Magellan MG10LEDV User Quick Reference Manual

MG10LEDV/H - User's Quick Reference Guide
Arm (red), Sleep (yel), Stay (grn):
On = Partition armed
Off = Partition disarmed
Flash = Exit Delay
Fast Flash* = Exit Delay (final 10
sec.)
Fast Flash* = Partition in alarm
* Audible Indicators:
Continuous beep = Alarm
Variable beep = Fire alarm
Intermittent beep = Beginning of
exit delay
Fast beep = Final 10 sec. of exit
delay
= Press once + [
] for Quick Menu
CODE
Programming
TO ARM
WHEN LEAVING
To Regular Arm:
1. Close all zones in the desired
partition.
2. Press [ ].
ARM
3. Enter your [
ACCESS CODE
* If needed, press button(s) corresponding to desired partition(s). For two partitions, press the other key after
the confirmation beep.
K
EYPAD
Partition 1 Status Partition 2 Status
On = StayD
Mode Enabled
MASTER
A
RMING AND
...
]*.
To Disarm:
[ ] + [
OFF
O
VERVIEW
D
ISARMING
TO ARM
WHEN STAYING
To Stay Arm:
1. Press the [
2. Enter your [
To Sleep Arm:
1. Press the [
2. Enter your [
]*
ACCESS CODE
Off Light (red):
On = Disarmed
Off = System armed
AC Light
On = Power on
Off = Power off
Zone Display:
Keys [1] to [0(10)] correspond
to zones 1 to 10 respectively.
Key Lit: Open or entry delay
Key Flash: In alarm
[ ] Trouble display
TBL
On = Trouble(s) occurring
[ ] Alarm memory display
MEM
On = Alarm(s) occurred
[ ] Bypass programming
BYP
On = Zone(s) bypassed
...
] key.
STAY
]*.
ACCESS CODE
] key.
SLEEP
]*.
ACCESS CODE
