- Page 1 Wall-mounted condensing boilers Installer’s and User’s instructions Hydroheat Supplies Pty Ltd PO Box 1045, 6 Helen Kob Drive Braeside VIC 3195 Ph 03 9588 1299 Fax 03 9588 2199...
-
Page 2: Table Of Contents
(ISO 9001), environmental (ISO 14001) and health and safety (OHSAS 18001) systems. This means that BAXI S.p.A. includes among its objectives the safeguard of the environment, the reliability and quality of its products, and the health and safety of its employees. -
Page 3: Instructions Prior To Installation
1. INSTRUCTIONS PRIOR TO INSTALLATION This appliance shall be installed in accordance with the manufacturer’s installation instructions, local gas fitting, electrical and water authority regulations, municipal building codes, AS5601 - Gas Installations and any other relevant statutory regulations. This boiler is designed to heat water at a lower than boiling temperature at atmospheric pressure. The boiler must be connected to a central heating system and to a domestic hot water supply system in compliance with its perfor- mances and output power. -
Page 4: Commissioning Of The Boiler
3. COMMISSIONING OF THE BOILER To correctly light the burner proceed as follows: 1) provide power supply to the boiler; 2) open the gas cock; 3) follow the directions given below regarding the adjustments to be made at the boiler control panel. Figure 1 IMPORTANT: The instructions contained in this manual relating to the operation of the hot water... - Page 5 3.1 DESCRIPTION OF KEYS (2) This key can be pressed to set the central heating water output temperature as described in point 3-3. (3) This key can be pressed to set the domestic hot water temperature as described in point 3-4. (10) Central heating mode operating key key can be pressed to activate four boiler central heating operating modes;...
- Page 6 3.2 SETTING THE TIME a) Press either of the keys to access the programming function; the display will show the letter P followed by a number (program line); Figure 3 b) press the keys until the display shows P1, referring to the time to be set; c) press the keys to set the time;...
- Page 7 3.5 SETTING THE DAILY PROGRAM FOR OPERATION IN CENTRAL HEATING AND DOMESTIC HOT WATER MODES 3.5.1 Setting the daily times for central heating mode operation - Press either of the keys to access the programming function; a) press these keys until the display shows P11, referring to the program start time; b) press the keys to set the time;...
- Page 8 3.7 TABLE OF USER-SETTABLE PARAMETERS Parameter Factory Parameter description Range setting Time of day setting ———- 0…23:59 Minimum central heating temperature setting (°C) 25..80 Start of first daily period of automatic central heating 6:00 00:00…24:00 End of first daily period of automatic central heating 22:00 00:00…24:00 Start of second daily period of automatic central heating...
- Page 9 3.9 FAULT WARNINGS TABLE Fault code Fault description action required outdoor temperature probe sensor failure call the authorised service centre. NTC output sensor failure call the authorised service centre NTC return heating probe faulty call the authorised service centre domestic hot water ntc sensor failure call the authorised service centre Safety or fumes thermostat or heating return press the reset key (for about 2 seconds: if this device is triggered...
-
Page 10: Filling The Boiler
Lastly, vent any radiators in the system. BAXI declines all liability for damage deriving from the presence of air bubbles in the primary exchanger due to the incorrect or imprecise observance of the above. -
Page 11: General Information
8. GENERAL INFORMATION The following remarks and instructions are addressed to Service Engineers to help them carry out a faultless installation. In- structions regarding lighting and operation of the boiler are contained in the ‘Instructions pertaining to the user’ section. Note that installation, maintenance and operation of the domestic gas appliances must be performed exclusively by qua- lified personnel in compliance with current standards. -
Page 12: Boiler Installation
Lastly, vent any radiators in the system. BAXI declines all liability for damage deriving from the presence of air bubbles in the primary exchanger due to the incorrect or imprecise observance of the above. -
Page 13: Boiler Size
11. BOILER SIZE MR: G 1-1/2” heating flow RR: G 1-1/2” heating return GAS: G 1” gas inlet to the boiler SC: condensation drain Figure 5 Figure 6 INSTRUCTIONS PERTAINING TO THE INSTALLER 910.024.1 - EN (AUS) -
Page 14: Installation Of Flue And Air Ducts
By means of a splitting kit a two-pipe system may also be installed. In case exhaust and intake flues not supplied by BAXI S.p.A. have been installed, these must be certified for the type of use and must have a maximum pressure drop in according to the values reported in the table (par 12.1). - Page 15 Horizontal flue terminal Ø 110/160 mm installation options LAS flue duct Ø 110/160 mm installation options L max = 10 m Vertical flue terminal Ø 110/160 mm installation options This type of installation can be carried out both on a flat or pitched roof by fitting a terminal, an appropriate weathering tile and sleeve, (supplementary fittings supplied on demand).
