Summary of Contents for Disney P250DVD
-
Page 2: Table Of Contents
1. Safety information----------------------------------------------------------------------------2 2. Brief instruction of controls-----------------------------------------------------------------3 3. Instructions of Remote controller----------------------------------------------------------5 4. Accessories & Connections & Battery Recharging-------------------------------------6 5. Operations--------------------------------------------------------------------------------------7 6. Normal Settings------------------------------------------------------------------------------13 7. Discs Supported------------------------------------------------------------------------------20 8. Trouble shooting-----------------------------------------------------------------------------21 9. Specifications--------------------------------------------------------------------------------22... -
Page 3: Safety Information
Safety information... -
Page 4: Brief Instruction Of Controls
Brief instruction of function keys TFT DISPLAY 10. SETUP DISC TRAY 11. USB OPEN 12. SD/MS/MMC PREV 13. PHONE PLAY/PAUSE 14. AV OUT NEXT 15. AV IN UP/DOWN/RIHGT/LEFT 16. ON/OFF ENTER 17. DC IN MENU 18. SENSOR... - Page 5 Brief instruction of function keys 1. TFT DISPLAY 10. OPEN 2. DISC TRAY 11. USB 3. ENTER 12. SD/MS/MMC 4. UP/DOWN/RIGHT/LEFT 13. PHONE 5. PLAY/PAUSE 14. AV OUT 6. PREV 15. AV IN 7. NEXT 16. ON/OFF 8. SETUP 17 DC IN 18.
-
Page 6: Instructions Of Remote Controller
Instructions of Remote controller 1.Menu/PBC 2.Title 3.Mode 4.Up/Down/Left/Right Key 5. Enter 6. Mute 7. Number(0-9) 8. Go To 9. A-B 10. Repeat 11. Audio 12.Sub-Title 13. USB/Card 14. Display 15. Play/Pause 16. Setup 17. Stop 18. Next 19. Zoom 20. Prev 21. -
Page 7: Accessories & Connections & Battery Recharging
Accessories & Connections & Battery Recharging 1 Accessories (1). Remote controller (2). A/V Cable (3). Earphone (4). AC Adapter (5). User manual 2 Connections Adapter Earphone Adapter Earphone 3 Battery Recharging (1). The battery will be recharged automatically when the player is connected with the power source by the attached DC adapter. -
Page 8: Operations
Operations 1. Selecting Tracks (compatible with DVD,SVCD,VCD,CD,CD-G,HD-CD,WMA,MP3/JPEG disc) a) When playing a DVD disc, press Numeric buttons on the menu or title page to select tracks; During DVD playback, you can input desired title number directly. b) As a SVCD or VCD disc, during sequence playback, press Numeric buttons to select tracks. (During Program Playback and PBC is on, you can only press Prev/Next button to select) c) As for CD, CD-G, HD-CD disc, press numeric buttons direcly to select tracks. - Page 9 Operations 5. Using the Repeat Feature (compatible with DVD, SVCD, VCD, CD ,CD-G, HD-CD discs) When a disc is playing, press Repeat button once, and repeat banner appears to show current repeat mode. a) In SVCD, VCD, CD, CD-G, HD-CD sequence playback mode, press Repeat button again to turn on repeat mode.
- Page 10 Operations Press the Angle button again to go to the next camera angle. If multiple camera angles are available, the Angle icon displays the current angle number and the number of angles available. For example: “ Angle Icon; [*/*] or [Off]”; 1/4 indicates that angle one is being displayed, and there are four different angles available. (This feature is disc-dependent.
- Page 11 Operations ● Looping will run from set point A to set point B until you turn off Repeat. Press A-B again to cancel A-B loop mode. ● When playing a SVCD, VCD or CD disc, you can repeat a specific segment only in one track. When the next track begins, A-B Repeat turn off automatically.
- Page 12 Operations ● According to the highlight, use the Numeric buttons to enter the chapters/tracks in the order you want them to play. Then press Play or use Arrow buttons to highlight the “PLAY” item and press Enter. The chapters/tracks will play in the programmed order. You can program maximum 16 titles/chapters/tracks.
- Page 13 Operations Ⅶ. When a picture playing or pausing, press the Arrow buttons to change the display angle: Up: flip vertical Down: flip horizontal Left: rotate 90° counter-clockwise Right: rotate 90° clockwise 15. USB & Card Reader Function ● USB: Take out the disc and press down the CD door, then insert USB, the player will read the USB automatically, you could select the song yourself;...
-
Page 14: Normal Settings
Normal Settings In DVD mode, press [SETUP] on the remote control or on the unit to show the setup Menu. Press direction key to select an item, and then press ENTER key to confirm. 1. GENERAL SETUP PAGE There are six items in the GENERAL SETUP PAGE. They are TV Shape, Angle Mark, Osd Lang, Captions, Screen Saver, Last Memory, Logo Type, MP3 Lyric. - Page 15 Normal Settings (3). OSD (On-Screen Display) LANGUAGE Set the on-screen display language in this item. There are 2 languages for your option: English,Romanian. (as default). (4). CAPTIONS Set this item to ON to show the closed captions; set it to OFF to hide it. You Can Also press [SUBTITLE] on the remote control to display or hide the Closed captions.
- Page 16 Normal Settings (7). LOGO TYPE There are 3 Kinds of logos for your option: Default: the opening logo you see when the device open Blue SCR: the background will change into blue if you choose this type Captured: You can set a captured picture (from programs) that you prefter. There are two options: ON and OFF.
- Page 17 Normal Settings (1). LT/RT: The 2.1-channel audio is mixed Into left channel right channel and is Output via the FR and FR speaker Respectively. (2). STEREO: The 2.1-channel audio is mixed into stereo signal and is output via the FR and FR speaker. NOTE: This function only applies to the Dolby AC-3 encoded 2.1-channel discs.
- Page 18 Normal Settings 4. VIDEO SETUP PAGE There are four items in the VIDEO SETUP PAGE they are sharpness. Brightness, Contrast and logo. They are used to set up the picture quality of the connected TV set or discs by pressing ok and UP/DOWN/LEFT/RIGHT keys.
- Page 19 Normal Settings (2-4). AUDIO, SUBTITLE and DISC MENU Select a preferred audio language, subtitle language and disc menu language in these items. You can also change the audio language by pressing [AUDIO] and the subtitle language by Pressing [SUBTITLE] on the remote control.
- Page 20 Normal Settings (7). DEFAULT Restore all the default settings except the settings in PASSWORD setup page and the PARENTAL item.
-
Page 21: Discs Supported
Discs Supported This portable DVD player supports below types of discs: Types of Discs Diameter Data Format Remark 12cm DVD Format Disc: Comperessed Digital Audio Comperessed Digital Video (Moving Picture) SVCD 12cm MPEG2 Include: SVCD, Comperessed Digital Audio Comperessed Digital Video (Moving Picture) 12cm MPEG1... -
Page 22: Trouble Shooting
Trouble shooting... -
Page 23: Specifications
Specifications Type of Disc DVD, VCD, HDCD, MP3, DVD R, DVD RW...ect Video Format MPEG2 of DVD:MPEG1 of VCD, DIVX MPEG4 Audio Format MPEG1, MPEG2, PCM, DOLBY, DIGITAL, STEREO ANALOG Signal Output Video system: NTSC or PAL Video : 1.0 Vp-p Audio: Stereo mix 2 Vp-p Audio Output Audio, Earphone...
