: Start Up Of The Adjustment Mode

    Push the control disk up or down to select the analog control to be adjusted and press the ENTER key to confirm. When the analog control is adjusted the projector returns automatically to the General access menu. When you want to return to the Adjustment mode, press EXIT , otherwise select quit ADJUST and press ENTER to return to operational mode.
  • Page 26 (Password protection is only available when the password DIP switch on the controller module is in the ON position. Contact a BARCO authorized technician when no password is requested during the adjustment procedure and password protection is desired.) Your password contains 4 digits.

  • Page 27: Starting Up The Random Access Adjustment Mode

    RANDOM ACCESS ADJUSTMENT MODE Starting up the random access adjustment mode. Push the control disk up or down to highlight "RANDOM AC- CESS" and then press ENTER . Some items in the Random access mode are password protected (when the password function is enabled). Enter your password to continue.

  • Page 28: Selecting Setup Pattern

    Random Access Adjustment Mode Selecting Setup Pattern If an external source is connected to the projector, this menu will be displayed. Push the control disk up or down to highlight the desired setup pattern and then press ENTER . Genlocked pattern : internally generated cross hatch pattern, locked on the external source.

  • Page 29: Random Access Adjustment Mode Selection Menu

    Color Balance The Color Balance function is used to select or adjust the color temperature of white used by the projector. The Color Balance can be adjusted on two different ways : - fixed color balance. You have the choice between 3200 K (reddish), 4900 K, 6500 K (white) or 9300 K (bluish).

  • Page 30: Line Doubler (Option)

    Random Access Adjustment Mode Line Doubler (option) Line doubling is only possible for Video, S-Video, Component Video images on standard line frequency and RGB signals on 15 kHz. To eliminate the video line patterns and to improve the image stability, the line doubler has to be switched on. The line doubler is default set in the ON position when starting up for the first time.

  • Page 31: Geometry Adjustments

    Geometry Adjustments The geometry adjustments have to be done only on the green image. These adjustments are automatically implemented for the other color images : Left-right (EW) and Top-Bottom Corrections, Blanking, Horizontal Amplitude, Vertical Amplitude, Vertical Linearity and Horizontal Phase. Highlight GEOMETRY by pushing the control disk up or down and press ENTER to display the geometry menu.

  • Page 32: Raster Shift Adjustment

    Press EXIT to return to the Geometry menu. Note : Horizontal and Vertical shifts for Red and Blue should end up with a setting close to 50%. If these settings are significantly greater or lesser than 50%, contact a BARCO authorized service technician. GEOMETRY...

  • Page 33: Left-Right (East-West) Adjustments

    Left-Right (east-west) Adjustments Left-right and center adjustments affect only the vertical lines of the projected image. To start up the left-right and center adjustments, follow the next procedure : Push the control disk up or down to highlight LEFT-RIGHT (E/W) on the geometry menu and then press ENTER .

  • Page 34: Top-Bottom (North-South) Adjustments

    Random Access Adjustment Mode Top-Bottom (north-south) Adjustments Top-Bottom and center adjustments affect only the horizontal lines of the projected image. To start up the Top-Bottom and center corrections, follow the next procedure : Push the control disk up or down to highlight TOP-BOTTOM (N/S) on the geometry menu and then press ENTER .

  • Page 35: Size Adjustment

    Size Adjustment Push the control disk up or down to highlight SIZE on the Geometry menu and then press ENTER . ENTER will select size adjustment. EXIT returns to random access adjustment mode menu. ADJUST returns to operational mode. Adjust the horizontal size by pushing the control disk to the right or to the left until the exact image width is obtained.

  • Page 36: Blanking Adjustments

    Random Access Adjustment Mode Blanking Adjustments Blanking adjustments affect only the edges of the projected image and are used to frame the projected image on to the screen and to hide or black out unwanted information (or noise). A 0% on the bar scale indicates no blanking.

  • Page 37: Convergence Adjustment

    Convergence Adjustment Convergence adjustments affect both the horizontal and vertical lines of the setup pattern. These adjustments are performed on the red image while superimposed on the green image and then on the blue image while superimposed on the green image. Note : the green convergence adjustments can be added as an option.
  • Page 38 Random Access Adjustment Mode 6-12 5975977 BARCODATA 708 260597...

  • Page 39: Service Mode

    IDENTIFICATION TOTAL RUN TIME CHANGE PASSWORD CHANGE LANGUAGE CHANGE PROJECTOR ADDRESS CHANGE BAUDRATE POWER UP MODE BARCO LOGO COPY A BLOCK DELETE A BLOCK DELETE ALL BLOCKS ALL SETTINGS TO MIDPOS R & B CONVERGENCE MID GR CONVERGENCE MID G2 ADJUSTMENT...

