Yale HSA6080 Manual

Key Pad Manual 8/12/06
Wirefree Yale HSA6080
Remote keypad
(Yale part number: 666080001001)
Pack contents
• 1 x HS0A6080 Remote keypad with
separate cradle.
• 2 x wall plugs.
• 2 x 2.3mm x 6mm fixing screws.
• 2 x 3.5mm x 15mm wall plugs.

Keypad description

Cradle: The keypad can be operated
ether in the cradle or be handheld. The
cradle has an attractive flip down lid
concealing the keypad. When the lid is
flipped down the keypad is easily
detached by sliding upwards and out for
convenience. Cradle fixing slots: Used for
cradle wall mounting.
LED Indicator: Displays keypad status.
Numeric Keys: Used for entering user
11:53 am Page 1
R
Keypad cradle
closed
Fixing Slots X 2
Keypad
Cradle Open
codes.
Arm Key: Press for Away Arming.
Panic Keys A and B: Press both for
Panic alarm.
Home Arm Key: Press to partially arm.
Disarm Key: Used with user code to
switch system off or to silence alarm.
Battery saver tab: Remove to activate
keypad battery supply.
Cradle guide: Locates keypad in cradle.
Case Screws: Provides access to
keypad for battery replacement.
HSA6000 series