- Page 16 … separated flue-air ducting This type of ducting allows to disengage exhaust flue gases both outside the building and into single flue ducts. Comburant air may be drawn in at a different site from where the flue terminal is located. The splitting kit consists of an air cap (160/110) and of an air duct adaptor.
- Page 17 Separated horizontal flue terminals installation options IMPORTANT - Make sure there is a minimum downward slope of 1 cm per metre of duct towards the boiler. Make sure the flue and air ducts are firmly fixed to the wall with suitable brackets. (L1 + L2) max = 27 m The maximum length of the suction duct must be 7 metres.
- Page 18 LUNA HT 1.850 CONCENTRIC PIPE Ø 110/160 (C13 – C33 – C43) PARAMETERS PIPES ΔP LENGTH MAX HEAT OUTPUT MIN HEAT OUTPUT IGNITION LOAD H536-H613 H541-H610 H612 H609 H611 H608 (Pa) (rpm) (pwm%) (rpm) (pwm%) (rpm) (pwm%) 0 m ÷ 2 m...
- Page 19 LUNA HT 1.1000 CONCENTRIC PIPE Ø 110/160 (C13 – C33 – C43) PARAMETERS PIPES ΔP LENGTH MAX HEAT OUTPUT MIN HEAT OUTPUT IGNITION LOAD H536-H613 H541-H610 H612 H609 H611 H608 (Pa) (rpm) (pwm%) (rpm) (pwm%) (rpm) (pwm%) 0 m ÷ 2 m 6400 1850 3100...
-
Page 20: Connecting The Mains Supply
13. CONNECTING THE MAINS SUPPLY Electrical safety of the appliance is only guaranteed by correct grounding, in compliance with the applicable laws and regulations. Connect the boiler to a 230V monophase + ground power supply by means of the three-pin cable supplied with it and make sure you connect polarities correctly. - Page 21 Cover Terminal board Terminal board Cover Terminal board P1 = Low loss header pump P2 = Heating circuit pump SI = Low loss header UR = Central heating unit Safety valve (*) Expansion vessel (*) available optional extra Figure 10 INSTRUCTIONS PERTAINING TO THE INSTALLER 910.024.1 - EN (AUS)
- Page 22 - Exchangers pressure drop WATER FLOW RATE (l/h) Graph 1 The minimum ga boiler water flow, with at least 1 - 1,5 bar, must be as follow: Minimum water Water flow rate LUNA HT flow rate with Δt=20°K Model 1.850 1900 3700 1.1000...
- Page 23 QAA73: parameters which can be set by the installation engineer (service) By pressing the two PROG buttons together for at least three seconds it is possible to access the list of parameters that the installer can display and/or set. Press either of these buttons to change the parameter to display or change. Press the [+] or [-] key to change the value displayed.
- Page 24 13.4 CONNECTING THE OUTDOOR TEMPERATURE SENSOR The SIEMENS model QAC34 outdoor temperature sensor (optional accessory) must be connected to terminals 7-8 of terminal board M2 in figure 9. The procedures for setting the gradient of the temperature curve “kt” vary depending on the accessories connected to the boiler.
- Page 25 TM = Flow temperature Te = Composite outside temperature Graph 4 c) with AGU2.500 device for control of a low temperature system: Refer to the instructions provided with the AGU2.500 accessories for connection and control of a low temperature zone. In this case the set of some electronic parameters have to be modified (see §...