  • Page 40: Projector Set-Up

    * Rear-table - Baud rate PC : transfer speed for communication with an IBM PC (or compatible) or MAC. The baud rate of the projector must be the same as the baud rate of the connected computer. When there is a difference, contact a qualified service technician to make the appropriate changes.

  • Page 41: Total Run Time

    Total Run Time Highlight 'Total Run Time' with the control disk and press ENTER to display the amount of time the projector has played since its first start up at the factory. ENTER gives the selected item. EXIT returns to the Service mode menu.

  • Page 42: Change Projector Address

    'operating mode' or in 'stand-by mode'. Operating mode : the projector start up and displays image . Stand-by mode : the projector start up in stand-by and waits until the stand-by button or a digit key is pressed. To change the Power up mode, select Power Up mode by pushing the control disk up or down and press ENTER to toggle between 'Operating' and 'Standby'.

  • Page 43: Barco_Logo

    The BARCO logo can be added to the image, in overlay or in background, on any place on the screen. To add the BARCO logo or to change a setting in the BARCO logo menu, highlight 'BARCO logo' by pushing the control disk up or down and press ENTER to select.

  • Page 44: Copy A Block

    Service Mode Copy a block The copy a block function copies the settings of a selected block into the active block. Highlight copy a block with the control disk and press ENTER . ENTER will select the highlighted item. EXIT returns to the Path Selection main menu. ADJUST returns to the Operational mode.

  • Page 45: Deletion Of All Blocks

    'All settings to midposition' when this latter is pressed. An undo is possible as long as the projector is playing on the same source (= same adjustment block) even when some adjustments as geometry or convergence are already readjusted. When undo is presssed all settings are reset to the previous settings.

  • Page 46: R & B Convergence Mid

    'R & B convergence mid' when this latter is pressed. An undo is possible as long as the projector is playing on the same source (= same adjustment block) even when some adjustments are already readjusted. When undo is presssed all settings are reset to the previous settings.

  • Page 47: Common Settings

    ENTER selects the G2 adjustment. EXIT returns to the Common settings menu. ADJUST returns to the Operational mode. 'G2 adjustment should be performed by BARCO personnel, or BARCO authorized dealers'. If you are qualified, press ENTER to continue. If not qualified, press EXIT to return to the Common settings menu.

  • Page 48: Projector Warm Up

    If a memory block adjusted on an internal # pattern is available, the CRT run in cycle will start when pressing ENTER. If no such a block is available, the projector cannot run the CRT run in option and leaves the adjustment mode.

  • Page 49: I2C Diagnostics

    ENTER . The I2C diagnostics menu gives an overview of the I2C failures inside the projector. To scroll through the failure list, push the control disk up or down. The I2C address, IC number and module name will be given in I2C diagnostic menu.
  • Page 50 Service Mode 7-12 5975977 BARCODATA 708 280597...

  • Page 51: Messages, Warnings And Failures

    PROJECTOR when activating the 'ADDRESS' ADDRESS : button on the RCU with a pencil or other small object. When using the projector with the WARNING : RCVDS, this warning will be dis- played when selecting an input slot input not...
  • Page 52 RCVDS and the projec- munication tor. error FAILURE Communication error between IRIS IRIS commu- 800 and the projector. Call a quali- nication fied service technician. error WAIT Message during the start up of the starting IRIS. Message will disappear when...

  • Page 53: Options

    BARCO's digitally controlled large screen projectors. It offers the possibility to connect and switch up to 5 different Video sources, 3 different S-Video sources and 1 RGB Analog source to a BARCO projector. In addition, the audio signal proper to the source, can be switched to an audio amplifier.

  • Page 54: Magik Interface

    Order number : R9827780 Line Doubler Kit BARCO's line doubler kit consists of a video decoder with a three-line adaptive Comb filter, an enhancement circuit and the line doubler itself. - The three-line adaptive Comb filter improves color transitions and reduces noise in the video signal.
  • Page 55 If other sources have already been connected to the projector and geometry and convergence adjustments have been performed on these sources, the projector will use Linear Digital Interpolation to create a new block for the new source. This block will provide an initial set of adjustments for the new source that have been calculated by the projector from “previous experience”.

  • Page 56: Appendix A : Adjustment Blocks And Source Numbers 90 - 99

    Adjustment Blocks and Source Numbers 90-99 5975977 BARCODATA 708 260597...
  • Page 57 INSERT CARD 5975977 BARCODATA 708 260597 INPUT SOURCES INPUT SOURCES PROJECTOR PROJECTOR INPUT SOURCES INPUT SOURCES RCVDS RCVDS Insert Card...
