C601-Cover(US) 4/12/01 9:44 AM Page 2 SAMSUNG ELECTRONICS AMERICA INC. 105 CHALLENGER ROAD, RIDGEFIELD PARK, NJ 07660 U.S.A. FOR YOUR NEAREST SAMSUNG SERVICE CENTER DIAL 1-800-SAMSUNG AH68-00719M DVD-C601...
FCC NOTE (for U.S.A): This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
If remote doesn’t operate Install Batteries in the Remote Open the battery cover on the • Check the polarity + - of the batteries back of the remote. (Dry-Cell) • Check if the batteries are drained. Insert two AA batteries. Make sure that the polarities (+ and -) •...
Number Play Region Number Both the DVD player and the discs are coded by region. These regional codes must match in order for the disc to play. If the codes do not match, the disc will not play. The Region Number for this player is described on the rear panel of the player.
COMPONENT VIDEO OUT JACKS • Use these jacks if you have a TV with Component Video in jacks. These jacks provide Pr, Pb and Y video. Along with S-Video, Component Video provides the best picture quality. The Y, Pb, Pr must be selected in the VIDEO OUT SELECT.
DISPLAY Button • Displays the current disc mode. ENTER/DIRECTION Button (UP/DOWN or LEFT/RIGHT buttons) ANGLE Button • Use to access various camera angles on a DVD. MODE Button • Allows you to program a specific order. SUBTITLE Button AUDIO Button •...
• Always turn off the DVD player, TV, and other components before you connect or disconnect any cables. • Refer to the owner’s manual of the additional components you are connecting for more information on those particular components. Connection to an Audio System...
RESUME function When you stop disc play, the player remembers where you stopped, so when you press PLAY again, it will pick up where you left off (unless the disc is removed, the STOP button is pressed twice or the player is unplugged.).
4/12/01 9:43 AM Page 16 Operating the Disc Changer The DVD Changer holds 5 discs and provides full random play with fast disc changes. Exchanging Discs Exchange allows you to change up to 4 discs except the disc currently playing.
• Depending on the disc, the Repeat function may not work. • If the title or track is completed before marking the end (B), the end of title or track becomes B automatically. • When in VCD 2.0 mode (MENU ON mode), this function does not work.
• When in VCD 2.0 mode (MENU ON mode), these functions do not work. • To resume normal play, press the CLEAR button. • Random Play can be operated only in the same disc format (only in CDs or in DVDs) Screen Fit Play PROGRAM 01 Press Screen FIT button on remote control.
9. NOTE • You can play the DVD player starting with the desired chapter after directly moving to the scene you want. • 'DIGEST' may not operate depending on the disc in use. This feature allows you slowly repeat scenes containing sports, dancing, musical instruments being played etc.
INDEX VIEW example NOTE • This function depends on what languages are encoded on the disc and may not work with all DVDs. • A DVD disc can contain up to 8 audio languages. • How to have the same audio language come up whenever you play a DVD;...
- The subtitle languages are represented by abbreviations. NOTE • This function depends on what languages are encoded on the disc and may not work with all DVDs. • A DVD disc can contain up to 32 subtitle languages. •...
4/12/01 9:43 AM Page 28 Using the Bookmark Function The Bookmark function lets you select parts of a DVD or VCD (MENU OFF mode) so that you can quickly find the section at a later time. Using the Bookmark Function (DVD/VCD) During play, press the BOOKMARK button on the remote.
To make the setup screen disappear after setting up, press the SETUP button again. If you set the player menu, disc menu, audio and subtitle language in advance, they will come up automatically every time you watch a movie. Using the Player Menu Language...
- English is selected and the screen returns to SETUP MENU. The Parental Control function works in conjunction with DVDs that have been assigned a rating - which helps you control the types of DVDs that your family watches. There are up to 8 rating levels on a disc.
LPCM, DTS or MPEG-2 Audio. NOTE • How to make the SETUP MENU disappear or return to menu screen during set up; Press RETURN button. • Certain audio features of this product manufactured under a license from Desper Products, Inc.
• Make sure you have selected the correct Digital Output in the Audio No audio. Options Menu. • Press power on from a cold start with no disc in the unit. Press the STOP Forgot password and PLAY buttons simultaneously on the front panel for three seconds. The Select Menu Language display will appear.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncom- mercial use of this product and shall not apply to the following, including, but not limited to: damage which occurs in shipment; applications and uses for which this product was not intended; failures or problems which are caused by products or equipment not supplied by SAMSUNG;...
