Before Using the DVD Player

Your DVD player is capable of playing DVD, VCD, and CD discs.
User instructions may vary depending on the type of disc. Read the instructions
carefully before use.
1
Turn on the power
Select a video mode by
to your DVD player
pressing the TV/VIDEO
Prepa-
and TV.
button.
rations
before
TV
use
The "WAIT" message that appears on the display for about 4~5 seconds when turning on
the power or selecting a DVD function indicates a stabilization period for optimizing the
condition of your DVD player. While the message is being displayed, other buttons
remain inactive.
When the power is not turned on, press down the Stop (
over 5 seconds.
The product will be initialized to its optimum state.
Some operational features such as the Speaker mode, Test tone, Volume, etc. will not
be displayed on the TV screen.
TV Broadcast System
• This device is designed to work with the NTSC video format.
• For normal playback, the video format a DVD disc is recorded in must
coincide with your TV's video format.
15
2
3
Press the DVD button
to select the DVD input

function.

TV/VIDEO
DVD
) button on the main unit for
P.SCAN
(Progressive Scan)
Unlike a regular Interlace Scan in which two fields of picture information are alternated to
create the entire picture (odd scan lines, then even scan lines), Progressive Scan uses
one field of information (all lines displayed in one pass) to create a clear and detailed
picture without visible scan lines. To enjoy a progressive scan video, connect a TV or
monitor that supports a progressive scan input to this device.
While the player is in the Stop mode, hold the P.SCAN
button down for longer than 1 second.
The selection switches back and forth between "P.SCAN" and "I.SCAN"
each time the button is held down for a minimum of 1 second.
The previous mode is indicated in the display first, followed by the
selected mode in about a second.
P.Scan Adj (Progressive Scan Adjusting)
This function allows you to optimize the picture quality when it becomes poor due to screen distortion or
discs containing erroneous data.
Press the Setup/P . Adj button. (Play mode only)
Each time the Setup/P . Adj button is pressed, the following appears on the TV screen:
What is Progressive (or Non-Interlaced) Scanning?
Interlaced Scan (1 FRAME = 2 FIELDS)
In interlaced-scan video, a frame consists of two
interlaced fields (odd and even), where each field
contains every other horizontal line in the frame.
The odd field of alternating lines is displayed first, and
then the even field is displayed to fill in the alternating
gaps left by the odd field to form a single frame.
One frame, displayed every 1/30th of a second, contains
two interfaced fields, thus a total of 60 fields are
displayed every 1/60th of a second each.
The interlaced scanning method is intended for capturing
a still object.
This function only works with TV's equipped with component video inputs (Y, P
Depending on the brand and model of your TV, this function may not work.
Function
Progressive Scan (FULL FRAME)
The progressive scanning method scans one full frame of
video consecutively down the screen, line by line.
As opposed to the interlaced scanning process by which a
video image is drawn in a series of passes, you get an
entire image drawn at one time.
The progressive scanning method is desirable for dealing
with moving objects. A camera that has the ability to
capture moving objects is called a "full frame shutter
camera".
, P
).
r
b
16
