Samsung Galaxy S Quick Start Manual

LEARNING THE BASICS INSERT SIM/USIM CARD
1. Turn the phone off and remove the back cover.
Front Camera Lens
(for video calls)
Sensors
Volume Key
Earpiece
Touch Screen
2. Insert the SIM or USIM card.
Home Key
Back Key
Menu Key
Microphone
Multifunction Jack
Note: Insert the
Microphone SIM card with the
(speakerphone or Headset Jack gold-coloured contacts
video recording) facing down.
Flash 3. Insert the battery.
Speaker
Power Key
Rear Camera
Lens
Back Cover
4. Replace the back cover.
Internal antenna
I747M_QSG_EN_D5.indd 1
CHARGING THE BATTERY PLAY STORE
Play Store provides you an easy and quick way to shop for
1. Locate the multifunction jack on the bottom of the phone.
games and mobile applications.
2. Plug the small end of the travel adapter into the
multifunction jack.
To install applications:
3. Plug the large end of the travel adapter into a power
1. In Idle mode, select Apps → Play Store.
outlet.
2. Select Accept when the terms and conditions appear.
4. When the battery is fully charged (the battery icon is
3. Select an item category and then select an item.
no longer moving), unplug the travel adapter from the
phone and then from the power outlet.
4. Select Install (for free items) or the price button (to
purchase an item).
WIRELESS FUNCTIONS
5. If you select Install, the item downloads immediately.
1. In Idle mode, select Apps → Settings.
6. If you select the purchase price, you need to enter your
credit card information. Follow the on-screen instructions.
2. Set the Wi-Fi slider to ON or OFF.
To uninstall applications:
1. From the Play Store home screen, press
GET TO KNOW THE IDLE SCREEN
Apps.
To scroll through the Idle screen: 2. Select the item that you want to delete.
Drag left or right to view the hidden areas of the Idle screen. 3. Select Uninstall → OK.
To add items to the Idle screen:
SYNCHRONIZE DATA
1. Tap and hold an empty area on the idle screen and
select Add to Home screen. You can synchronize data (Google messages, calendar,
and contacts) with the Google web server and back up or
2. Select the item category and then select an item:
restore your data.
• Apps: Add applications or widgets.
To activate automatic sync:
• Folder: Create a new folder.
1. In Idle mode, select Apps → Settings → Accounts
• Page: Add a page to the home screens.
and sync.
2. Set the Accounts and sync slider to ON.
3. Select an account
4. Select the applications to be synchronized. To exclude
applications, clear their checkboxes.
TECHNICAL SPECIFICATIONS
To synchronize data manually:
Network
1. In Idle mode, select Apps → Settings → Accounts
and sync.
•
LTE dual band
2. Select an account.
• HSPA+ Tri band
3. Select Sync now. Your device will start synchronizing
•
GSM/EDGE/GPRS quad band
the data you set for synchronization.
Dimensions: 136.6 x 70.6 x 8.6 mm
Wi-Fi
Weight: 133 g
Your device features wireless networking capabilities
Display: 4.8" 720 x 1280 SuperAMOLED
that allow you to connect to wireless local area networks
Battery: 3.8V Li-ion 2100 mAh
(WLANs).
Memory
To activate and connect to a WLAN:
• Phone Book: up to available memory
1. In Idle mode, select Apps → Settings → Wi-Fi. Your
phone automatically searches for available WLAN • Multimedia: Images, Videos, Sounds, and Game and
networks.
apps shared memory
→ My
2. Select a network under Wi-Fi networks.
Messaging Capabilities
3. Enter a password for the WLAN.
• Voice recorder
4. Select Connect.
• MMS
To add a WLAN:
• SMS
1. In Idle mode, select Apps → Settings → Wi-Fi.
•
IM
2. Select Add network.
• E-mail
3. Enter the SSID for the network and select the security
Camera / Video Specs
type.
4. Set the security settings depending on the selected • 8M pixel camera
security type.
•
3264 x 2448 camera resolution
5. Select Save.
• 1080p (1920 x 1080) at 30 fps
Bluetooth Supported Profiles
• Supports v4.0, A2DP, EDR
Expandable Memory: Up to 32 GB
THE FINE PRINT
Samsung Electronics Canada Inc.
Customer Care Centre
1.800.SAMSUNG
www.samsung.ca
Many of the services and features described above are network dependent
and may require additional subscription and/or usage charges. Not all
features are available for purchase or use in all areas.
Please Note: Standby and talk times will vary depending on phone usage
patterns and conditions. Battery power consumption depends on factors
such as network configuration, signal strength, operating temperature,
features selected, frequency of call, and voice, data and other application
usage patterns.
Compatibility with all Bluetooth® equipment is not guaranteed. The
Bluetooth technology trademarks are owned by Bluetooth SIG, Inc.,
Canada and used by Samsung Electronics Co. Ltd. under license.
© 2012 Samsung Electronics Canada Inc. All rights reserved. Samsung
is a registered trademark of Samsung Electronics Co. Ltd. and its related
entities. Specifications subject to change without notice.
