HTC One E8 Manual

HTC One (E8) dual sim
Inserting your nano UIM/SIM and microSD cards
IMPORTANT: USE A STANDARD NANO UIM/SIM ONLY.
Inserting a modified SIM may damage the card slot or
cause the card to not fit properly.
CDMA/
3G/GSM
GSM Only
nano SIM
microSD
cut-off corner
gold contacts
1. Insert the tip of the tray
eject tool (or a small bent
paperclip) into the hole
next to the nano UIM/SIM
card tray that's on the left
side of the phone.
Push the tip all the way
into the hole until the tray
ejects, and then pull the
tray out.
2. With contacts facing
down, place a nano
UIM/SIM card into the
SIM 1 holder (supports
CDMA/3G/GSM).
Place your second nano
SIM card into the SIM 2
holder (supports GSM
only).
If the card is NFC-enabled,
it must be placed in
the SIM 1 holder to be
recognized.
Insert the tray back into
the slot.