- Page 26 2 ZONE 3 ZONE n ZONE BOILER (ROOM THERMOSTAT) (ROOM THERMOSTAT) (ROOM THERMOSTAT) CIRCULATING PUMP 2 ZONE- 3 ZONE- N ZONE- PUMP PUMP PUMP 1 ZONE WATER TANK (QAA73) PUMP 1 ZONE PUMP HEATING CUT-OUT RELAY Figure 11 c) with AGU2.500 device for control of a low temperature system: Refer to the instructions provided with the AGU2.500 accessories for connection and control of a low temperature zone.
- Page 27 STORAGE TANK CONNECTION DIAGRAM KEY: - DOMESTIC HOT WATER HEATER UNIT - CENTRAL HEATING UNIT M2 and M3 - CONNECTION TERMINAL BOARD - DOMESTIC HOT WATER SENSOR - LOW LOSS HEADER PUMP - CENTRAL HEATING PUMP - D.H.W. PUMP - LOW LOSS HEADER Figurr 12 WARNING: In the case of a direct coupling of the boiler coil fitting on the boiler unit’s “T”...
-
Page 28: Gas Valve Adjustment
14. GAS VALVE ADJUSTMENT Carry out the following ope rations in the given sequence: 1) Calibration of the maximum heat output. Check that the CO measured on the flue, with the boiler operating at the maximum heat output, is the same as that shown in table 1. Otherwise, turn the regulation screw (V) on the gas valve. Turn the screw clockwise to reduce the concentration of CO and anticlockwise to increase it. - Page 29 Figure 14 Natural Gas - 1.13kPa Propane Gas - 2.75kPa max. heat output 8.7 % 10.2 % min. heat output 8.4 % 9.8 % Table 1 Gas consumption at 15 °C 1013 mbar 1.850 1.1000 LUNA HT LUNA HT Natural Gas - 1.13kPa PCI (MJ/m ) NET 34.02...
-
Page 30: Setting The Boiler Parameters
15. SETTING THE BOILER PARAMETERS The boiler parameters may only be modified by professionally qualified staff proceeding as follows: a) press the , keys on the boiler’s front panel together for about 3 s until the parameter H90 appears on the display; b) press the keys to select the parameter for modification;... -
Page 31: Control And Operation Devices
16. CONTROL AND OPERATION DEVICES The boiler has been designed in full compliance with European reference standards and in particular is equipped with the following • Overheat thermostat Thanks to a sensor placed on the heating flow, this thermostat interrupts the gas flow to the main burner in case the water contained in the circuit has overheated. -
Page 32: Positioning Of The Ignition And Flame Sensing Electrode
17. POSITIONING OF THE IGNITION AND FLAME SENSING ELECTRODE Figure 15 18. CHECK OF COMBUSTION PARAMETERS To measure combustion performance and hygiene levels of combustion products, the forced draught boiler models are equipped with two test points on the tapered coupling specifically designed for this purpose. One of the two test points is connected to the exhaust flue duct to allow measurements of the combustion products hy- gienic standards and combustion efficiency. -
Page 33: Activating The Chimney-Sweeper Function
19. ACTIVATING THE CHIMNEY-SWEEPER FUNCTION To facilitate measurement of the combustion efficiency and improve the cleanliness of the production products, the flue- sweeper function can be activated by proceeding as described below: 1) press the (2-3) together until the pointer “ ” appears on the display alongside the symbol (about 3 seconds but no more than 6 seconds). -
Page 34: Boiler Schematic
21. BOILER SCHEMATIC air/gas diaphragm Figure 18 Legend: boiler drain point manometer siphon NTC delivery heating probe 105°C overheat thermostat gas valve flue-water exchanger flame detector electrode burner ignition electrode gas mixture header mixer with venturi gas diaphragm flue thermostat coaxial fitting automatic air vent hydraulic pressure sensor... -
Page 35: Illustrated Wiring Diagram
22. ILLUSTRATED WIRING DIAGRAM INSTRUCTIONS PERTAINING TO THE INSTALLER 910.024.1 - EN (AUS) -
Page 36: Technical Data
(**) according to EN 60529 BAXI S.p.A., in its commitment to constantly improve its products, reserves the right to alter the specifications contained herein at any time and without previous warning. These Instructions are only meant to provide consumers with use information and under no circumstance should they be construed as a contract with a third party.
